Quick Start Guide
Quick Start Guide
Be sure to install the software programs before connecting the scanner
to the computer!
Setup and Scanning
Unlock the Scanning Unit
Connect the Scanner
Try the Additional Features
2
3
4
5
p.
6
p.
7
10
p.
11
Advertisement
Table of Contents
Related Manuals for Canon CanoScan 5000F
Summary of Contents for Canon CanoScan 5000F
-
Page 1: Table Of Contents
Quick Start Guide Quick Start Guide Be sure to install the software programs before connecting the scanner to the computer! Setup and Scanning Check the Package Contents Install the Software Windows Macintosh Unlock the Scanning Unit Connect the Scanner Try Scanning Try the Additional Features Using the Scanner Buttons Scanning Film... - Page 2 If you are uncertain of the legality of scanning any particular item, you should consult your legal adviser in advance. As an ENERGY STAR Partner, Canon Inc. has determined that this model meets the ENERGY STAR Program for energy efficiency.
-
Page 3: Arcsoft Photostudio
Guide to the Manuals Quick Start Guide (this guide) This guide describes a series of processes, from opening the package to using the scanner. READ THIS GUIDE FIRST! Scanning Guide (HTML format manual) Refer to this guide when you have finished setting up the scanner according to the procedures in the Quick Start Guide. -
Page 4: Check The Package Contents
Check the Package Contents Scanner and Accessories CanoScan 5000F Film Guides for CanoScan 5000F (for a film strip and slides) Documents and Software Programs • Quick Start Guide (this guide) • Additional Documents • CanoScan Setup Utility CD-ROM • The two figures in the brackets below indicate the respective sizes of the Windows/ Macintosh versions of the software. -
Page 5: Install The Software
Install the Software (Windows) • With Windows XP/2000, you should log on with an administrator user name when you install or uninstall software programs. Turn the computer on. If the "Found New Hardware Wizard" or "Add New Hardware Wizard" appears, click [Cancel]. Place the CanoScan Setup Utility CD-ROM in the drive. -
Page 6: Install The Software (Macintosh)
Install the Software (Macintosh) Turn the computer on. If the “...Would you like to look for the software on the Internet?” appears, click [Cancel]. Place the CanoScan Setup Utility CD-ROM in the drive. The CanoScan Setup Utility main menu will display. If no window displays, double-click the CD-ROM icon, then the Setup icon. - Page 7 Unlock the Scanning Unit • Unlock the scanning unit before connecting the scanner to the computer. If it is left locked, a malfunction or other problem may occur. Open the document cover and peel the seals from the scanner. Push the lock switch toward the unlock mark ( •...
-
Page 8: Connect The Scanner
Connect the Scanner • Confirm that the scanning unit is unlocked. (P.5) Peel the caution seal from the back of the scanner. Connect the FAU cable to the scanner (CanoScan 5000F only). Connect the scanner to the computer with the supplied USB interface cable. Wide Flat Connector FAU Cable (CanoScan 5000F only) USB Interface Cable... -
Page 9: Windows
Try Scanning The following steps explain how to scan with ArcSoft PhotoStudio. Place a photo or a picture on the glass by aligning its top edge with the alignment mark, and close the document cover. Windows Select [Start], [Programs] or [All Programs], [ArcSoft PhotoStudio] and [PhotoStudio 5]. - Page 10 Try Scanning Windows Click the Acquire icon [File] menu and select [Acquire]. ScanGear CS will start. If an error message appears, click the [File] menu, choose [Select Source], select your scanner model name and click the [Select] button. For CanoScan 5000F, in the [Select source] category, select [Platen].
- Page 11 Click [Scan]. The final scan will start. Click (close box) in the ScanGear CS window to close it. The scanned image will appear in the PhotoStudio window. Save the scanned image. Click the [File] menu and select [Save As]. Select the folder where you wish to store the image file, enter a file name, select a file type (JPG format is recommended) and click [Save].
-
Page 12: Using The Scanner Buttons
Using the Scanner Buttons You can use the four convenient buttons on the front of the scanner to scan and perform related tasks easily with a single touch of the button. Place an item on the scanner before pressing a button. •... -
Page 13: Scanning Film
Scanning Film (for CanoScan 5000F) You can scan 35 mm film (a film strip or slides) with this scanner. Positioning the Film Use the following procedures to insert the film into the film guide. Remove the protective sheet from the document cover. Slide the protective sheet up to remove it. - Page 14 Scanning Film (for CanoScan 5000F) Place the loaded film guide on the scanner platen. Up to three frames in a film strip can be scanned at once. Position the film guide so that the three frames being scanned are toward the back of the platen and, as in the diagram, align the film guide with the FILM symbol on the platen.
-
Page 15: Simple Mode
Scanning Film (for CanoScan 5000F) Simple Mode In the [Select source] category, select [Film]. In the [Film type] category, select [Nega/Sleeve] or [Posi/Sleeve]. • Only film strips can be scanned in the Simple mode. To scan slides, switch to the Advanced mode by clicking the [Advanced Mode] button on the bottom right of the window. - Page 16 Scanning Film (for CanoScan 5000F) Click [Preview]. Place a check mark beside the number(s) of the frame(s) to be scanned and click [Scan]. At first, a check mark only appears beside the first frame. You can scan multiple frames in one step if you place check marks beside the numbers of each frame you wish to include.
-
Page 17: System Information
System Information This form should be used to record the operating environment for the purchased scanner. If any problems occur with the scanner, you will need this information when you contact our Customer Support Help Desk. Be sure to record the information and store it in a safe location. •... -
Page 18: Specifications
Specifications Scanner Type Scanning Element Light Source Optical Resolution Selectable Resolution Color Scanning Bit Depth Grayscale Color Scanning Speed (Photo or Document) Grayscale, B&W Scanning Speed (Film) Color, GrayScale, B&W Preview Speed Interface Maximum Document Size Film Type/Number of Frames Scanner Buttons Temperature Operating Range... - Page 19 CANON LATIN AMERICA, INC. 703 Waterford Way, Suite 400 Miami, Florida 33126, U.S.A. CANON MEXICANA, S. de R.L. de C.V. Anillo Periferico Sur No. 4124, Torre Zafiro (II) Colonia Ex-Rancho de Anzaldo, Piso 5 y 6, Mexico D.F. Tel. (525) 5490-2000 CANON PANAMA, S.A.
