In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its
original condition and only parts identical to those specified should be used.
» ELECTRICAL SPECIFICATIONS ......................................................................................................... 1
» IMPORTANT SERVICE SAFETY PRECAUTION ................................................................................. 2
» LOCATION OF USER'S CONTROL ..................................................................................................... 6
» INSTALLATION AND SERVICE INSTRUCTIONS ................................................................................ 7
» CHASSIS LAYOUT ............................................................................................................................. 13
» BLOCK DIAGRAM .............................................................................................................................. 14
» SCHEMATIC DIAGRAMS ................................................................................................................... 15
» PRINTED WIRING BOARD ASSEMBLIES ........................................................................................ 19
» REPLACEMENT PARTS LIST ............................................................................................................ 22
» PACKING OF THE SET ...................................................................................................................... 27
POWER INPUT .................................................... 120 V AC 60 Hz
POWER RATING .................................................................... 69 W
PICTURE SIZE ............................................. 580cm
CONVERGENCE ............................................................. Magnetic
SWEEP DEFLECTION .................................................... Magnetic
FOCUS ............................................... Hi-Bi-Potential Electrostatic
INTERMEDIATE FREQUENCIES
Picture IF Carrier Frequency ..................................... 45.75 MHz
Sound IF Carrier Frequency ...................................... 41.25 MHz
Color Sub-Carrier Frequency .................................... 42.17 MHz
AUDIO POWER
OUTPUT RATING ................................ 0.9W (at 10% distortion)

SHARP CORPORATION

SERVICE MANUAL

MODELS
CONTENTS
ELECTRICAL SPECIFICATIONS
SPEAKER
SIZE ...................................................................... 8 cm (Round)
VOICE COIL IMPEDANCE ............................. 32 ohm at 400 Hz
2
(89.8sq inch)
ANTENNA INPUT IMPEDANCE
VHF/UHF ..................................................... 75 ohm Unbalanced
TUNING RANGES
VHF-Channels ............................................................... 2 thru 13
UHF-Channels ............................................................ 14 thru 69
CATV Channels ........................................................... 1 thru 125
(Nominal)
Specifications are subject to change without
prior notice.
This document has been published to be used for after
sales service only.
The contents are subject to change without notice.
1
COLOR TELEVISION
Chassis No. SN-000
13N-M100/150
CN13M10
13N-M100/150
CN13M10
S10V213N-M100
Page
(EIA, Channel Plan U.S.A.)

Advertisement

Table of Contents
loading

Related Manuals for Sharp 13N-M100

Summary of Contents for Sharp 13N-M100

  • Page 1: Table Of Contents

    13N-M100/150 CN13M10 SERVICE MANUAL S10V213N-M100 COLOR TELEVISION Chassis No. SN-000 13N-M100/150 CN13M10 MODELS In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its original condition and only parts identical to those specified should be used.

  • Page 2: Important Service Safety Precaution

    13N-M100/150 CN13M10 IMPORTANT SERVICE SAFETY PRECAUTION Ë Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the servicing guidelines which follow: WARNING X-RADIATION AND HIGH VOLTAGE LIMITS 1. For continued safety, no modification of any circuit 1.

  • Page 3: Safety Notice

    13N-M100/150 CN13M10 IMPORTANT SERVICE SAFETY PRECAUTION (Continued) • Connect the resistor connection to all exposed metal BEFORE RETURNING THE RECEIVER parts having a return to the chassis (antenna, metal (Fire & Shock Hazard) cabinet, screw heads, knobs and control shafts, escutcheon and etc.) and measure the AC voltage...
  • Page 4 13N-M100/150 CN13M10 PRECAUTIONS A PRENDRE LORS DE LA REPARATION Ne peut effectuer la réparation qu' un technicien spécialisé qui s'est parfaitement accoutumé à toute vérification de sécurité et aux conseils suivants. AVERTISSEMENT LIMITES DES RADIATIONS X ET DE LA HAUTE TENSION 1.
  • Page 5 13N-M100/150 CN13M10 PRECAUTIONS A PRENDRE LORS DE LA REPARATION (Suite) • Toucher avec la sonde d'essai les pièces métalliques VERIFICATIONS CONTRE L'INCEN-DIE ET exposées qui présentent une voie de retour au LE CHOC ELECTRIQUE châssis (antenne, coffret métallique, tête des vis, Avant de rendre le récepteur à...

  • Page 6: Location Of User's Control

    13N-M100/150 CN13M10 LOCATION OF USER'S CONTROL Front Panel POWER – VOL + VIDEO IN AUDIO MENU VIDEO/AUDIO IN TERMINALS SENSOR AREA FOR REMOTE CONTROL POWER – VOL + MENU POWER Press → On. Press again → Off. CHANNEL UP/DOWN – MENU VOLUME UP/DOWN (') Selects next higher channel.

  • Page 7: Installation And Service Instructions

    13N-M100/150 CN13M10 INSTALLATION AND SERVICE INSTRUCTIONS Note: (1) When performing any adjustments to resistor controls and transformers use non-metallic screwdrivers or TV alignment tools. (2) Before performing adjustments, the TV set must be on at least 15 minutes. HIGH VOLTAGE CHECK CIRCUIT PROTECTION The receiver is protected by a 4.0A fuse (F701),...
  • Page 8 13N-M100/150 CN13M10 For adjustments of this model, the bus data is converted to various analog signals by the D/A converter circuit. Note: There are still a few analog adjustments in this series such as focus and master screen voltage. Follow the steps below whenever the service adjusment is required.
  • Page 9 R/B ANGLE 00-0F H BLK R 00-0F H BLK L 00-0F * Must be "B0" for 13N-M100/150, "A0" for CN13M10 Table - A Below are the ranges and initial values for each adjustment and in each categories. DATA SERVICE ADJUSTMENT CONTENTS...
  • Page 10 13N-M100/150 CN13M10 Holding down both the Vol-up/Ch-down buttons on the TV set at service mode for more than 2 seconds will automatically write the above initial values into IC2101. ADJUSTMENT PART REPLACED NOTES NECESSARY UNNECESSARY IC2001 Data is stored in IC2101.

