BGS technic 6667 Instruction Manual

TOOLS

1 Centering mandrel (clutch disc), 42 - 52 mm
2 Centering mandrel (clutch disc), 36 - 45 mm
3 Centering sleeve (pilot bearing), 30 mm
4 Centering sleeve (pilot bearing), 27 mm
5 Centering sleeve (pilot bearing), 25 mm
6 Centering sleeve (pilot bearing), 20 mm
7 Replacement O-rings

INTENDED USE

This tool set is required when replacing truck single and double clutch discs and allows a professional
centering of clutch discs.

SAFETY INFORMATIONS

• Read carefully the instructions before working with this tool set.
• Do not use this tool set for other purpose for which it is designed.
• Observe the general safety instructions for garages.
• Keep your work area tidy and clean. Areas or corridors which are untidy increase the risk of injury.
• Lifting of vehicles only allowed on the special lifting points.
• Before starting the work under a vehicle always ensure that it is adequately supported by axle
stands or ramps. Chock wheels and ensure that the hand brake is firmly applied.
• Always use approved eye protection, especially when working under vehicles.
• Ensure a secure and well-gripped stance during fitting.
• Check the condition of the tool regularly and do not use it if it is damaged.
• Make sure the tool is properly mounted.
• This manual serves as a brief guide and does not replace a workshop manual. Always refer to the
vehicle-specific service literature, particularly the technical data such as torque values and
instructions for disassembly/assembly, etc..
• Keep children and other unauthorized persons away from the work area.
• Do not let children play with the tool or its packaging and keep this tool out of the reach of
children.
