Chromalox FXTH PN401 Installation & Operation Manual

RENEWAL PARTS IDENTIFICATION
Chromalox Type FXTH Flexible Tank Heater
Thermowell
3/4" NPT
Thermowell
Riser
Specifications – Type FXTH
Amp / Tube
kW 240 480
6 15 7
8 19 10
10 24 12
12 29 14
10 24 12
12 29 14
15 36 18
18 43 22
21 51 25
24 58 29
27 65 33
30 72 36
12 15 7
16 19 10
20 24 12
24 29 14
20 24 12
24 29 14
30 36 18
36 43 22
42 51 25
48 58 29
54 65 33
60 72 36
18 15 7
30 24 12
36 29 14
30 24 12
36 29 14
45 36 18
*Suffix letters with FXTH Catalog Number indicate modification from standard as follows:
V= Voltage, W= Wattage, A= change in riser length, R= low temperature alarm contactor, D= temperature indicator and XX = special.
© 2010 Chromalox, Inc.
Chromalox
Installation, Operation
and
Heater
Terminal
Housing
2-1/2" NPT
Three Tube
Heater Assembly
C
Minimum Heater Heater
Manhole Length Width
Size (In.) B
14 12'3-3/4" 5-1/4
14 15'3-3/4" 5-1/4
14 15'3-3/4" 5-1/4
14 15'3-3/4" 5-1/4
14 20'3-3/4" 5-1/4
14 20'3-3/4" 5-1/4
14 20'3-3/4" 5-1/4
14 27'1" 5-1/4
14 30'1" 5-1/4
14 32'1" 5-1/4
14 35'1" 5-1/4
14 40'1" 5-1/4
18 12'3-3/4" 10-1/4
18 15'3-3/4" 10-1/4
18 15'3-3/4" 10-1/4
18 15'3-3/4" 10-1/4
18 20'3-3/4" 10-1/4
18 20'3-3/4" 10-1/4
18 20'3-3/4" 10-1/4
18 27'1" 10-1/4
18 30'1" 10-1/4
18 32'1" 10-1/4
18 35'1" 10-1/4
18 40'1" 10-1/4
24 15'3-3/4" 15-1/4
24 15'3-3/4" 15-1/4
24 15'3-3/4" 15-1/4
24 20'3-3/4" 15-1/4
24 20'3-3/4" 15-1/4
24 20'3-3/4" 15-1/4
®
9-3/16"
6-1/4"
Two Tube Single Tube
Heater Assembly Heater Assembly
Notes:
1. Min. fluid Depth for safe heater operation is 12".
2. 5/8" - 11 x 1 in. long hex head bolts. 8 required.
No. Tubes
and Catalog
C Circuits Number*
1 FXTH-11206
1 FXTH-11508
1 FXTH-11510
1 FXTH-11512
1 FXTH-12010
1 FXTH-12012
1 FXTH-12015
1 FXTH-12718
1 FXTH-13021
1 FXTH-13224
1 FXTH-13527
1 FXTH-14030
2 FXTH-21212
2 FXTH-21516
2 FXTH-21520
2 FXTH-21524
2 FXTH-22020
2 FXTH-22024
2 FXTH-22030
2 FXTH-22736
2 FXTH-23042
2 FXTH-23248
2 FXTH-23554
2 FXTH-24060
3 FXTH-31218
3 FXTH-31530
3 FXTH-31536
3 FXTH-32030
3 FXTH-32036
3 FXTH-32045
4
FEBRUARY, 2008
Vent Tube
Bolts. See
Note 2
Heater Terminal Housing
2"
Gasket (Furnished)
Manhole Adapter (Optional)
Customer Manhole Cover
14'
12"
B
Catalog Number of Recommended
OCC or WCC Control Centers
Approx
Net Wt.
Lbs. 240V
79 (OCC or WCC)-15-213
97 WCC-25-213
97 WCC-25-213
97 WCC-30-213
127 WCC-25-213
127 WCC-30-213
127 WCC-40-213
170 WCC-45-213
190 WCC-55-213
205 WCC-60-213
225 WCC-70-213
250 WCC-75-213
157 WCC-15-223
194 WCC-25-223
194 WCC-25-223
194 WCC-30-223
253 WCC-25-223
253 WCC-30-223
253 WCC-40-223
340 WCC-45-223
380 WCC-55-223
405 WCC-60-223
440 WCC-70-223
500 WCC-75-223
236 WCC-15-233
291 WCC-25-233
291 WCC-30-233
370 WCC-25-233
370 WCC-30-233
370 WCC-40-233
FXTH
PN401
161-051300-001
Lifting Cables
Overtemperature
Sensor
8"
480V
WCC-10-413
WCC-10-413
WCC-15-413
WCC-15-413
WCC-15-413
WCC-15-413
WCC-20-413
WCC-25-413
WCC-30-413
WCC-30-413
WCC-35-413
WCC-40-413
WCC-10-423
WCC-10-423
WCC-15-423
WCC-15-423
WCC-15-423
WCC-15-423
WCC-20-423
WCC-25-423
WCC-30-423
WCC-30-423
WCC-35-423
WCC-40-423
WCC-10-433
WCC-15-433
WCC-15-433
WCC-15-433
WCC-15-433
(OCC or WCC)-20-433