  • Page 11: Service Adjustment

    13N-M100/150 CN13M10 Ë SERVICE ADJUSTMENT RF AGC Adjustment White Balance Adjustment. 1. Receive a good local channel. 1. Receive a good local channel. 2. Enter the service mode signal category and select 2. Select the service adjustment "S12" and set the data the service adjustment "S01".
  • Page 12 13N-M100/150 CN13M10 Vertical-Size, V-Linearity, V-S Correction Adjustment 1. Receive a good local channel. 2. Enter the service mode DEF category and select the adjustment "D02" for Vertical Size, "D05" for V- Linearity and "D06" for V-S Correction Adjustment. 3. Set in order "D05" for V-Linearity, "D06" for V-S Correction and set the data to get the best linearity.

  • Page 13: Chassis Layout

    13N-M100/150 CN13M10 CHASSIS LAYOUT PWB-B PWB-A...

  • Page 14: Block Diagram

    13N-M100/150 CN13M10 BLOCK DIAGRAM SYNC SEP. OUT...

  • Page 15: Description Of Schematic Diagram

    13N-M100/150 CN13M10 DESCRIPTION OF SCHEMATIC DIAGRAM WAVEFORM MEASUREMENT CONDITIONS: NOTES: 1. Photographs taken on a standard gated color bar 1. The unit of resistance "ohm" is omitted. (K=k Ω =1000 Ω , M=M Ω ) signal, the tint setting adjusted for proper color. The wave shapes at the red, green and blue cathodes of 2.
  • Page 16 13N-M100/150 CN13M10 SCHEMATIC DIAGRAM: MAIN Unit...
  • Page 17 13N-M100/150 CN13M10 SCHEMATIC DIAGRAM: CRT Unit...

  • Page 18: Printed Wiring Board Assemblies

    13N-M100/150 CN13M10 PRINTED WIRING BOARD ASSEMBLIES PWB-B: CRT Unit (Wiring Side) PWB-B: CRT Unit (Chip Parts Side)
  • Page 19 13N-M100/150 CN13M10 PWB-A: MAIN Unit (Wiring Side)
  • Page 20 13N-M100/150 CN13M10 PWB-A: MAIN Unit (Chip Parts Side)

  • Page 21: Replacement Parts List

    4. DESCRIPTION in USA: Contact your nearest SHARP Parts Distributor to order. in CANADA: Contact SHARP Electronics of Conada Limited For location of SHARP Parts Distributor, Please call Toll- Phone (416) 890-2100 Free; 1-800-BE-SHARP MARK: SPARE PARTS-DELIVERY SECTION MARQUE: SECTION LIVRAISON DES PIECES DE RECHANGE...
  • Page 22 13N-M100/150 CN13M10 Ref. No. Part No. Description Code Ref. No. Part No. Description Code PWB-A: DUNTKA055WEV6 (13N-M100/150) FILTERS PWB-A: DUNTKA055WEV8 (CN13M10) CF2040 RFiLC0121GEZZ J Ceramic Filter MAIN UNIT (Continued) SF201 RFiLC0441CEZZ J SAW Filter COILS Q752 VS2SC945AQ/-1 J 2SC945AQ L201 VP-XF1R2K0000 J Peaking 1.2µH...
  • Page 23 13N-M100/150 CN13M10 Ref. No. Part No. Description Code Ref. No. Part No. Description Code PWB-A: DUNTKA055WEV6 (13N-M100/150) RJ15 VRN-MD2AL000J 1/10W M-Film PWB-A: DUNTKA055WEV8 (CN13M10) RJ17 VRN-MD2AL000J 1/10W M-Film RJ18 VRN-MD2AL000J 1/10W M-Film MAIN UNIT (Continued) RJ20 VRN-MD2AL000J 1/10W M-Film RJ22...
  • Page 24 CN13M10 Ref. No. Part No. Description Code Ref. No. Part No. Description Code PWB-A: DUNTKA055WEV6 (13N-M100/150) R2048 VRD-RA2BE562J J 5.6k 1/8W Carbon PWB-A: DUNTKA055WEV8 (CN13M10) R2049 VRN-MD2AL333J J 33k 1/10W M-Film R2060 VRN-MD2AL221J J 220 1/10W M-Film MAIN UNIT (Continued) R2061 VRN-MD2AL562J J 5.6k 1/10W M-Film...

  • Page 25: Supplied Accessories

    (13N-M100, CN13M10) R883 VRD-RA2BE561J J 560 1/8W Carbon JBTN-0306PESB R Button (13N-M150) R884 VRN-MD2AL152J J 1.5k 1/10W M-Film GCABB2309PEKA R Rear Cabinet (13N-M100) R886 VRN-MD2AL431J J 430 1/10W M-Film GCABB2309PEKB R Rear Cabinet (13N-M150) R887 VRD-RA2BE470J J 47 1/8W Carbon...

  • Page 26: Packing Of The Set

    13N-M100/150 CN13M10 PACKING OF THE SET Polyethylene Bag Operation Manual Batteries Wrapping Paper Buffer Material FRONT Packing Case Use tapes to fix the packing case. REAR MARK : Not Replacement Items.
  • Page 27 13N-M100/150 CN13M10 COPYRIGHT © 2000 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
