Summary of Contents for DOM RONIS CoverK
- Page 1 CoverK Assembly...
-
Page 2: Drilling Template
Drilling template COVERK : Drilling temp ASSEMBLY Right hand door... - Page 3 K : Drilling template Left hand door...
- Page 4 Accessories ASSEMBLY ø3.8x39.7 ø4x26.6 ø4x14 Strike plate Sticker Battery pack...
- Page 5 Right door assembly ASSEMBLY 19 mm Section A-A x mm 19 + x mm ø2.5...
- Page 6 Right door assembly ASSEMBLY IMPORTANT: Do not use an electric screwdriver or drill to attach the battery holder. Make sure the battery holder does not plunge into the lock. Right door...
- Page 7 Left door assembly ASSEMBLY 19 mm Section A-A x mm 19 + x mm ø2.5...
- Page 8 Left door assembly ASSEMBLY IMPORTANT: To fix the batteries container don’t use electric screwdriver or drill. Make sure the battery holder does not plunge into the lock. Left door...
- Page 9 WARNING Do not mount ejectors Depending on door type on door with force higher (left or right), assemble according than 15N. to the below images: 70,6 70,6 Left door Right door IMPORTANT We suggest changing batteries once every three years to ensure their good condition.
-
Page 10: Important Notes
Important notes ASSEMBLY IMPORTANT Maximum door thickness: 20mm. The lock won’t work when mounted on metal door. To allow IP65 rate : ■ Maximum rugosity of the door : Rt = 18 micrometers (VDI 3400N°33) ■ Flatness of the assembly area of the lock : 0.1mm The Management / Master cards are configured for a single... -
Page 11: Battery Warnings
Battery warnings ASSEMBLY ..If the CoverK continuously beeps, the batteries are low. The lock will no longer engage. 1. Unscrew the screw with the T20. 2. Release the battery holder. 3. Replace the old batteries. 4. Screw the battery holder back into place.
