CHAPTER 1
Chapter 1
INTRODUCTION
The MS-6334 Micro-ATX S5 mainboard is a high-performance
computer mainboard based on Intel
to support the Intel
ness/personal desktop markets.
The Intel
ler that supports a 32-bit 133MHz SDRAM array for enhanced integrated 3D
graphics performance. It is a highly-flexible chipset which is designed to
extend the basic graphics/multimedia PC platform up to the mainstream
performance desktop platform.
The Intel
data bus interfaces within a single device. It takes advantage of the
pipelined addressing capability of the processor to improve the overall
system performance. In addition, the chipset also integrates a system
memory controller that supports a 64-bit 100/133 MHz SDRAM array.
The Intel
multifunctional I/O Controller Hub that provides the interface to the PCI Bus
and integrates many of the functions needed in today's PC platforms. It
communicates with the host controller over a dedicated hub interface and
provides added flexibility in designing cost-effective system solutions.
®
®
®
Pentium
III (FC-PGA) processor for high-end busi-
®
815 chipset integrates a Display Cache SDRAM control-
®
815 chipset implements the host address, control, and
®
82801AA (ICH) chipset is a highly integrated
815 chipset. The MS-6334 is optimized
1-1
INTRODUCTION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS-6334 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MSI MS-6334

  • Page 1 CHAPTER 1 INTRODUCTION Chapter 1 INTRODUCTION The MS-6334 Micro-ATX S5 mainboard is a high-performance ® computer mainboard based on Intel 815 chipset. The MS-6334 is optimized ® ® to support the Intel Pentium III (FC-PGA) processor for high-end busi- ness/personal desktop markets.
  • Page 2: Mainboard Features

    CHAPTER 1 INTRODUCTION 1.1 Mainboard Features l Support Socket 370 for Intel ® Celeron Pentium III(FC-PGA) processor l Support 500MHz, 550MHz, 600MHz, 633MHz, 667MHz and up to 9XX Chipset l Intel ® 815 chipset. (544 BGA) - AGP 4x/2x/1x universal slot - Support 66/100/133MHz FSB l Intel ®...
  • Page 3 CHAPTER 1 INTRODUCTION On-Board Peripherals l On-Board Peripherals include: - 1 floppy port supports 2 FDD with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes. - 2 serial port (COMA + COMB--header) - 1 parallel port supports SPP/EPP/ECP mode - 4 USB ports (Rear * 2/Front * 2) - 1 VGA port - 1 Line-In/Line-Out/Mic-In/Game Port Video...
  • Page 4 CHAPTER 1 INTRODUCTION BIOS l The mainboard BIOS provides “Plug & Play” BIOS which detects the peripheral devices and expansion cards of the board automatically. l The mainboard provides a Desktop Management Interface(DMI) function which records your mainboard specifications. Dimension l Micro-ATX Form Factor Mounting l 6 mounting holes.
  • Page 5: Mainboard Layout

    Chipset Winbond Top: Midi/ W83627HF-AW Game Port JMDM1 Bottom: JWOL1 Line-Out Line-In COM B AGP Slot JIR1 JUSB1 PCI SLOT 1 Intel PCI SLOT 2 FW82801AA JBAT1 Creative SYSFAN CT5880 PCI SLOT 3 BIOS JGS1 JGL1 MS-6334 Micro-ATX S5 Mainboard...
  • Page 6: Hardware Installation

    Chapter 2 HARDWARE INSTALLATION 2.1 Central Processing Unit: CPU ® ® The mainboard operates with Intel Celeron /Pentium III (FC-PGA) processor. The mainboard uses a CPU socket called Socket 370 for easy CPU installation. The CPU should always have a Heat Sink and a cooling fan attached to prevent overheating.
  • Page 7: Cpu Core Speed Derivation Procedure

    2.1-2 CPU Core Speed Derivation Procedure The mainboard CPU Bus Frequency can be set through BIOS setup. CPU Clock = 100MHz Core/Bus ratio then CPU core speed = Host Clock x Core/Bus ratio = 700MHz...
  • Page 8: Fan Power Connectors: Cpufan & Sysfan

