- Page 1 User’s Guide Dell SE2717H/SE2717HX/SE2717HR Model No.: SE2717H/SE2717HX/SE2717HR Regulatory model: SE2717Hc...
- Page 2 Copyright © 2016–2019 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners. 2019 – 03...
-
Page 3: Table Of Contents
Contents About your monitor ......6 Package contents ..... . 6 Product features . - Page 4 Connecting the VGA cable (sold separately for SE2717HX/ SE2717HR)......22 Connecting the HDMI cable (sold separately for SE2717H) ..22 Organizing cables .
- Page 5 Appendix....... . . 50 FCC notices (U.S. Only) and other regulatory information 50 Contacting Dell..... . . 51 │...
-
Page 6: About Your Monitor
About your monitor Package contents Your monitor ships with the components shown in the table below. If any component is missing, contact Dell technical support. For more information see Contacting Dell. NOTE: Some items may be optional and may not ship with your monitor. -
Page 7: Product Features
• Software and documentation media includes an Information File (INF), Image Color Matching File (ICM), and product documentation. • Dell Display Manager Software included (in the CD shipped with the monitor). • Energy Saver feature for Energy Star compliance. • Security-lock slot. - Page 8 • 0.3 W standby power when in the sleep mode. • Energy Gauge shows the energy level being consumed by the monitor in real time. • Supports AMD FreeSync™ technology. • Optimize eye comfort with a flicker-free screen. • ComfortView feature is designed to reduce the amount of blue light emitted from the monitor to optimize eye comfort.
-
Page 9: Identifying Parts And Controls
Identifying parts and controls Front view Control buttons Label Description Function buttons (For more information, see Operating your monitor) Power On/Off button NOTE: For displays with glossy bezels the user should consider the placement of the display as the bezel may cause disturbing reflections from surrounding light and bright surfaces. -
Page 10: Back View
Barcode serial number and Service Refer to this label if you need to Tag label contact Dell for technical support. The Dell service tag is used for Dell warranty and customer service management purposes and for records of the base system. -
Page 11: Side View
Side view Bottom view Bottom view without monitor stand Label Description Power port Connect the power cable. HDMI port Connect your computer with HDMI cable. VGA port Connect your computer with VGA cable. About your monitor │... -
Page 12: Monitor Specifications
Color depth 16.7 million colors Color gamut CIE 1976 (84%), CIE 1931 (72%) FreeSync support frame 48-75 Hz frequency (HDMI port only) Dell display manager compatibility Connectivity 1xHDMI (ver 1.4) 1xVGA Border width (edge of monitor 11.60 mm (Top) to active area) 11.60 mm(Left/Right) -
Page 13: Resolution Specifications
Resolution specifications Model SE2717H/SE2717HX/SE2717HR Horizontal scan range 30 kHz to 83 kHz (automatic) Vertical scan range 48 Hz to 76 Hz (automatic) Maximum preset resolution 1920 x 1080 at 60 Hz for VGA port. 1920 x 1080 at 75 Hz for HDMI port. -
Page 14: Electrical Specifications
Electrical specifications Model SE2717H/SE2717HX/SE2717HR Video input signals • HDMI 1.4, 600mV for each differential line, 100 ohm input impedance per differential pair, • Analog RGB, 0.7 Volts +/-5%, positive polarity at 75 ohm input impedance 100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz /... -
Page 15: Physical Characteristics
Physical characteristics Model SE2717H/SE2717HX/SE2717HR Signal cable type • Digital: detachable, HDMI, 19 pins • Analog: detachable, D-Sub, 15 pins Dimensions (with stand) Height 458.7 mm (18.06 in) Width 621.1 mm (24.45 in) Depth 185.4 mm (7.30 in) Dimensions (without stand) Height 369.0 mm (14.53 in) Width 621.1 mm (24.45 in) -
Page 16: Environmental Characteristics
Environmental characteristics Model SE2717H/SE2717HX/SE2717HR Temperature Operating 0°C to 40°C (32°F to 104°F) Non-operating • Storage: -20°C to 60°C (-4°F to 140°F) • Shipping: -20°C to 60°C (-4°F to 140°F) Humidity Operating 20% to 80% (non-condensing) Non-operating • Storage 10% to 90% (non-condensing) • Shipping 10% to 90% (non-condensing) - Page 17 The OSD functions only in the normal operation mode. When any button is pressed in the Active-off mode, one of the following messages will be displayed: Dell SE2717H There is no signal coming from your computer. Press any key on the keyboard or move the mouse to wake it up.
