AK - 45
CHASSIS
SIF AGC for gain controlled SIF amplifier; single reference QSS mixer able to operate in high performance
single reference QSS mode and in intercarrier mode, switchable via I
AM demodulator without extra reference circuit
Alignment-free selective FM-PLL demodulator with high linearity and low noise
I 2 C-bus control for all functions
I 2 C-bus transceiver with pin programmable Module Address (MAD).

13.13.3.Pinning

SYMBOL PIN
VIF1 1
VIF2 2
OP1 3
FMPLL 4
DEEM 5
AFD 6
DGND 7
AUD 8
TOP 9
SDA 10
SCL 11
SIOMA 12
n.c. 13
TAGC 14
REF 15
VAGC 16
CVBS 17
AGND 18
VPLL 19
V 20
P
AFC 21
OP2 22
SIF1 23
SIF2 24

13.14.PI5V330

13.14.1.General Description

The PI5V330 is well suited for video applications when switching composite or RGB analog.
DESCRIPTION
VIF differential input 1
VIF differential input 2
output 1 (open-collector)
FM-PLL for loop filter
de-emphasis output for capacitor
AF decoupling input for capacitor
digital ground
audio output
tuner AGC TakeOver Point (TOP)
I 2 C-bus data input/output
I C-bus clock input
2
sound intercarrier output and MAD select
not connected
tuner AGC output
4 MHz crystal or reference input
VIF-AGC for capacitor; note 1
video output
analog ground
VIF-PLL for loop filter
supply voltage (+5 V)
AFC output
output 2 (open-collector)
SIF differential input 1
SIF differential input 2
22
2 C-bus