    2.1-3 Fan Power Connectors: CPUFAN & SYSFAN These connector support system cooling fan with + 12V. It supports three pin head connector. When connecting the wire to the connector, always take note that the red wire is the positive and should be connected to the +12V, the black wire is Ground and should be connected to GND.
  • Page 9 A battery must be used to retain the mainboard configuration in CMOS RAM. Short 1-2 pins of JBAT1 to store the CMOS data. JBAT1 Clear Data Keep Data Note: You can clear CMOS by shorting 2-3 pin, while the system is off. Then, return to 1-2 pin position.
  • Page 10: Memory Bank Configuration

    2.3-1 Memory Bank Configuration The mainboard supports a maximum memory size 512MB: It provides three 168-pin unbuffered DIMMs (Double In-Line Memory Module) sockets. It supports 8 MB to 128 Mbytes DIMM memory module.
  • Page 11: Memory Installation Procedures

    2.3-2 Memory Installation Procedures A. How to install a DIMM Module Single Sided DIMM Double Sided DIMM 1. The DIMM slot has 2 Notch Keys “VOLT and DRAM”, so the DIMM memory module can only fit in one direction. 2. Insert the DIMM memory module vertically into the DIMM slot. Then push it in.
  • Page 12: Memory Population Rules

    2.3-3 Memory Population Rules 1. Supports only SDRAM DIMM. 2. To operate properly, at least one 168-pin DIMM module must be in- stalled. 3. This mainboard supports Table Free memory, so memory can be installed on DIMM1, DIMM2, DIMM3 in any order. 4.
  • Page 13 2.4 Case Connector: J6 The Keylock, Power Switch, Reset Switch, Power LED, Speaker, and HDD LED are all connected to the JFP1 connector block. Reset Switch Power Switch Single Dual Speaker Color Color Power LED Buzzer (short pin) Keylock (Reserved)
  • Page 14 2.4-1 Power Switch Connect to a 2-pin push button switch. 2.4-2 Reset Switch Reset switch is used to reboot the system rather than turning the power ON/ OFF. Avoid rebooting while the HDD LED is lit. You can connect the Reset switch from the system case to this pin.
  • Page 15: Floppy Disk Connector: Fdd

    2.5 Floppy Disk Connector: FDD The mainboard also provides a standard floppy disk connector FDD that supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk types. This connector supports the provided floppy drive ribbon cables. 2-10...
  • Page 16: Hard Disk Connectors: Ide1 & Ide2

    2.6 Hard Disk Connectors: IDE1 & IDE2 The mainboard has a 32-bit Enhanced PCI IDE and Ultra DMA/66 Controller that provides PIO mode 0~4, Bus Master, and Ultra DMA/33/66 function. It has two HDD connectors IDE1 (primary) and IDE2 (secondary). You can connect up to four hard disk drives, CD-ROM, 120MB Floppy and other devices to IDE1 and IDE2.
  • Page 17: Atx 20-Pin Power Connector: Jwr1

    2.7-1 ATX 20-pin Power Connector: JWR1 This connector supports the power button on-board. Using the ATX power supply, functions such as Modem Ring Wake-Up and Soft Power Off are supported by this mainboard. This power connector supports instant power on function which means that system will boot up instantly when the power connector is inserted on the board.
  • Page 18: Irda Infrared Module Connector: Jir1

    2.8 IrDA Infrared Module Connector: JIR1 The mainboard provides one infrared (JIR1) connector for IR modules. This connector is for optional wireless transmitting and receiving infrared module. You must configure the setting through the BIOS setup to use the IR function.
  • Page 19 The mainboard has a 9-pin male DIN connector for serial port COM A. This port is a 16550A high speed communication port that send/receive 16 bytes FIFOs. You can attach a mouse or a modem cable directly into this connec- tor.
  • Page 20 The mainboard provides a 25 pin female centronic connector for LPT. A parallel port is a standard printer port that also supports Enhanced Parallel Port(EPP) and Extended capabilities Parallel Port(ECP). See connector and pin definition below: Parallel Port (25-pin Female) LPT 1 PIN DEFINITION SIGNAL...
  • Page 21: Keyboard Connector: Jkbms1

    ® The mainboard provides a standard PS/2 mouse mini DIN connector for ® ® attaching a PS/2 mouse. You can plug a PS/2 mouse directly into this connector. The connector location and pin definition are shown below: Pin5 Mouse Clock Pin6 Pin3 Pin4...
  • Page 22: Joystick/Midi Connectors

