Table of Mainboard Components
Label Component
1394A_J2 IEEE 1394A header
AGP1 Accelerated Graphics Port (supports 1.5V AGP card only)
ATX1 Standard 20-pin ATX power connector
AUDIO1 Front audio connector
AUXIN1 Extra line-in connector
BAT1 Three volt realtime clock battery
CASFAN1 Case fan connector
CDIN1 CD-in connector
CHS1 Chassis Intrusion Detect
CNR1 Communications Networking Riser slot
CPU SOCKET Socket A for AMD Athlon/Duron CPUs
CPUFAN1 Cooling fan for CPU
DIM1 ~ DIM3 Three 184-pin DDR SDRAM
FDD1 Floppy disk drive connector
IDE 1 Primary IDE channel
IDE 2 Secondary IDE channel
IR1 Infrared port
JP1 Clear CMOS jumper
JP8 ~ JP9 CPU Frequency jumper
1
LED1 Memory module LED
PANEL1 Connector for case front panel switches and LED indicators
PCI1 ~ PCI5 Five 32-bit add-on card slots
SJ1 Single color LED header
SPEAKER1 Speaker connector
USB3 Connector for front panel USB ports
This concludes Chapter 1. The next chapter explains how to install the
mainboard.
1
The red indicator LED1 turns on if your system is still powered, at which
time memory modules cannot be installed or uninstalled.
