HP Compaq Presario,Presario 9536 Supplementary Manual

System Boards

(w/o Processor) Assembly
P54C System Board, 004810-101
75/90 MHz, 8 MB, w/
MPEG
P54C System Board, 004813-101
75/90 MHz, 8 MB,
w/o MPEG
P54C System Board, 004814-101
100/133 MHz, 8 MB,
w/ MPEG
P54C System Board, 005491-101
100/133 MHz, 8MB,
w/o cache, w/ MPEG
1
Presario 9534, 9536, 9538.
3
Presario 9542, 9544, 9548, 9564.

Configuration Jumper Settings (004810, 004813, 004814, 005491)

Jumper Function
P1 CMOS Power
P2 Clock Multiplier
P3 Bus Speed Select 1 - 2

Microprocessors

P54C/75
P54C/90
P54C/100
P54C/133
1
Presario 9520.
3
Presario 9542, 9544, 9546, 9548.

Memory

4 MB SIMM, 60ns, Tin/Lead
Contacts. U.S. Only.
1 MB Video Memory
3-118
Presario 9500
Spare Part Config Codes
214524-001 HSB
GRZ
GRZ
214525-001 GRE
HRZ
214414-001 HSA
HSA
HTG
214079-001 HSA
2
Presario 9520, 9530, 9532, 9536.
4
Presario 9546.
Setting Description
1 - 2 Secure CMOS Power (Default)
Open Remove jumper 10 sec, then reinstall to
clear CMOS
Setting
A1-A2
B1-B2
A2-A3
B1-B2
A2-A3
B2-B3
A1-A2
B2-B3
50MHz CPU External Bus Frequency
2 - 3 40MHz CPU External Bus Frequency
3 - 4 60MHz CPU External Bus Frequency
4 - 5 66MHz CPU External Bus Frequency
Spare Part
172760-003
172760-002
213113-001
223311-001
2
Presario 9530, 9534, 9536, 9538.
4
Presario 9564.
Assembly Spare Part
214531-001 214049-001
004827-001 213859-001
System
Note 1
Note 2
Note 3
Note 4
Multiplier
1.5X
2.0X
2.5X
3.0X
System
Note 1
Note 2
Note 3
Note 4
System
9548, 9564
Option
Volume Two