    2.13 Joystick/Midi Connectors You can connect joystick or game pad to this connector. Joystick/MIDI 2.14 Audio Port Connectors Line Out is a connector for Speakers or Headphones. Line In is used for external CD player, Tape player, or other audio devices. Mic is a connector for the microphones.
  • Page 23: Usb Connectors

    2.15 USB Connectors The mainboard provides a UHCI(Universal Host Controller Interface) Universal Serial Bus root for attaching USB devices like: keyboard, mouse and other USB devices. You can plug the USB device directly to this connector. USB Port 1 1 2 3 4 USB Port 2 SIGNAL -Data...
  • Page 24: Vga Db 15 Pin Connector

    2.16 VGA DB 15 Pin Connector The mainboard provides a DB 15-pin connector to connect to a VGA monitor. Analog Video Display Connector(DB15-S) Signal Description Green Blue Not used Ground Ground Ground Ground Not used Ground Not used Horizontal Sync Vertical Sync 2-19...
  • Page 25 Attach a power saving switch to JGS1. When the switch is pressed, the system immediately goes into suspend mode. Press any key and the system wakes up. JGS1 2-20...
  • Page 26 JGL1 can be connected with an LED. There are two types of LED that you can use: 3-pin LED or 2-pin LED(ACPI request). When the 2-pin LED is connected to JGL1, the light will turn green, when system is On. During sleep mode, the 2-pin LED will change color from Green to Orange.
  • Page 27 The JWOL1 connector is for use with LAN add-on cards that supports Wake Up on LAN function. To use this function, you need to set the “Wake-Up on LAN” to enable at the BIOS Power Management Setup. JWOL1 SIGNAL 5VSB MP_WAKEUP Note: LAN wake-up signal is active “high”.
  • Page 28 The JMDM1 connector is for used with Modem add-on card that supports the Modem Wake Up function. To use this function, you need to set the “Power On by Ring” to enable at the BIOS Power Management Setup. JMDM1 SIGNAL MDM_WAKEUP 5VSB Note: Modem wake-up signal is active “low”.
  • Page 29 2.21 Modem-In: MDM_IN The connector is for Modem with internal voice connector. Mono_Out Phone_In MDM_IN Mono_Out is connected to the Modem Speaker Out connector. Phone_In is connected to the Modem Microphone In connector. 2-24...
  • Page 30 This connector is used for DVD add-on card with Line In connector. AUX_IN 2-25...
  • Page 31 This connector is for CD-ROM audio connector. CD_IN 2-26...
  • Page 32 This jumper is used to locked/unlocked BIOS Flash. This Jumper should be unlock when flashing/programming the BIOS. BIOS Flash BIOS Flash Locked Unlocked 2-27...
  • Page 33 The Communication Network Riser specification is an open industry- standard specification that defines a hardware scalable Original Equipment Manufacturer (OEM) mainboard riser board and interface, which supports both audio and modem only. 2-28...
  • Page 34 The mainboard provides a front Universal Serial Bus connector. This is an optional USB connector for Front Panel. JUSB1 Description Description USB3- USBD3+ USBD2+ USB2- 2-29...
  • Page 35: Award Bios Setup

    ® Chapter 3 AWARD BIOS SETUP ® Award BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed RAM (CMOS RAM), so that it retains the Setup information when the power is turned off.
  • Page 36: Status Page Setup Menu/Option Page Setup Menu

    ® Power on the computer and press <Del> immediately to allow you to enter Setup. The other way to enter Setup is to power on the computer. When the below message appears briefly at the bottom of the screen during the POST (Power On Self Test), press <Del>...
  • Page 37: Standard Cmos Features

    ® ® Once you enter Award BIOS CMOS Setup Utility, the Main Menu (Figure 1) will appear on the screen. The Main Menu allows you to select from twelve setup functions and two exit choices. Use arrow keys to select among the items and press <Enter>...
  • Page 38 ® Integrated Peripherals Use this menu to specify your settings for integrated peripherals. Power Management Setup Use this menu to specify your settings for power management. PnP/PCI Configurations This entry appears if your system supports PnP/PCI. PC Health Status (Optional) This entry shows your PC health status.
  • Page 39 ® The items in Standard CMOS Setup Menu are divided into 10 catego- ries. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item.
  • Page 40 ® Date The date format is <day><month> <date> <year>. Day of the week, from Sun to Sat, determined by BIOS. Read-only. month The month from Jan. through Dec. date The date from 1 to 31 can be keyed by numeric function keys.
  • Page 41 ® If the controller of HDD interface is SCSI, the selection shall be “None”. If the controller of HDD interface is CD-ROM, the selection shall be “None”. Access Mode The settings are Auto, Normal, Large,LBA. Cylinder number of cylinders Head number of heads Precomp write precomp...
  • Page 42: Anti-Virus Protection

