D+M Group DENON AVR-X4000W Model Information

Integrated network
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model Information
Index
Front Panel
Rear Panel
Remote Control
Warranty
Reset Procedure
Accessories
Protection History
Display Mode
Upgrades/Updates
Product Specifications
I/R Codes
NOTE:
This edition is missing the FAQ's content (pages 15 and 16) .................................................................7/28/2015
This edition is missing the link to the IR Codes.....................................................................................7/28/2015
MODEL:
Model Information
INTEGRATED NETWORK AV RECEIVER
AVR-X4000W
1
MI072815E3-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DENON AVR-X4000W and is the answer not in the manual?

Questions and answers

Related Manuals for D+M Group DENON AVR-X4000W

Summary of Contents for D+M Group DENON AVR-X4000W

  • Page 1 MODEL: AVR-X4000W Model Information Index Model Information Front Panel INTEGRATED NETWORK AV RECEIVER Rear Panel Remote Control Warranty Reset Procedure Accessories Protection History Display Mode Upgrades/Updates Product Specifications I/R Codes NOTE: This edition is missing the FAQ’s content (pages 15 and 16) ………………………………………………………..7/28/2015 This edition is missing the link to the IR Codes………………………………………………………………………..7/28/2015 MI072815E3-1...

  • Page 2: 4 Front Panel

    Front Panel  Power operation button (  SOURCE SELECT knob Used to turn the power of the MAIN ZONE This selects the input source. (room where this unit is located) on/off (standby).  Remote control sensor  Power indicator This receives signals from the remote control unit.

  • Page 3: Front Panel

    Buttons and Connectors Behind the Compartment Door (1 of 2)  AUX1 HDMI 7 connector  AUX1 INPUT connector Used to connect HDMI output compatible devices such as video Used to connect analog output compatible devices such as video cameras and game consoles. cameras and game consoles.
  • Page 4 Buttons and Connectors Behind the Compartment Door (2 of 2)  Information button (INFO) This displays the status information on the TV screen.  STATUS button Each press of this switches the status information that is shown on the display. ...
  • Page 5 Display 7 8 9     Input signal indicators  MUTE indicator The respective indicator will light corresponding to the input signal. This blinks while the sound is muted. link,  Decoder indicators  Volume indicator These light when Dolby or DTS signals are input or when the Dolby or DTS ...

  • Page 6: Rear Panel (1 Of 2)

    Rear Panel (1 of 2)  FM/AM antenna terminals (ANTENNA)  SIGNAL GND jacks Used to connect FM and AM antennas. Used to connect a record player.  Speaker terminals (SPEAKERS)  Denon Link HD connector Used to connect speakers. ...

  • Page 7: Rear Panel (2 Of 2)

    Rear Panel (2 of 2)  Network connector (NETWORK) Used to connect this unit to the network.  TRIGGER OUT jacks Used to connect devices equipped with the trigger function.  Analog audio connectors (AUDIO) Used to connect devices equipped with analog audio connectors. NOTE: Do not touch the inner pins of the connectors on the rear panel.

  • Page 8: Remote Control (1 Of 3)

    Remote Control (1 of 3)  AVR operation buttons (AVR CONTROL MAIN, Z2, Z3) These switch the zone (MAIN ZONE, ZONE2, ZONE3) that is operated through the remote control unit.  Operation mode indicators The “AVR” operation mode indicator lights when the unit is being operated.

  • Page 9: Remote Control

    Remote Control (2 of 3)  System buttons. These perform playback related operations.  Skip buttons ( ) Play button (  Search buttons (  Pause button ( Stop button () Tuning up / Tuning down buttons (TUNE +, –). These select either FM broadcast or AM broadcast.

  • Page 10: Remote Control (3 Of 3)

    Remote Control (3 of 3)  VOLUME buttons () These adjust the volume level.  OPTION button This displays the option menu on the TV screen.  ENTER button This determines the selection.  SETUP button This displays the menu on the TV screen. ...

  • Page 11: Denon Limited Warranty (1 Of 2)

    DENON LIMITED WARRANTY (1 of 2) This warranty will be honored only in the U.S.A. Length of Non-Transferable Warranty This warranty on your DENON product which is distributed and warranted by DENON ELECTRONICS (USA), LLC remains in effect for the following periods from the date of the original consumer purchase from an AUTHORIZED DENON ELECTRONICS (USA), LLC DEALER.
  • Page 12 Warranty (2 of 2) What is Covered Except as specified below, this Warranty covers all defects in material and workmanship in this product occurring during the above warranty periods. The following are not covered by the Warranty: (1) Any product which is not distributed in the U.S.A. by DENON ELECTRONICS (USA), LLC. (2) Any product which is not purchased in the U.S.A.
  • Page 13 Reset Important: Back up the settings before resetting the microprocessor. Most settings are reset to the factory default values after performing this procedure. This means that all the settings data will be completely lost if it’s not previously saved. Power/Standby “INFO”...
  • Page 14 Accessories Sound Remote Control Sound Calibration (RC1185) Calibration Microphone Microphone Stand (ACM1HB) 30701013600AD $52.99 32401000800AD $31.99 963549101000D $16.82 AM Loop FM Indoor Power Cord) Antenna Antenna 963116100070S $8.99 943116100170D $5.99 943611500750D $9.99 Safety CD ROM External Instructions Antennas For Owner’s Bluetooth/Wire Manual less...
  • Page 15 FAQ’s ( 1 of 2) HOME ACCESSORIES FAQ’s 2...
  • Page 16 FAQ’s (2 of 2) HOME FAQ’s 1 UPGRADE...
  • Page 17 Upgrades/Updates Firmware: This unit has the ability to update its firmware over the internet if so is selected by the user. When connected to a network via Wi-Fi or Ethernet, the AVR searches automatically for new updates and if any is found, a message appears on the screen for approx. 40 seconds with the options of updating the firmware: “NOW”, “LATER”, or “IGNORE”.

  • Page 18: Specifications - Audio Section

    Specifications – Audio Section Audio section 125 W + 125 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.05 % T.H.D.) Front 165 W + 165 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.) 125 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.05 % T.H.D.) Center 165 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.) Rated output...

  • Page 19: Specifications - Video Section, Tuner Section, General Section

    Specifications - Video section, Tuner Section, General Section Video section Input/output level and impedance 1 Vp-p, 75 Ω/ohms Standard video connectors Frequency response 5 Hz -10MHz, 0, - 3dB Y signal 1 Vp-p, 75 Ω/ohms Input/output level and impedance PB/CB signal 0.7 Vp-p, 75 Ω/ohms Color component video connector PR/CR signal...

  • Page 20: Specifications - Dimensions, Weight

    Specifications – Dimensions, Weight Dimensions section (Unit : inch/mm) Weight: 27 lbs 2 oz (12.3 kg) HOME SPECIFICATIONS - SPECIFICATIONS VIDEO SPECIFICATIONS - AUDIO - TUNER - GENERAL DIMENSIONS - WEIGHT...
  • Page 21 The End NOTE: This edition is missing the FAQ’s content (pages 15 and 16) ………………………………………………………..7/28/2015 This edition is missing the link to the IR Codes………………………………………………………………………..7/28/2015 HOME...
