Allied Healthcare ResusciTIMER Manual

The Resuscitation Timer has been designed to work with a bag mask resuscitator. The Resuscitation Timer monitors the
patient airway pressure to determine and display inspiratory time, breaths per minute (BPM) and airway pressure. The
Resuscitation Timer will guide the caregiver to deliver resuscitation per the American Heart Association Guidelines 2005.
Should the Resuscitation Timer stop working for any reason, continue to use the bag mask resuscitator in a normal
manner.
ResusciTIMER™
Functional Specifications
Size 3.9" width x 2.7" height x 1.4" depth
(9.9 cm width x 6.8 cm height x 3.5 cm depth)
Weight 5 ounces including battery
Battery Type 9V Alkaline
Battery Life 4.5 hrs, continuous use @ 72°F
Airway Pressure 60 cm of H
Adult Setting I time = 1.0 – 1.4 sec 10 ± 2 BPM
Child Setting I time = 1.0 – 1.4 sec 18 ± 2BPM
Accuracy I time = 10% or .1 sec
Operating Conditions
Temperature
0°F to 120°F (10°C to 38°C)
Relative Humidity 0% to 90%
Storage Conditions
Temperature
-20°F to 140°F (-29°C to 60°C)
Relative Humidity 0% to 90%
Shipping Conditions
Temperature
-40°F to 140°F (-40°C to 60°C)
Relative Humidity 0% to 90%
PATENT PENDING
0 maximum Accuracy 5%
2
BPM = ±1
1
