Sharp C-2890EES Service Manual page 15

REF No. PARTS DESCRIPTION
R931 30012667 RES SMD 1/16W 220K J (0603)
R932 30012707 RES SMD 1/16W 680R J (0603)
R933 30012707 RES SMD 1/16W 680R J (0603)
MISCELLANEOUS PARTS
. 20024343 SNOW BOX ASSY.2850/51
. 20024254 SNOW BOX-BOTTOM 2850/51
. 20024255 SNOW BOX-TOP 2850/51
. 20072943 FRONT 2850M W/H HIT.FUME (P)
. 20094177 BASE 2850-51 (I) WO/CHASSIS FRAME AK28
!
. 20004519 CABLE HOLDER CRT (I)
. 20095238 BACK CVR.2850/51 AK28 H.FUME (P)
!
. 20126784 BUTTON ASSY.2850M (HIT.FUME/P)
. 20035216 LENS 2850 (I)
. 20035214 BUTTON FUNCTION 2850 5T (I)
. 20035209 BUTTON ON/OFF 2850 (I) (SM BASKI)
. 60000003 ABS BLACK
. 35000013 SPRING ON/OFF SWITCH
. 20140227 MD.ASY.TK123-2850/51 5SW (AK41)(SHARP)
. 20140956 CHS.ASSY.45-315C21514111121B1122B
. 30018087 CNAS 2P/350 TRFPFC DIS W/C
. 35000217 SCREW S C SYF YFMB 3.5*9.5
. 35000136 FUSE HOLDER TK79-A (GRAY)
. 20093231 CHS. FRAME JVC AK37 (I) V-0 (3.kalýp)
. 20095322 PASIF PFC 37-TRF0,9A (25-28-29-28"16/9)
. 35005061 SCREW RB C SK ZN YFMB 2.9*9.5
. 30007728 CABLE 1P R2.6 50 W/CLIPS
. 30009833 CABL 1P/100 SIS
. 30009833 CABL 1P/100 SIS
. 30019101 CABL 1P/350 DIS UL1672AWG22
. 20149936 ON/OFF SW ASSY.FTZ AK45 SHARP (MAKARONLU
. 30022450 SWITCH SAFE ON/OFF 8A/128A
!
. 30028208 POWER CORD SAFE EURO 2.2M SHARP W/FILTER
!
. 30028092 SPEAKER 8R 15W 57*160 (improved)
. 30028092 SPEAKER 8R 15W 57*160 (improved)
. 35000010 EARTH SPRING (4CM)
. 20152057 CRT B.ASSY.TP45B-5-SING.FOCUS(AK45)SHARP
. 20157327 SCREW ASSY.2850/51 HP/2SC(45)
. 20108124 BACK DOOR AK45/52 (I)
. 35000199 SCREW S C ZN YSMB 3.9*25
. 35000212 SCREW S C ZNSY YSMB 2.9*13
. 35000212 SCREW S C ZNSY YSMB 2.9*13
. 35000214 SCREW S C ZNSY YSMB 3.5*19
. 35000224 SCREW C SK ZN YFMB 2.9*9.5
. 35000231 SCREW SK C NI YFMB 2.9*6.5
. 35000235 SCREW P C ZN AKBR 7*32
. 35004572 SCREW P C AgSYF YSB 4x20
. 20157329 R/C 1548 SHARP (GRAY/S)
. 50043630 WARRANTY CARD SHARP (ESP)
. 50049951 I/B SHARP C2890E P/AK45/1548/ESP/POR
. 20157362 LBL.BCK.CVR.SHA.EL.SHARP C2890E(ES)"45"
. 30009005 IC 24C16
. 40014959 LOGO BADGE SHARP (W/P-SILVER BRUSH/H.ST)
F100 30001731 FUSE SAFE 2.5A 250V 5*20MM
!