-
Page 18: Pin Assignments
Pin assignments VGA connector Pin Number 15-pin Side of the Connected Signal Cable Video-Red Video-Green Video-Blue Self-test GND-R GND-G GND-B Computer 5V/3.3V GND-sync DDC data H-sync V-sync DDC clock │ About your monitor... - Page 19 HDMI connector Pin Number 19-pin Side of the Connected Signal Cable TMDS DATA 2+ TMDS DATA 2 SHIELD TMDS DATA 2- TMDS DATA 1+ TMDS DATA 1 SHIELD TMDS DATA 1- TMDS DATA 0+ TMDS DATA 0 SHIELD TMDS DATA 0- TMDS CLOCK+ TMDS CLOCK SHIELD TMDS CLOCK-...
-
Page 20: Plug And Play Capability
During the LCD Monitor manufacturing process, it is not uncommon for one or more pixels to become fixed in an unchanging state which are hard to see and do not affect the display quality or usability. For more information on Dell Monitor Quality and Pixel Policy, see Dell Support site at www.dell.com/support/monitors. -
Page 21: Setting Up The Monitor
Setting up the monitor Connecting the stand NOTE: The stand is detached when the monitor is shipped from the factory. NOTE: This is applicable for a monitor with a stand. If you have purchased a third-party stand, refer to the respective stand setup guide for the set up instructions. -
Page 22: Connecting Your Monitor
1. Turn Off your computer and disconnect the power cable. 2. Connect the VGA or HDMI cable from your monitor to the computer. Connecting the VGA cable (sold separately for SE2717HX/SE2717HR) Connecting the HDMI cable (sold separately for SE2717H) │... -
Page 23: Organizing Cables
Organizing cables Use the cable-management slot to organize the cables connected to your monitor. Setting up the monitor │... -
Page 24: Removing The Stand
Removing the stand NOTE: To prevent scratches on the LCD screen while removing the stand, ensure that the monitor is placed on a soft and clean surface. NOTE: This is applicable for a monitor with a stand. When any other stand is bought, please refer to the respective stand setup guide for the set-up instructions. -
Page 25: Operating Your Monitor
Operating your monitor Power on the monitor Press the button to turn on the monitor. Using the control buttons Use the control buttons at the bottom of the monitor to adjust the settings on your monitor. Control buttons The following table describes the control buttons: Control Buttons Description Use this button to choose from a list of preset... - Page 26 Use the Brightness/Contrast key for direct access to the "Brightness" and "Contrast" control menu. Shortcut key/ Brightness/ Contrast Use the Menu button to launch the On-Screen Display (OSD) and select the OSD Menu. See Accessing the OSD menu. Menu Use this button to go back to the main menu or exit the OSD main menu.
-
Page 27: Osd Controls
OSD controls Use the buttons at the bottom of your monitor to adjust the image settings. 1 2 3 4 Contorl Buttons Description Use the Up button to increase values or move up in a menu. Use the Down button to decrease values or move down in a menu. -
Page 28: Using The On-Screen Display (Osd) Menu
OSD menu, or wait for the OSD menu to automatically close. 1. Press the button to display the OSD main menu. Main Menu for analog (VGA) input Dell SE2717H Energy Use Brightness / Contrast Auto Adjust Input Source... - Page 29 Icon Menu and Description Submenus Brightness/ Use this menu to activate brightness/contrast Contrast adjustment. Dell SE2717H Energy Use Brightness / Contrast Auto Adjust Input Source Color Display Energy Menu Personalize Others Resolution: 1920x1080, 60Hz Brightness Brightness adjusts the luminance of the backlight.
- Page 30 Auto Adjust Use this key to activate automatic setup and adjust menu. Dell SE2717H Energy Use Brightness / Contrast Auto Adjust Press to adjust the screen automatically. Input Source Color Display Energy Menu Personalize Others Resolution: 1920x1080, 60Hz The following dialog appears on a black screen as the monitor self-adjusts to the current input: Auto Adjustment in Progress...
- Page 31 Input Source Use the input source menu to select between the different video signals that may be connected to your monitor. Dell SE2717H Energy Use Brightness / Contrast Auto Adjust HDMI Input Source Auto Select Color Reset Input Source Display...
- Page 32 Preset Modes When you select preset modes, you can choose standard, comfortview, multmedia, movie, game, warm, cool, or custom color from the list. • Standard: Loads the monitor's default color settings. This is the default preset mode. • ComfortView: Decreases the level of blue light emitted from the screen to make viewing more comfortable for your eyes.
- Page 33 Press the buttons to adjust the three colors (R, G, B) values and create your own preset color mode. Dell SE2717H Energy Use Brightness / Contrast Preset Modes Standard ComfortView Auto Adjust Multimedia Input Source Movie Color FPS Game Display...
- Page 34 This feature can shift the color of the video image to green or purple. This is used to adjust the desired flesh tone color. Use to adjust the hue from 0 to 100. Press to increase the green shade of the video image.
