TOOL AND FASTENER SPECIFICATIONS

TOOL SPECIFICATIONS
MODEL NO.
HEIGHT
WIDTH
LENGTH
WEIGHT
OPERATING PRESSURE
FASTENER SPECIFICATIONS
STAPLE LENGTH
STAPLE DIAMETER
TOOL AIR FITTINGS
This tool uses a 1/4" N.P.T. male plug. The inside diameter should be .28" (7mm)
or larger. The fitting must be capable of discharging tool air pressure when
disconnected from the air supply.
OPERATING AIR PRESSURE:
80 to 120 p.s.i. (5.5 to 8.3 bars). Select the operating air pressure within this range
for best tool performance.
DO NOT EXCEED THIS RECOMMENDED OPERATING PRESSURE.
SCS200 (Part# 515700)
11.7"
3.4"
15.1"
5lbs. 9 oz
80 to 120 p.s.i. (5.5 to 8.3 bars)
3/4"-2"
16 gauge
:
3
