INSTALLATION AND MAINTENANCE INSTRUCTIONS
Intelligent Plug-In Model 5251P
Fixed Temperature Sensor
Before installing sensors, refer to NFPA 72, and 101 (Life Safety Code) for information on sensor spacing, placement, zon-
ing, and special applications.
GENERAL DESCRIPTION
Model 5251P is an intelligent sensor that utilizes a state-of-the-art thermistor sensing circuit for fast response. This sensor
is designed to provide open area protection with 50 foot spacing capability and is intended for use with compatible con-
trol panels only.
Two LEDs on each sensor light to provide 360° visibility of the sensor indication. The LEDs can be latched ON by code
command from the panel for an alarm indication. The LEDs can also be unlatched to the normal condition by code com-
mand. Remote LED annunciator capability is available as an optional accessory (Part No. RA400Z).
SPECIFICATIONS
Diameter:
Height:
Weight:
Installation Temperatures:
Operating Humidity Range:
Mounting:
Voltage Range:
Standby Current:
LED Current:
Fixed Temperature Rating:
WIRING GUIDE
Refer to the installation instructions for the particular plug-in base being used: 1) for the B210LP base (D250-01-00); 2) for
the B501 base (D550-02-00); 3) for the RMK400 used with the B501 base (D450-07-00). Bases are provided with screw ter-
minals for power, ground, and remote annunciator connections. See Figure 1.
D200-88-00
6.1 inches (155 mm) installed in B210LP
4.1 inches (104 mm) installed in B501
2.0 inches (51 mm)
5 ounces (150 gm)
-4° F to 100° F (-20° C to 38° C)
10% to 93% Relative Humidity Non-condensing
B210LP flanged base
B501 flangeless base
B501 with RMK400 recessed mounting kit
15 to 32 Volts DC Peak
300 µ A @ 24 VDC (one communication every 5 seconds with LED blink enabled)
6.5 mA @ 24 VDC
135° F (57° C)
1
firealarmresources.com
A Division of Pittway
3825 Ohio Avenue, St. Charles, Illinois 60174
1-800-SENSOR2, FAX: 630-377-6495
I56-1331-02R
Advertisement
Table of Contents
Related Manuals for Pittway System Sensor 5251P
Summary of Contents for Pittway System Sensor 5251P
- Page 1 INSTALLATION AND MAINTENANCE INSTRUCTIONS Intelligent Plug-In Model 5251P A Division of Pittway 3825 Ohio Avenue, St. Charles, Illinois 60174 Fixed Temperature Sensor 1-800-SENSOR2, FAX: 630-377-6495 Before installing sensors, refer to NFPA 72, and 101 (Life Safety Code) for information on sensor spacing, placement, zon- ing, and special applications.
- Page 2 NOTE: All wiring must conform to applicable local codes, ordinances, and regulations. NOTE: Verify that all sensor bases are installed and that the wiring polarity is correct at each base. WARNING: Disconnect the power from the loop before installing sensors. 1.
- Page 3 2. The LEDs on the detector should light when the temperature at the detector reaches 135° F (57° C). If the LEDs fail to light, check the power to the detector and the wiring in the detector base. 3. Reset the detector at the system control panel. Detectors that fail these tests should be cleaned as described under MAINTENANCE and retested.
- Page 4 Please refer to insert for the Limitations of Fire Alarm Systems Three-Year Limited Warranty System Sensor warrants its enclosed heat detector to be free from defects ment, RA #__________, 3825 Ohio Avenue, St. Charles, IL 60174. Please in materials and workmanship under normal use and service for a period include a note describing the malfunction and suspected cause of failure.
