- Page 1 Intelligent control ionizing air blower AP&T AP-DJ1811 Shanghai Anping Static Technology Co.,Ltd New Product Intelligent Control Ionizing Air Blower AP&T...
- Page 2 Suitable for electronics, optoelectronics, semiconductor and other industries Effectively solve the problems caused by static electricity Static removal Prevent adhesion of objects Prevent blockage of feeder Prevent material splash Prevent static electricity...
-
Page 3: Network Monitoring
Network Monitoring Multiple networking methods to monitor the working status of ionizing air blower online IMS monitoring software RS485 communication IMS monitoring software USB wire link AP-DY6703 IMS monitoring software USB wire link AP-KT3701 AP-DY6704... -
Page 4: Intelligent Remote Control
Intelligent Remote Control Cleaning time /Air volume output adjustable Cleaning time setting Set a reminder for the cleaning time at will. Blue light flashes indicates cleaning is required. The electrode needle cleaning cycle should be set according to the working environment when using the ionizing air blower. Cleaning cycle should be shorten appropriately in environment with more moisture and dust. - Page 5 Pulse DC Discharge effect is better compare to frequency AC ionizing air blower Pulse DC VS Traditional AC Positive voltage working time （Positive high voltage） Positive pulse Negative pulse Pulse DC Pulse DC method generate ions with two polarity by applying "+"...
- Page 6 Test Length (mm) Discharge Time(s) -150 Ion Balance(V) -150 Discharge time distribution diagram of AP-DJ1811 Ion balance distribution diagram of AP-DJ1811 Note：The 0 point of the test length is the center position of the air blower Test standard：ANSI/ESD.STM3.1，SJ/T 11446—2013 Test instrument: Trek charge plate tester Test voltage：±1000V →...
- Page 7 Features Safe / Easy to use / Durable No.1 Intelligent remote control Ion output characteristics can be adjusted by remote control. No.2 8 Electrode needles Multiple air outlets, 8 tungsten electrode needles per air outlet with longer life time. No.3 Built-in cleaning brush Automatic needle brushing function when start up.
- Page 8 Features Safe / Easy to use / Durable No.5 LED display LED display shows the equipment address (e.g.A00), wind speed gear (e.g.S1), cleaning cycle (e.g.T04), temperature and humidity, cleaning indication (Cleaning), fault alarm (Fan Fault!!) and HV fault alarm (HV Fault!!) No.6 High air volume fan five...
-
Page 9: Product Use
Product Use specification RJ45 power/communication interface （ ） wind speed gear （5gears） Run / Pause Fan No. Cleaning cycle Temperature and humidity Unlock / Lock （The temperature and humidity sensor is located inside the product） Green light always on: normal Blue light always on: pause/standby Blue light flashes: cleaning indication Red light always on: fan fault alarm... -
Page 10: Specification
Specification Model AP-DJ1811 Input voltage DC 24V（RJ45 Interface） Output voltage DC±4KV → ±6KV Power Ion emission Pulse DC Emitter electrode Tungsten alloy Discharge range 750*300mm（L*W） Air volume ≤ 135CFM*1 Noise Single air outlet≤ 58dBA（1000mm away from the air outlet） Ozone thickness ≤... -
Page 11: Installation Steps
Products Use Installation steps/technical tips/Installation accessories Installation steps 1. Install the ionizing air blower and the matching power adapter firmly in the best discharge position. 2. Insert the power network cable into the adapter and the ionizing air blower RJ45 network port, and insert the national standard power cable of the adapter into the row socket. - Page 12 Safety warning 1. Please read the instruction manual carefully before installing and using this equipment. 2. The whole set of equipment must be reliably grounded during use, and the connection resistance of the electrical connection to the AC equipment ground should be less than 1 ohm. 3.
- Page 13 It can be used only after the electrical performance index is normal. After-sales service AP-DJ1811 ionizing air blower has undergone rigorous testing and aging treatment before ex-work. Its performance has completely reached the relevant indicators marked in the usage instruction.
- Page 14 AP&T Professional electrostatic intelligent monitoring/analysis and elimination solution provider 专 业 创 造 价 值 S p ecia lit y C r ea t es Va l u e Shanghai Anping Static Technology Co.,Ltd Tel : +86-21-64517676 Fax : +86-21-64517673 Postcode : 200233 Website : www.ap-static.com Address : 3/F,Building 27,No.69,Guiqing Road,Shanghai,China...
