- Page 1 G20 Mobile Maintenance Platform Owner’s Manual www.equiptec.co...
-
Page 2: Table Of Contents
Contents Introduction ..............Compliance ..............Assembly ..............Warranty ..............Safety Requirements ..........Prior to Use ..............Positioning the Giraffe G20 ........G20 Use ..............Giraffe G20 Stability ..........Operation ..............Maintenance .............. Six Monthly Service Inspection ......Annual Service Inspection ........Bi-Annual Service Inspection ........ - Page 3 Contents Optional Accessories ..........One Step Extension ..........Two Step Extension ..........Four Step Extension ..........Eight Step Extension ..........Hammerhead Deck ..........Angle Deck ..............Slide Out Deck ............Trailer ................Transport ..............Notes ................Contact Details ............Giraffe Owner’s Manual G20 - SB 1.0 January 2022...
-
Page 4: Introduction
Introduction The Equiptec Giraffe G20 (G20) is designed to facilitate easy and simple stair access to a variable height platform. It incorporates a large cantilever to allow the platform to be positioned over obstacles, and thus provide a deck that is sturdy, and as ergonomically safe as possible to work from. The G20 has a wide variety of Standard Accessories that can be added to it, and therefore can be Customised in different ways. -
Page 5: Warranty
Equiptec via the service checklist form (either scan the QR code on the unit or click the link in the reminder E-mail). -
Page 6: G20 Use
Safety Requirements Positioning the G20 4. The standard issue castor wheels are not designed to roll over obstacles. If the surface of the area the G20 is to be moved across is soft, has larger stones, objects or debris in the G20’s path, or for any reason the G20 cannot be moved by manual pushing/ pulling, it is recommended to shift the G20 with a forklift using the forklift pockets provided. -
Page 7: Giraffe G20 Stability
Safety Requirements Using the G20 (see also ‘Operation’) 5. In its standard configuration, the G20 deck has 3 access gates to facilitate access to/from a work surface if required. These gates must remain shut except when walking through them. Do not use these gates if there is not a flat surface immediately beyond it that has been certified to be of sufficient strength to support your weight and has sufficient,... -
Page 8: Operation
Safety Requirements G20 Stability Speed Wind Visable Indications Action Required Metre / Description Moderate Raises dust and Safe to work on 13 - 18 20 - 29 5.5 - 7.9 Breeze loose paper Cease to work Small trees in leaf on the G20 and Fresh Breeze 19 - 24... -
Page 9: Maintenance
While these checks are relatively simple, it is recommended that they are carried out by qualified tradespeople. If the Owner does not wish to carry out any particular service or task themselves, Equiptec may be able to arrange for an authorised Equiptec Distributor to visit the Site and perform these tasks, however, the Distributor may charge for this service. -
Page 10: Six Monthly Service Inspection
Upload any photos of any damage Note: Once photos of any damage are uploaded, check with Equiptec before continuing to operate a damaged unit. It must be ascertained if the damage will compromise safety, strength, or the smooth functioning of the G20. -
Page 11: Annual Service Inspection
Hydraulic Ram needs bleeding (usually causes a soft “spongey” lift that does not go to full height easily). See Instructions in “Hydraulic System” section below 8. Check for any excess movement (either fore/aft or lateral) of the deck when fully elevated. Contact Equiptec for advice if any issues come to light. -
Page 12: Bi-Annual Service Inspection
