INSTALLATION AND MAINTENANCE INSTRUCTIONS
1251 Plug-in Intelligent Ionization
Sensor with Communications
Specifications
Operating Voltage Range:
Max. Avg. Standby Current:
Max. Alarm Current (LED on):
Operating Humidity Range:
Operating Temperature Range:
Height:
Diameter:
Weight:
Before Installing
Please read the system wiring and installation manual, I56-
407. This manual includes detailed information on sensor
spacing, placement, zoning, and special applications. Cop-
ies of this manual are available from System Sensor.
General Description
The Model 1251 intelligent ionization sensor uses a state-
of-the-art sensing chamber. This sensor is designed to pro-
vide open area protection and is intended for use with
compatible control panels only.
Two LEDs on each sensor light to provide a local, visible
sensor indication. The LEDs can be latched on by code
command from the control panel for an alarm indication.
The LEDs can also be unlatched to the normal condition by
code command. Remote LED annunciator capability is also
available as an optional accessory (RA400Z).
D200-51-00
Technical Manuals Online! - http://www.tech-man.com
15 to 32 VDC
300µA @ 24 VDC (one communication every 5 sec. with LED blink enabled)
6.5 mA @ 24 VDC
10% to 93% Relative Humidity, noncondensing
0° to 49°C (32° to 120°F)
1.7 inches (43 mm) installed in B210LP Base
6.2 inches (155 mm) installed in B210LP Base
4.1 inches (104 mm) installed in B501 Base
3.6 oz. (102 g)
1