J344 30001996 FIXED COIL 22UH Q40 K
NOT 30011742 CABL 1P/25 SIS
PL1 30002302 CNAS 6P/450 TB FLT W/C UL2468AWG24
PL100 30001792 CONN HEADER 2P 7.5MM TOP WHT
!
PL101 30001795 CONN HEADER 3P 5/7.5MM TOP WHT
!
SN CODE EX CODE
REF No. PARTS DESCRIPTION
AA AB
PL102 30001792 CONN HEADER 2P 7.5MM TOP WHT
AA AB
PL204 30010921 DOUBLE-DECK SCART SOCKET
AA AB
PL206 30010039 CONN HEADER 8P 2.5MM TOP WHT
PL214 35000135 TEST PIN 1.1MM
PL500 30001783 CONN HEADER 5P 2.5MM TOP BD
AL AX
PL502 30001784 CONN HEADER 6P 2.5MM TOP BD
AE AP
PL602 30001792 CONN HEADER 2P 7.5MM TOP WHT
!
AE AP
PL602 30016483 CNAS 2P/600 HRZ DIS W/C UL1672AWG24
!
AQ BB
PL603 30001829 CONN HEADER 2P 2.5MM TOP WHT SD
AH AT
PL603 30019083 CNAS 2P/600 SIS W/C+FER UL1007AWG24
AA AB
PL604 30001850 CONN HEADER 6P 2.5MM TOP WHT SD
AT BE
PL708 30001762 CONN HEADER 2P 2.5MM(9.7MM) TOP
AA AD
PL709 30001764 CONN HEADER 2P 2.5MM(9.7MM) TOP BLACK
AB AG
PL901 30028447 SOCKET CRT SAFE NARROWNECK W/GND INCHANG
!
AC AG
PL902 30010039 CONN HEADER 8P 2.5MM TOP WHT
AB AG
PL902 30027546 CNAS 5P/350 SHL+3P/350 SIS RGB W/DC+FER
AK AV
PL903 30001850 CONN HEADER 6P 2.5MM TOP WHT SD
!
AA AB
PL903 30027043 CNAS 6P-4P+1P/600 SIS W/3C+FER UL1007
!
AF AR
PL905 35000135 TEST PIN 1.1MM
BP CE
PL909 35000135 TEST PIN 1.1MM
AA AE
S224 30000792 RES CF 1/4W 75R J
AA AB
S225 30012713 RES SMD 1/16W 75R J (0603)
AA AD
S226 30012713 RES SMD 1/16W 75R J (0603)
AD AL
S227 30012713 RES SMD 1/16W 75R J (0603)
AL AX
SG901 30000428 SPARK GAP 300V
AA AA
SG902 30000428 SPARK GAP 300V
AA AC
SG903 30000428 SPARK GAP 300V
AA AB
SG904 30000428 SPARK GAP 300V
AA AB
SG905 30021532 SPARK GAP 1500V
AA AB
SW1 30002181 SWITCH TACT(4)
AH AU
SW2 30002181 SWITCH TACT(4)
AC AK
SW3 30002181 SWITCH TACT(4)
AG AT
SW4 30002181 SWITCH TACT(4)
AE AN
SW5 30002181 SWITCH TACT(4)
AE AN
TH101 30001268 THERMISTOR 3P
!
AA AB
AS BD
AC AK How to update the Technical Information
AC AH
appeared on this Service Manual
AA AA
AA AB
1. Web site:
AA AB
AA AA
2. Select:
AA AB
AA AB
3. Login:
AA AC
AA AB
4. Password:
AM AY
AB AF
AC AK
By this access you can consult the latest schematic dia-
AA AC
gram or request the Parts Listing of a concrete Produc-
AF AQ
tion Date / Serial Number.
AA AE
AA AC
By this way it can be also consulted the issued Techni-
AA AB
cal Reports (Service Bulletins).
AA AB
AB AF
AA AC
AA AC
15
https://www.vestelservice.com
Technical Support
101278
SHPII278
C-2890EES