Check the condition of all Rollers# Note: Use a safe platform ladder such as an Equiptec Squirrel to access the Side Panel Top Covers and remove them. # Note: Check Roller condition carefully especially if the environment the G20 is operating in is dusty or abrasive in any way. -
Page 13: Giraffe G20 Parts Diagrams
BEND RADIUS & ALLOWANCES TO BE CHECKED BY DIMENSIONS ARE IN MILLIMETERS DRAWING IS THE SOLE MANUFACTURER AND PART MODIFIED TO SUIT AS PER FINISHED UNLESS OTHERWISE SPECIFIED PROPERTY OF EQUIPTEC ANY DIMENSIONS. DO NOT SCALE FROM DRAWING REPRODUCTION IN PART OR ALL PARTS DEBURRED PART NO. -
Page 14: Base Unit Parts Diagram
DIMENSIONS ARE IN MILLIMETERS DRAWING IS THE SOLE Product Product MANUFACTURER AND PART MODIFIED TO SUIT AS PER FINISHED UNLESS OTHERWISE SPECIFIED PROPERTY OF EQUIPTEC ANY DIMENSIONS. DO NOT SCALE FROM DRAWING Description Qty No. Description REPRODUCTION IN PART OR ALL PARTS DEBURRED PART NO. -
Page 15: Roller Panel Parts Diagram
BEND RADIUS & ALLOWANCES TO BE CHECKED BY DIMENSIONS ARE IN MILLIMETERS DRAWING IS THE SOLE MANUFACTURER AND PART MODIFIED TO SUIT AS PER FINISHED UNLESS OTHERWISE SPECIFIED PROPERTY OF EQUIPTEC ANY DIMENSIONS. DO NOT SCALE FROM DRAWING REPRODUCTION IN PART OR ALL PARTS DEBURRED PART NO. -
Page 16: Hydraulic System
Maintenance Hydraulic System Hydraulic Oil The Oil used in the Giraffe hydraulic system is standard ISO 46 hydraulic oil. Brand equivalents are shown here. Supplier Product Name Supplier Product Name Atlantic Hy Lube Hydraulic Fluid ISO 46 Mobil DTE 25 Batran 46 Penrite Indus Pro Hydraulic 46... -
Page 17: Descent Speed Adjustment
Maintenance Hydraulic System Descent Speed Adjustment The Hydraulic system has a valve to control the speed of the descent of the Platform. This will be factory set at a suitable speed that is both practical and safe. This should not need any alteration, but if for any reason further adjustment is required, the procedure is as follows…... -
Page 18: Hydraulic System Parts Identification
Maintenance Hydraulic System Hydraulic System Parts Identification The system is relatively simple. See hydraulic system general assembly below. ITEM NO. DESCRIPTION PART NO. Default/QTY. PM 25 s PUMP 1/4"-3/8" ADAPTOR AC-0406 DOWTY WASHER 1/4" DO4 2002600 1/4" FLOW CONTROL VALVE WITH CHECK VRFU9001 1/4"-1/4"... -
Page 19: Optional Accessories
Optional Accessories Many optional extras are available for the G20. They can all be retrofitted relatively simply, but Equiptec recommend these tasks are undertaken by an Engineering based Tradesperson. The instructions for fitting each type are all downloadable from the Equiptec website, and Equiptec remains available to assist via Video Conference if required. -
Page 20: Hammerhead Deck
Optional Accessories Hammerhead Deck This option gives a wider deck at the front. With 1.8m of room it allows 2 people to comfortably work alongside each other. The Hammerhead Deck also offers the ability to remove gates on either, or both sides, giving unimpeded access to a 1.8m wide workface. -
Page 21: Transport
Transport When transporting the G20 in its fully made up form, it is mandatory to ensure the following: • The G20 is completly lowered • The unit is supported under chassis within 100mm in from the Castor Brackets at either end, and at a height that allows the wheels to swivel freely (See blue squares depicting packers in diagram below). -
Page 22: Notes
Notes Page 19 January 2022 G20 - SB 1.0 Giraffe Owner’s Manual... -
Page 23: Contact Details
Contact details Manufacturer The Equiptec Giraffe G20 is manufactured in New Zealand by Equiptec. Please contact us and one of our team will be very happy to assist in your enquiry. Head Office USA Office P: +64 6 842 0222 P: + 1 888 523 4340 E: sales@equiptec.co... - Page 24 Manufacturers of Giraffe, Monkey and Squirrel AHP www.equiptec.co Ph: +64 6 842 0222...