    ® CMOS Setup Utility - Copyright(C) 1984-2000 Award Software Advanced BIOS Features Anti-Virus Protection Disabled CPU Internal Cache Enabled Item Help External Cache Enabled CPU L2 Cache ECC Checking Enabled Processor Number Feature Enabled Menu Level > Quick Power On Self Test Disabled First Boot Device Floppy...
  • Page 43 ® CPU Internal Cache The default value is Enabled. Enabled (default) Enable cache Disabled Disable cache Note: The internal cache is built in the processor. External Cache Choose Enabled or Disabled. This option enables the level 2 cache memory. CPU L2 Cache ECC Checking Choose Enabled or Disabled.
  • Page 44 ® Swap Floppy Drive Switches the floppy disk drives between being designated as A and B. Default is Disabled. Boot Up Floppy Seek During POST, BIOS will determine if the floppy disk drive installed is 40 or 80 tracks. 360K type is 40 tracks while 760K, 1.2M and 1.44M are all 80 tracks.
  • Page 45: Security Option

    ® Security Option This category allows you to limit access to the system and Setup, or just to Setup. System The system will not boot and access to Setup will be denied if the correct password is not entered at the prompt. Setup(default) The system will boot, but access to Setup will be denied if the correct password is not entered...
  • Page 46 ® The Advanced Chipset Features Setup option is used to change the values of the chipset registers. These registers control most of the system options in the computer. Choose the “ADVANCED CHIPSET FEATURES” from the Main Menu and the following screen will appear. CMOS Setup Utility - Copyright(C) 1984-2000 Award Software Advanced Chipset Features SDRAM CAS Latency Time...
  • Page 47 ® SDRAM CAS Latency Time When synchronous DRAM is installed, the number of clock cycles of CAS latency depends on the DRAM timing. The settings are: 2 and 3. SDRAM Cycle Time Tras/Trc Select the number of SCLKs for an access cycle. The settings are: 5/7 and 6/8.
  • Page 48 ® Video BIOS Cacheable Select Enabled allows caching of the video BIOS , resulting in better system performance. However, if any program writes to this memory area, a system error may result. The settings are: Enabled and Disabled. Memory Hole At 15M-16M You can reserve this area of system memory for ISA adapter ROM.
  • Page 49: Agp Graphics Aperture Size

    ® AGP Graphics Aperture Size This option determines the effective size of the graphics aperture used in the particular PAC configuration. The AGP aperture is memory- mapped, while graphics data structure can reside in a graphics aperture. The aperture range should be programmed as not cacheable in the processor cache, accesses with the aperture range are forwaded to the main memory, then PAC will translate the original issued address via a translation table that is maintained on the main memory.
  • Page 50: On-Chip Primary/Secondary Pci Ide

    ® CMOS Setup Utility - Copyright(C) 1984-2000 Award Software Integrated Peripherals On-Chip Primary PCI IDE Enabled On-Chip Secondary PCI IDE Enabled Item Help IDE Primary Master PIO Auto IDE Primary Slave PIO Auto IDE Secondary Master PIO Auto Menu Level >...
  • Page 51 ® IDE Primary/Secondary Master/Slave PIO The four IDE PIO (Programmed Input/Output) fields let you set a PIO mode (0-4) for each of the four IDE devices that the onboard IDE interface supports. Modes 0 through 4 provide successively increased performance. In Auto mode, the system automatically determines the best mode for each device.
  • Page 52 ® IDE HDD Block Mode Block mode is also called block transfer, multiple commands, or multiple sector read/write. If your IDE hard drive supports block mode (most new drives do), select Enabled for automatic detection of the optimal number of block read/writes per sector the drive can support. The settings are: Enabled, Disabled.
  • Page 53: Onboard Parallel Mode

