HEAVY DUTY WORK STATION
46725
ASSEMBLY AND OPERATING INSTRUCTIONS
Due to continuing improvements, actual product may differ slightly from the product described herein.
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at http://www.harborfreight.com
®
Copyright © 2001 by Harbor Freight Tools
. All rights reserved. No portion of
this manual or any artwork contained herein may be reproduced in any shape
or form without the express written consent of Harbor Freight Tools.
For technical questions and replacement parts, please call 1-800-444-3353

Advertisement

loading

Related Manuals for Harbor Freight Tools Central Machinery 46725

Summary of Contents for Harbor Freight Tools Central Machinery 46725

  • Page 1 . All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. For technical questions and replacement parts, please call 1-800-444-3353...

  • Page 2: Specifications

    Specifications ITEM DESCRIPTION Tabletop Dimensions 20-1/8 (W) x 17-3/4 (D) x 3/4 (T) inches Tabletop Material 3/4 inch pressboard Frame Material Formed and stamped sheet steel 23-3/4 inches (minimum) Table Height 30-1/4 inches (maximum) Top Shelf Dimensions 15-5/16 (W) x 13-1/8 (D) x 1/8 (T) inches Bottom Shelf Dimensions 19-1/2 (W) x 17-3/16 (D) x 1/8 (T) inches Weight 15.55 lbs...
  • Page 3 Use eye and ear protection. Always wear ANSI approved impact safety goggles. Wear a full face shield if you are producing metal filings or wood chips. Wear an ANSI approved dust mask or respirator when working around metal, wood, and chemical dusts and mists.
  • Page 4 When unpacking, check to make sure that all the parts are included. Refer to the Parts List and Assembly Drawing at the end of this manual. If any parts are missing or broken, please call Harbor Freight Tools at the number on the cover of this manual as soon as possible. Assembly Refer to the Assembly Drawing on page 7 during this procedure.

  • Page 5: Maintenance

    Assembly the other two Legs with the Short Middle Frame (5) and the Short Lower Frame (7). Use Screws (12) through the Height Adjuster, Screws (13) through Short Lower Frame (7), and Washers (15). Tighten securely. Slide the Middle Wood Plate (2) into the Long Middle Frames (4) Slide the Lower Wood Plate (3) into the Long Lower Frames (6).

  • Page 6: Parts List

    Parts List Item # Description Wood Table Top Wood Plate, Middle Wood Plate, Lower Frame, Long Middle Frame, Short Middle Frame, Long Lower Frame, Short Lower Height Adjuster Connector Bracket PVC Feet Screw, 5x12 mm Screw, 5x10 mm Washer, 5 mm Screw, 8x5/8"...

  • Page 7: Assembly Drawing

    Assembly Drawing SKU 46725 Page 7...
