- Page 1 Self-cleaning Desktop Ionizing Air Blower AP&T AP-DC2451-001 Shanghai Anping Static Technology Co.,Ltd Self-cleaning Desktop Ionizing Air Blower AP&T...
- Page 2 Suitable for electronics, optoelectronics, semiconductor and other industries Effectively solve the problems caused by static electricity Static removal Prevent adhesion of objects Prevent blockage of feeder Prevent material splash Prevent static electricity...
- Page 3 Speciality Creates Value...
- Page 4 High Efficiency Static Removal Keep a clean production environment and stay away from static electricity Discharge effect Test standard：ANSI/ESD.STM3.1，SJ/T 11446—2013 Test instrument: Trek 157 static tester Test voltage：±1000V → ±100V attenuation 300mm 600mm 900mm 1200mm 20.8s 6.5s 6.8s 10.9s 300mm Test environment：humidity 50±5%；temperature 23±3℃...
- Page 5 Features Safe / Easy to use / Durable No.1 Automatic needle brushing Automatic needle brushing function when start up. By default, the needle is automatically brushed every 8 hours for manual cleaning and maintenance free. No.2 Standard tungsten alloy needle Longer life time compare to titanium and silicon materials.
-
Page 6: Product Specifications
Product specifications Product details / Product specifications / Product size Product details Front Back Metal net cover Power switch Bakelite screw handle（M5×12） Working status indicator Power input socket U-shaped bracket Air volume adjustment knob Product size Unit：mm ① Air volume adjustment knob ②... - Page 7 Product specifications Model AP-DC2451-001 Input voltage Power Working voltage ±DC4000-DC7000V Ion emission Steady-state DC Tungsten Alloy Emitter electrode Discharge structure Uncoupled electrical contact (discharge cylinder) Discharge range 750*300mm（L*W） Discharge speed ≤ 2.0s（300mm away from the air outlet） Ion balance ≤ |±10V|（300mm away from the air outlet）...
-
Page 8: Installation Position
Products Use Step of use/Installation position/Packing accessories Step of use Take out the power adapter from the packing box and Use screws or bolts to fix on a firm and flat surface(such connect the ionizing air blower. as a wall or shelf). The angle of ionizing air blower can Place the ionizing air blower close to the working area be adjusted by the knobs on both sides of the bracket to (about 300~750mm away from the object with... -
Page 9: Troubleshooting
Safety warning 1. Read the operating instruction carefully before installing and using the device. 2. Do not insert foreign objects into the inlet or outlet of the ionizing air blower. 3. Do not use the device when the humidity is higher than 70%. 4. - Page 10 AP&T Professional electrostatic intelligent monitoring/analysis and elimination solution provider 专 业 创 造 价 值 S p ecia lit y C r ea t es Va l u e Shanghai Anping Static Technology Co.,Ltd Tel : +86-21-64517676 Fax : +86-21-64517673 AP&T Postcode : 200233 Website : www.ap-static.com...