- Page 35 Display Use the display to adjust image. Dell SE2717H Energy Use Brightness / Contrast Aspect Ratio Wide 16:9 Auto Adjust Horizontal Position Input Source Vertical Position Color Sharpness Display Pixel Clock Phase Energy Dynamic Contrast Menu Normal Personalize Response Time...
- Page 36 Energy Dell SE2717H Energy Use Brightness / Contrast Power Button LED On During Active Auto Adjust Reset Energy Input Source Color Display Energy Menu Personalize Others Resolution: 1920x1080, 60Hz Power Button Allows you to set the power LED indicator on during active or off during active to save energy.
- Page 37 Menu Select this option to adjust the settings of the OSD, such as, the languages of the OSD, the amount of time the menu remains on screen and so on. Dell SE2717H Energy Use Brightness / Contrast Language English Auto Adjust...
- Page 38 Personalize Users can choose a feature from shortcut key 1, shortcut key 2, reset personalization, preset modes or Brightness/Contrast and set it as a shortcut key. Dell SE2717H Energy Use Brightness / Contrast Shortcut Key 1 Preset Modes Auto Adjust...
- Page 39 You can disable this feature by selecting disable. Enable this feature for best user experience and optimum performance of your monitor. Dell SE2717H Energy Use Brightness / Contrast DDC/CI Enable...
-
Page 40: Osd Warning Messages
OSD warning messages When the Dynamic Contrast feature is enabled (in these preset modes: Game or Movie), the manual brightness adjustment is disabled. Dell SE2717H To allow manual adjustment of brightness, the Dynamic Contrast will be switched off. Do you want to continue? - Page 41 If you press any button other than the power button, the following messages will appear depending on the selected input: Dell SE2717H No VGA signal from your device. Press any key on the keyboard or move the mouse to wake it up.
-
Page 42: Setting Up Your Monitor
• Go to your graphics card website and download the latest graphic drivers. If you have a Dell desktop or a Dell portable computer with internet access 1. Go to www.dell.com/support, enter your service tag, and download the latest driver for your graphics card. -
Page 43: If You Have A Non Dell Desktop, Portable Computer, Or Graphics Card
If you have a non Dell desktop, portable computer, or graphics card In Windows 7, Windows 8, Windows 8.1 and Windows 10: 1. For Windows 8 and Windows 8.1 only, select the Desktop tile to switch to classic desktop. 2. Right-click on the desktop and click Personalization. -
Page 44: Using Tilt
Using tilt NOTE: This is applicable for a monitor with a stand. When any other stand is bought, please refer to the respective stand setup guide for set up instructions. Tilt NOTE: The stand is detached when the monitor is shipped from the factory. -
Page 45: Troubleshooting
If the monitor is working correctly, it detects that there is no signal and one of the following message appears. While in self-test mode, the power LED remains white. Dell SE2717H No HDMI Cable The display will go into Power Save Mode in 5 minutes. -
Page 46: Built-In Diagnostics
Built-in diagnostics Your monitor has a built-in diagnostic tool that helps you determine if any screen abnormality you experience is an inherent problem with your monitor, or with your computer and video card. NOTE: You can run the built-in diagnostics only when the video cable is unplugged and the monitor is in self-test mode. -
Page 47: Common Problems
Missing Pixels • Cycle power On-Off. • Pixel that is permanently Off is a natural defect that can occur in LCD technology. • For more information on Dell Monitor Quality and Pixel Policy, see Dell Support site at: www.dell.com/support/monitors. Stuck-on Pixels • Cycle power On-Off. - Page 48 • Check for bent or broken pins in the video cable connector. • Restart the computer in the safe mode. Safety Related • Do not perform any troubleshooting steps. Issues • Contact Dell immediately. Intermittent • Ensure that the video cable connecting the monitor to the Problems computer is connected properly and is secure.
- Page 49 Video Ghosting or • Change the Response Time in the Display OSD to Fast or Overshooting Normal depending on your application and usage. Product-specific problems Specific Possible Solutions Symptoms Screen image is too • Check the Aspect Ratio setting in the Display settings OSD. small • Reset the monitor to Factory Settings (Factory Reset).
- Page 50 5. Perform stretches to relieve tension in the neck, arm, back, and shoulders during the breaks. FCC notices (U.S. Only) and other regulatory information For FCC notices and other regulatory information, see the regulatory compliance website located at www.dell.com/regulatory_compliance. │ Appendix...
- Page 51 4. Click Contact Us on the left side of the page. 5. Select the appropriate service or support link based on your need. 6. Choose the method of contacting Dell that is convenient for you. WARNING: For displays with glossy bezels the user should consider the placement of the display as the bezel may cause disturbing reflections from surrounding light and bright surfaces.