    ® Onboard Parallel Port Disabled There is a built-in parallel port on the (3BCH/IRQ7)/ on-board Super I/O chipset that pro- (278H/IRQ5)/ vides Standard, ECP, and EPP features. (378H/IRQ7) It has the following options: Disable 3BCH/IRQ7 Line Printer port 0 278H/IRQ5 Line Printer port 2 378H/IRQ7 Line Printer port 1...
  • Page 54: Power Status Led

    ® channels 3 or 1. The onboard parallel port is EPP Spec. compliant, so after the user chooses the onboard parallel port with the EPP function, the following message will be displayed on the screen: “EPP Mode Select.” At this time either EPP 1.7 spec.
  • Page 55: Acpi Function

    ® The Power Management Setup allows you to configure you system to most effectively save energy while operating in a manner consistent with your own style of computer use. CMOS Setup Utility - Copyright(C) 1984-2000 Award Software Power Management Setup ACPI Function Enabled ACPI Suspend Type...
  • Page 56: Acpi Suspend Type

    ® ACPI Suspend Type This item will set which ACPI suspend type will be used. S1 (POS) The S1 sleeping state is low wake-up latency sleeping state. In this state, no system context is lost(CPU or chip set) and hardware maintains all system context.
  • Page 57 ® Video Off In Suspend This determines the manner in which the monitor is blanked. The settings are: Yes and No. Suspend Type Select the Suspend Type. The settings are: PWRON Suspend, Stop Grant. Modem Use IRQ This determines the IRQ in which the MODEM can use. The settings are: 3, 4, 5, 7, 9, 10, 11, NA.
  • Page 58 ® Power On by Ring During Disabled, the system will ignore any incoming call from the modem. During Enabled, the system will boot up if there’s an incoming call from the modem. Wake Up on LAN To use this function, you need a LAN add-on card which support power on functions.
  • Page 59 ® Reload Global Timer events are I/O events whose occurrence can prevent the system from entering a power saving mode or can awaken the system from such a mode. In effect, the system remains alert for anything which occurs to a device which is configured as Enabled , even when the system is in a power down mode.
  • Page 60: Reset Configuration Data

    ® This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its own special components. This section covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings.
  • Page 61 ® Resource Controlled By The Award Plug and Play BIOS has the capacity to automatically configure all of the boot and Plug and Play compatible devices. However, this capability means absolutely nothing unless you are using a Plug and ® Play operating system such as Windows 95/98.
  • Page 62: Cpu Warning Temperature

    ® This section shows the Status of you CPU, Fan, Warning for overall system status. This is only available if there is Hardware Monitor onboard. CMOS Setup Utility - Copyright(C) 1984-2000 Award Software PC Health Status CPU Warning Temperature Disabled Current System Temp C/102 Item Help...
  • Page 63: Shutdown Temperature

    ® Current System Temp/Current CPU Temperature/Current System Fan (optional)/CPU Fan/Vcore/VTT/3.3V/+5V/+12V/- 12V/-5V/VBAT(V)/5VSB(V) This will show the CPU/FAN/System voltage chart and FAN Speed. Shutdown Temperature This option is for setting the Shutdown temperature level for the processor. When the processor reach the temperature you set, this will shutdown the system.
  • Page 64: Auto Detect Dimm/Pci Clk

    ® This section is for setting CPU Frequency/Voltage Control. CMOS Setup Utility - Copyright(C) 1984-2000 Award Software Frequency/Voltage Control Auto Detect DIMM/PCI Clk Enabled Spread Spectrum Enabled Item Help CPU Clock Ratio Auto Menu Level > ↑ ↓ → ← Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5:Previous Values F6:Fail-safe defaults F7:Optimized Defaults Auto Detect DIMM/PCI Clk This item allows you to enable/disable auto detect DIMM/PCI Clock.
  • Page 65 ® Load Fail-Safe Defaults When you press <Enter> on this item, you get a confirmation dialog box with a message similar to: Load Fail-Safe Defaults (Y/N) ? N Pressing ‘Y’ loads the BIOS default values for the most stable, minimal- performance system operations.
  • Page 66 ® You can set either supervisor or user password, or both of them. The differences are: Supervisor password : Can enter and change the options of the setup menus. User password : Can only enter but do not have the right to change the options of the setup menus.
  • Page 67 ® Additionally, when a password is enabled, you can also require the BIOS to request a password every time your system is rebooted. This would prevent unauthorized use of your computer. You determine when the password is required within the BIOS Features Setup Menu and its Security option.
  • Page 68 ® Chapter 4 ® BIOS USER’S GUIDE The system configuration information and chipset register information is stored in the CMOS RAM. This information is retained by a battery when the power is off. Enter the BIOS setup (if needed) to modify this information. The following pages will describe how to enter BIOS setup, and all about options.
  • Page 69: Enter Bios Setup

