- Page 1 Intelligent Control / Network LED Display Ionizing Air Blower AP-DJ2813 AP&T Shanghai Anping Static Technology Co.,Ltd New Product Intelligent Control Network LED Display Ionizing Air Blower AP&T...
- Page 2 Suitable for electronics, optoelectronics, semiconductor and other industries Effectively solve the problems caused by static electricity Static removal Prevent adhesion of objects Prevent blockage of feeder Prevent material splash Prevent static electricity...
-
Page 3: Network Monitoring
Network Monitoring Monitoring the working status of ionizing air blower online IMS monitoring software RS485 communication IMS monitoring software USB wire link AP-DY6703 IMS monitoring software USB wire link AP-KT3701 AP-DY6704... -
Page 4: Intelligent Remote Control
Intelligent Remote Control Cleaning time /Air volume output/Ion balance adjustable Cleaning time setting Set a reminder for the cleaning time at will. Blue light flashes indicates cleaning is required. The electrode needle cleaning cycle should be set according to the working environment when using the ionizing air blower. Cleaning cycle should be shorten appropriately in environment with more moisture and dust. - Page 5 Pulse DC Discharge effect is better compare to frequency AC ionizing air blower Pulse DC VS Traditional AC Positive voltage working time Pulse DC method generate ions with two polarity by （Positive high voltage） Positive pulse Negative pulse applying "+" and "-" high voltage alternately on Pulse DC positive and negative electrode needles.
- Page 6 -125 -400 -250 -125 Discharge time distribution diagram of AP-DJ2813 Ion balance distribution diagram of AP-DJ2813 Note：The 0 point of the test length is the center position of the air blower Test standard：ANSI/ESD.STM3.1，SJ/T 11446—2013 Test instrument: Trek charge plate tester Test voltage：±1000V →...
- Page 7 Features Safe / Easy to use / Durable No.1 Magnetic net cover The power is cut off immediately and the fan is in the standby (STOP) state when the net cover is separated , which is convenient for disassembly and maintenance. No.2 High air volume fan five speed adjustment...
- Page 8 Features Safe / Easy to use / Durable No.6 LED display LED display shows the equipment address (e.g.A00), wind speed gear (e.g.S1), cleaning cycle (e.g.T04), temperature and humidity, cleaning indication (Cleaning), fan fault alarm (Fan Fault!!) and HV fault alarm (HV Fault!!). The balance voltage of each air outlet displays in real time, which alarms (Ion Fault!!!) when the set threshold is exceeded, alarms fault when the high voltage is 0V.
-
Page 9: Product Use
Product Use Panel functions/specification/dimensions Panel functions Front Back Three-in-one power switch Cleaning switch Power switch Bakelite screw handle（M5×8） Ground Stud Air volume adjustment L-shaped bracket Status Indicator RJ45 power/communication interface LCD display LCD parameter display description Display content Description Sample graph RUN/STOP Run / Pause Green light：Running... -
Page 10: Specification
Specification Model AP-DJ2813 Input voltage Input voltage DC 24V（RJ45 interface）/ Three in one socket（220VAC 50/60Hz） Output voltage DC±4KV → ±6KV Power Ion emission Pulse DC Emitter electrode Tungsten alloy Discharge range 750*550mm（L*W） Air volume ≤ 135CFM*3 Noise Single air outlet≤ 58dBA（1000mm away from the air outlet）... -
Page 11: Installation Steps
Products Use Installation steps/technical tips/Packing accessories Installation steps 1. Install the ionizing air blower and the matching power adapter firmly in the best discharge position. 2. Insert the power network cable into the adapter and the ionizing air blower RJ45 network port, and insert the three-phase power cable of the adapter into the row socket. - Page 12 Safety warning 1. Please read the instruction manual carefully before installing and using this equipment. 2. The whole set of equipment must be reliably grounded during use, and the connection resistance of the electrical connection to the AC equipment ground should be less than 1 ohm. 3.
- Page 13 It can be used only after the electrical performance index is normal. After-sales service AP-DJ2813 ionizing air blower has undergone rigorous testing and aging treatment before ex-work. Its performance has completely reached the relevant indicators marked in the usage instruction.
- Page 14 AP&T Professional electrostatic intelligent monitoring/analysis and elimination solution provider 专 业 创 造 价 值 S p ecia lit y C r ea t es Va l u e Shanghai Anping Static Technology Co.,Ltd Tel : +86-21-64517676 Fax : +86-21-64517673 AP&T Postcode : 200233 Website : www.ap-static.com...
