TOOL AND FASTENER SPECIFICATIONS

TOOL SPECIFICATIONS
MODEL NO.
HEIGHT
WIDTH
LENGTH
WEIGHT
OPERATING PRESSURE
FASTENER SPECIFICATIONS
NAIL LENGTH
SHANK DIAMETER
TOOL AIR FITTINGS
This tool uses a 1/4" (6 mm) N.P.T. male plug. The inside diameter should
be .28" (7mm) or larger. The fitting must be capable of discharging tool air
pressure when disconnected from the air supply.
OPERATING AIR PRESSURE:
80 to 120 p.s.i. (5.5 to 8.3 bars). Select the operating air pressure within this range
for best tool performance.
DO NOT EXCEED THIS RECOMMENDED OPERATING PRESSURE.
T250-16S (Part# B20118)
11.6"
2.9"
12.3"
3.9lbs.
80 to 120 p.s.i. (5.5 to 8.3 bars)
1" - 2-½"
16 gauge (1.6 mm)
:
3