    ® 4.1 Enter BIOS Setup ® Enter the AMI setup Program’s Main Menu as follows: 1. Turn on or reboot the system. The following screen appears with a series of diagnostic check. AMIBIOS (C) 1999 American Megatrends Inc. AGIOMS VXXX XXXXXX Hit <DEL>...
  • Page 70 ® AMIBIOS HIFLEX SETUP UTILITIES - VERSION 1.22 (C) 1999 American Megatrends, Inc. All Rights Reserved Standard CMOS Setup Advanced CMOS Setup Advanced Chipset Setup Power Management Setup PCI/Plug and Play Setup Peripheral Setup Hardware Monitor Setup Auto-Detect Hard Disks Change User Password Change Supervisor Password Change Language Setting...
  • Page 71: Standard Cmos Setup

    ® 4.2 Standard CMOS Setup 1. Press <ENTER> on “Standard CMOS Setup” of the main menu screen . AMIBIOS SETUP - STANDARD CMOS SETUP (C)1999 American Megatrends,Inc.All Rights Reserved Date (mm/dd/yyyy): Fri March 20, 1999 Time (hh/mm/ss): 17:09:25 Floppy Drive A: 1.44 MB 3 1/2 Floppy Drive B: Not Installed...
  • Page 72: Advanced Cmos Setup

    ® 4.3 Advanced CMOS Setup 1. Press <ENTER> on “Advanced CMOS Setup” of the main menu AMIBIOS SETUP - ADVANCED CMOS SETUP (C) 1999 American Megatrends, Inc. All Rights Reserved Quick Boot Enabled Available Options: Ist Boot Device Floppy Disabled 2nd Boot Device IDE 0 Enabled...
  • Page 73 ® Description of the item on screen follows: Quick Boot ® Set this option to Enabled to permit AMI BIOS to boot within 5 seconds. This option replaces the old ABOVE 1 MB Memory Test option. The Optimal default setting is Enabled. The Fail-Safe default setting is Disabled.
  • Page 74 ® Boot up Num Lock ® When this option is set to Off, AMI BIOS turns off the Num Lock key when the system is powered on. The end user can then use the arrow keys on both the numeric keypad and the keyboard. The settings are On or Off.
  • Page 75 ® CPU Serial Number This option is for Pentium III processor. During Enabled, this will check the CPU Serial number. Disabled this option if you don’t want the system to know the Serial number. Cache Bus ECC ® This option is for Pentium II processor.
  • Page 76: Advanced Chipset Setup

    ® 4.4 Advanced Chipset Setup 1. Press <ENTER> on “Advanced Chipset Setup” of the main menu screen. AMIBIOS SETUP - ADVANCED CHIPSET SETUP (C) 1999 American Megatrends, Inc. All Rights Reserved Available Options: USB Function Enabled USB Keyboard Legacy Support Disabled Disabled Enabled...
  • Page 77 ® Description of the item on screen follows: USB Function Set this option to Enabled or Disabled the on-chip USB controller. The Optional and Fail-Safe default settings are Disabled. USB Keyboard Legacy Support Set this option to Enabled or Disabled USB keyboard. The Optional and Fail-Safe default settings are Disabled.
  • Page 78 ® SDRAM RAS Precharge This option defines the RAS# precharge requirements for the SDRAM memory type in 66MHz clocks. Under 66MHz CPU bus, set this option to either 2 or 3 but for 100MHz CPU, it is recommended that this be set to 3.
  • Page 79: Power Management Setup

