Summary of Contents for Sauber MFG 1521-AP
- Page 1 Operation and Maintenance Manual...
- Page 2 Valued Customer: Please review the following manual. If you have any ques- tions or need assistance of any kind, please contact your account representative toll free: Voice Communications......(800) 323-9147 Fax Communications......... (800) 833-3264 We welcome feedback on your manuals and our marketing communications.
- Page 3 Custom Engineered For AEP Preface Thank you for choosing Sauber Mfg. Co. You have purchased a trailer that has been designed and built with care. With a small amount of maintenance and by understanding its operation, your new trailer will provide you with years of excellent service.
- Page 4 1' of the hitch front. The calculations below assume 20% total weight transfer to the trailer tongue and are based on standard minimum butt and top circumference measurements for the class pole indicated. The pole trailer length required for Sauber Extendible Tongue Pole and Combination Trailers can be calculated by the for- mula: (TC / (TC + BC)) * 1.20 * PL + UB + 1 = Pole Trailer Length Required...
- Page 5 Striping........3-M........ # 29804-SP DOT-C2, 2"W Red/White Jack........... Sauber......Model 8808 EZ-Up w/ Sand Shoe Outrigger Jack......Sauber......Model 8805 Electrical Connector....SAE....... 11119, 7-way This information is the property of Sauber Mfg. Co. and is intended for customer use only.
- Page 6 Tensioning Brake....... Sauber......Model 1602-Detail Attached Retriever........Sauber......Model 1000 -Detail Attached Note: Most items listed here are in stock at Sauber Mfg. Co. This information is the property of Sauber Mfg. Co. and is intended for customer use only.
- Page 7 Tensioning Brake Factory Maintenance........Aprox 2500 hours of use Includes: 1. Rotor inspection/machining 1. Brake lining replacement 1. Pivot pin inspection 1. Alignment 1. Dynamic brake load testing This information is the property of Sauber Mfg. Co. and is intended for customer use only.
-
Page 8: Reference Drawing
11/2007 Operation & Maintenance Manual Page 6 Model 1521-AP Combination Trailer Reference Drawing This information is the property of Sauber Mfg. Co. and is intended for customer use only. -
Page 9: Maintenance
Care and Use of BOA Winches MAINTENANCE: • The gear mechanism requires periodic lubrication to maintain proper function. It is important to use premium grade 2 lithium based bearing grease with molydisulfide. • The grease fitting is located on the back of the gear housing and mates with a standard zerk adapter on a grease gun. - Page 10 Do not use tensioning bars other than the provided crank handle, which is designed specifically to work with the BOA winch. SHIPPING FROM SAUBER MFG. CO. In preparation for shipping, nearly the entire length of the strap is wrapped on the BOA winch mandrel.
- Page 11 • Customer Labor Reimbursement @ $65/hour • A credit memo will be issued for claims under $400 and can be applied to a credit card For additional details about our warranties, contact your sales professional, and thank you for investing in Sauber Manufacturing equipment.
