Summary of Contents for Equiptec Giraffe G20

  • Page 1 G20 Assembly Manual www.equiptec.co...
  • Page 2 Assembly Instructions for your new Equiptec Giraffe G20 You may also like to watch a video and/or CAD animation of this sequence at www.equiptec.co/Giraffe Alternatively contact Equiptec directly for advice. w. www.equiptec.co e. sales@equiptec.co p. +64 6 842 0222 Giraffe G20 as shipped with it packaging removed Giraffe Assembly Instructions G20 - SB 2.0...
  • Page 3 Washer Heavy Duty Flat Washer hollow members Washer Spring Washer Bolt Bolt M8 Nyloc Heavy Duty Flat Washer Washer Handrail M8 Cap Extrusion Pivot Screw Bolt Joiner Giraffe Assembly Instructions G20 - SB 2.0 www.equiptec.co April 2021...
  • Page 4 Stair Midrail Assembly Platform Handrail Assembly Platform LH Handrail Assembly Platform RH Handrail Assembly Upper Platform Stair Handrail Assembly Left Corner Post + Gate Assembly Right Corner Post + Gates Assembly Giraffe Assembly Instructions G20 - SB 2.0 www.equiptec.co April 2021...
  • Page 5 Platform RH Handrail Assembly Assembly Stair Handrail Stair Midrail Platform Handrail Assembly Assembly Assembly Left Corner Post + Gate Right Corner Post + Gates Assembly Assembly Upper Platform Stair Handrail Assembly Giraffe Assembly Instructions G20 - SB 2.0 www.equiptec.co April 2021...
  • Page 6 4. Install pump handle - slide into place (as per detail A) and tighten grub screw into indent at base of handle Detail A Pump Handle Grub Screw to be tightened Giraffe Assembly Instructions G20 - SB 2.0 www.equiptec.co April 2021...

  • Page 7: Step 2 - Deck Installation

    Ensure bolt heads are on the inside (facing the deck) Fastening List 12 x M10 x 30mm Bolt 12 x M10 Nyloc Nut 24 x M10 Flat Washer Rotate Deck up into position Giraffe Assembly Instructions G20 - SB 2.0 www.equiptec.co April 2021...

  • Page 8: Step 3 - Castor Wheel Assembly

    12 x M12 Nordlock Washer M12 Flat M12 Spring 8 x M12 Flat Washer Washer Washer 8 x M12 Spring Washer M12 x 40mm Bolt + Flat Washer + Spring Washer x 2 Giraffe Assembly Instructions G20 - SB 2.0 www.equiptec.co April 2021...
  • Page 9 (7.5 ft/lbs) torque Fastening List 4 x M10 x 80mm Bolt 4 x M10 Nyloc Nut 8 x M10 Flat Washer M10 x 80mm Bolt DO NOT OVERTIGHTEN 10Nm (7.5 ft/lbs) maximum Giraffe Assembly Instructions G20 - SB 2.0 www.equiptec.co April 2021...
  • Page 10 Step 5 - Fitting Floating Treads 1. Install the five Floating Treads as shown 2. Ensure orientation is correct Floating Treads Giraffe Assembly Instructions G20 - SB 2.0 www.equiptec.co April 2021...
  • Page 11 4 x M10 Heavy Duty Washer Leave this cap screw loose M10 x 65mm Bolt DO NOT OVERTIGHTEN Max tighting torque 10Nm (7.5 ft/lbs) See general fixing detail B on page 2 Giraffe Assembly Instructions G20 - SB 2.0 www.equiptec.co April 2021...
  • Page 12 DO NOT OVERTIGHTEN Max tighting torque 10Nm (7.5 ft/lbs) See general fixing detail A on page 2 Leave these cap screws loose See general fixing detail D on page 2 Giraffe Assembly Instructions G20 - SB 2.0 www.equiptec.co April 2021...
  • Page 13 2 x M8 x 35mm Cap Screw 2 x M8 Nyloc Nuts 4 x M10 x 65mm Bolt 4 x M10 Nyloc Nut 4 x M10 Flat Washer 4 x M10 Heavy Duty Washer Giraffe Assembly Instructions G20 - SB 2.0 www.equiptec.co April 2021...
  • Page 14 DO NOT OVERTIGHTEN Max tighting torque 10Nm (7.5 ft/lbs) M10 x 70mm Bolt DO NOT OVERTIGHTEN Max tighting torque 10Nm (7.5 ft/lbs) See general fixing detail A on page 2 Giraffe Assembly Instructions G20 - SB 2.0 www.equiptec.co April 2021...
  • Page 15 2 Ensure bolt heads are on inside (facing treads) M10 x 75mm Bolt DO NOT OVERTIGHTEN Max tighting torque 10Nm (7.5 ft/lbs) See general fixing detail A on page 2 Giraffe Assembly Instructions G20 - SB 2.0 www.equiptec.co April 2021...
  • Page 16 3 x M10 Flat Washer 3 x M10 Heavy Duty Washer M10 x 70mm Bolt DO NOT OVERTIGHTEN Max tighting torque 10Nm (7.5 ft/lbs) See general fixing detail A on page 2 Giraffe Assembly Instructions G20 - SB 2.0 www.equiptec.co April 2021...
  • Page 17 3 x M10 Heavy Duty Washer M10 x 70mm Bolt Right corner DO NOT OVERTIGHTEN post and gates Max tighting torque assembly 10Nm (7.5 ft/lbs) See general fixing detail A on page 2 Giraffe Assembly Instructions G20 - SB 2.0 www.equiptec.co April 2021...
  • Page 18 Your New Equiptec Giraffe G20 is now ready for use Contact Equiptec to activate your G20 warranty now! Ensure all users read, understand and follow all safety notices and directions in the Owner’s Manual Giraffe Assembly Instructions G20 - SB 2.0 www.equiptec.co...

  • Page 19: Contact Details

    Contact details Manufacturer The Giraffe G20 is manufactured in New Zealand by Equiptec. Please contact us and one of our team will be very happy to assist in your enquiry. Ph: +64 6 842 0222 E: sales@equiptec.co W: www.equiptec.co Physical address:...
  • Page 20 Manufacturers of Lift Series Giraffe, Monkey and Squirrel www.equiptec.co Ph: +64 6 842 0222...