    ® 4.5 Power Management Setup 1. Press <ENTER> on “Power Management Setup” of the main menu screen. AMIBIOS SETUP - POWER MANAGEMENT SETUP (C) 1999 American Megatrends, Inc. All Rights Reserved Available Options: ACPI Standby State Disabled Power Management/APM Enabled Enabled Green PC LED Status Blinking...
  • Page 80 ® Description of the item on screen follows: ACPI Standby State This option sets the ACPI Power Management Standby State. Power Management/APM Set this option to Enabled to enable the chipset’s power management features and APM(Advanced Power Management). The settings are Enabled, Inst-On(instant-on) or Disabled.
  • Page 81 ® Standby Time Out (Minute) This option specifies the length of a period of system inactivity while in Standby state. When this length of time expires, the computer enters Suspend power state. The settings are Disabled, 1 min, 2 min, 3 min, 4 min, 5 min, 6 min, 7 min, 8 min, 9 min, 10 min, 11 min, 12 min, 13 min, 14 min or 15 min.
  • Page 82: Restore On Ac Power Loss

    ® Restore on AC/Power Loss The settings are power on or last status. During power on, after every AC power loss, the system will be turned on. During last status, after every AC power loss, whatever the system status, it will be the same when the AC power returns.
  • Page 83 ® RTC Alarm Resume From Soft-Off This function is for setting the Date, Hour, Minute, and Second for your computer to boot up. During Disabled, you cannot use this function. During Enabled, Choose the Date, Hour, Minute, and Second: RTC Alarm Date Choose which day the system will boot up.
  • Page 84: Pci/Plug And Play Setup

    ® 4.6 PCI/Plug and Play Setup 1. Press <ENTER> on “PCI/Plug and Play Setup” of the main menu screen. AMIBIOS SETUP - PCI/PLUG AND PLAY SETUP (C) 1999 American Megatrends, Inc. All Rights Reserved Available Options: Plug and Play Aware O/S Clear NVRAM Enabled PCI Latency Timer (PCI Clocks)
  • Page 85: Primary Graphics Adapter

    ® Description of the item on screen follows: Plug and Play Aware O/S Set this option to Yes if the operating system in this computer is aware of and follows the Plug and Play specification. The settings are Yes or No.
  • Page 86: Dma Channel

    ® DMA Channel 0/1/3/5/6/7 These options specify the bus that the specified DMA channel is used. These options allow you to reserve DMAs for legacy ISA adapter cards. ® These options determine if AMI BIOS should remove a DMA from the available DMAs passed to devices that are configurable by the system BIOS.
  • Page 87: Peripheral Setup

    ® 4.7 Peripheral Setup 1. Press <ENTER> on “Peripheral Setup” of the main menu screen. AMIBIOS SETUP - PERIPHERAL SETUP (C) 1999 American Megatrends, Inc. All Rights Reserved Available Options: CLKGEN Spread Spectrum Enabled Auto CPU Ratio Selection 3.0x Disabled CPU Host Clock (Mhz) Auto Enabled...
  • Page 88 ® Description of the item on screen follows: CLKGEN Spread Spectrum This item allows you to set the CPU clock generator spread spectrum. CPU Ratio Selection This item allows you to set the CPU ratio. CPU Host Clock (MHz) This item allows you to set the CPU host clock. Onboard Sound This item allows you to enable/disable the onboard Aureal audio chipset.
  • Page 89: Onboard Fdc

    ® Onboard FDC Choose Auto, for the BIOS to automatically detect the device If the ISA add-on card has Onboard FDC to be set at Disabled FDC exist Enabled none FDC exist Choose Enabled, Enabling onboard FDC. Choose Disabled, Disabling onboard FDC. The Optimal and Fail-Safe default settings are Auto.
  • Page 90 ® Serial PortB Mode Choosing Normal will set the Serial Port B for normal use, not for IR device. Choosing IrDA or Ask IR will set it for use with IR device using these protocols. IR Duplex Mode Can be set as either Half or Full duplex. IR Pin Select Set this option to IRRX/IRTX when using an internal IR device which is connected to IR1 connector.
  • Page 91 ® Parallel Port Mode This option allows user to choose the operating mode of the onbaord parallel port. The settings are Normal, SPP/EPP or ECP mode. EPP Version This option is for setting which EPP version will be used. The settings are 1.7 and 1.9.
  • Page 92 ® 4.8 Hardware Monitor Setup (optional) The Hardware Monitor Setup is used to set the CPU speed and monitor the current CPU Temperature, CPU Fan speed, Chassis Fan Speed, Power fan speed, Vcore, etc. This is only available if there is Hardware Monitor onboard.
  • Page 93: Integrated Graphics Controller

    CHAPTER 5 VGA DRIVER Chapter 5 ® INTEL 815 INTEGRATED GRAPHICS CONTROLLER 5.1 Overview ® The Intel 815 Chipset extends Intel’s graphics capabilities into the value PC segment by incorporating 2D and 3D capabilities with the memory controller, to provide the industry with complete graphics offerings for every comput- ing segment.
  • Page 94: System Requirements

    CHAPTER 5 VGA DRIVER 5.1.2 System Requirements This section describes system requirements for the VGA Driver installa- tion and Usage. ® ® Computer Intel Celeron / Pentium III (FC-PGA) processor or higher Monitor VGA Support, mimimum 640x480 resolu- tion ® Operating system DOS 5.0 or higher, Windows 95/98,...
  • Page 95 CHAPTER 5 VGA DRIVER 5.2 Intel 815 VGA Driver Setup & Usage ® Procedures Insert the CD-title into your CD-ROM drive. This CD will auto-run. This will display installation for VGA driver and sound driver, Intel 815 INF Update (only for Windows 95/98) and Trend PC-cillin 98. Just click the button for automatic installation for VGA driver.
  • Page 96 CHAPTER 5 VGA DRIVER ® 5.2.2 Windows NT 4.0 ® You need to install Windows NT “Service Pack 3” or higher, ® before you install Windows NT driver. 5.2.2-1 Display Driver Installation Procedure: Step 1: Click Start menu and select Control Panel from Settings group.
  • Page 97 CHAPTER 5 VGA DRIVER 5.2.2-2 Changing resolution, color depth, and refresh rate: Step 1: Click Start menu and select Control Panel from Settings group. Step 2: Select Display icon. Step 3: Select Settings. Step 4: Select Color Palette to change between 256 color, 65536 colors, and 16777216 colors.
  • Page 98 Chapter 6 CREATIVE AUDIO DRIVER (OPTIONAL) ® The Creative CT5880 digital controller provides the next generation of audio performance to the PC market 6.1.1 Features SoundScape WaveTable Synthesizer. Full DOS Game Compatibility. PCI Bus Master for fast DMA. Fully Compliant with PC97 Power Management Specification. 6.1.2 System Requirements This section describes system requirements for the Audio Driver installation and Usage.
  • Page 99: Audio Driver Setup

    6.1.3 Audio Driver Setup Insert the CD-title into your CD-ROM drive. This CD will auto-run. This will display installation for Microsoft DirectX7.0a, Creative ® Audio PCI Sound Drivers and Intel chipset. Please make sure that ® you have finished the installation for Intel Chipset Drivers before proceeding to install the Audio Driver.
  • Page 100: Windows Nt

    ® 6.1.3-2 Windows NT 4.0 Audio Driver Installation Procedure: Step 1: Click Start menu and select Control Panel from Settings group. Step 2: Select Multimedia icon. Step 3: Click on the Devices tab. Step 4: Click Add. Step 5: Double click on Unlisted or Updated Driver in the list. Step 6: Insert the CD-ROM Disk into the CD-ROM Drive.
  • Page 101 Chapter 7 SIGMATEL AUDIO DRIVER (OPTIONAL) Sigmatel 9721 is a general-purpose 18-bit stereo, full duplex, audio codec that conforms to the analog component specification of AC’97. 7.1.1 Features High performance 3D technology Energy saving power down modes 18-bit full duplex stereo ADC, DACs AC-Link protocol compliance Multiple power supply options Pin compatible with the STAC9704/07...
  • Page 102 7.1.2 System Requirements This section describes system requirements for the Audio Driver installation and Usage. ® ® Computer Intel Pentium II/III or Coppermine processor or higher ® Operating system DOS 5.0 or higher, Windows ® ® Windows 98, Windows NT 3.51 or ®...
  • Page 103 Audio Driver Installation Procedure: Step 1: Insert the provided CD_ROM disk into the CD-ROM drive. Step 2: Look for the CD_ROM drive, double click on the CD_ROM icon. This will show the setup screen. Step 3: Click on “SigmaTel Sound Drivers” icon. Step 4: This will copy the audio drivers into the hard drive.
