BASSO15
15˝ Bass-Reflex Multipurpose Subwoofer
Many key factors are to be considered when configuring the subwoofer
section of a loudspeaker system to perfectly match each application:
size/weight, logistic and operational setups, SPL needs, LF extension,
cost limitations, as well as sound engineer preferences (depending
on different the type and size of the event) or audio program
characteristics and regional style taste for subwoofer mixes.
BASSO Series models allow the user to choose the most adequate
subwoofer for any given situation from within a family of products with
common finish, design solutions and performance philosophy as well as
shared rigging and transport accessories.
BASSO15 is a 15" bass-reflex subwoofer with a very compact design and
excellent power-density that make this loudspeaker a versatile tool for
installed sound reinforcement and portable FOH applications.
SYSTEM CONFIGURATION AND SETTINGS
BASSO15 back panel is fitted with a pair of Neutrik NL-4 connectors in
parallel for straightforward, flexible installation setup.
NL-4 PINOUT:
+/- 1
Subwoofer Signal
+/- 2
Parallel Signal
QuickStart Guide
BASSO15
INPUT
LINK
NL-4 PINOUT
Subwoofer Signal
Parallel Signal
1000W RMS
8 Ω
28 kg
Designed, engineered and manufactured
by IDEA in Cedeira (Galicia)
This product must be installed and/or
PRODUCT OF EUROPE
operated by qualified professionals
Made in Spain
following safe practices and local
regulations. Refer to the owner's
manual for instructions and optional
accessories.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Idea BASSO15
Summary of Contents for Idea BASSO15
- Page 1 FOH applications. SYSTEM CONFIGURATION AND SETTINGS BASSO15 back panel is fitted with a pair of Neutrik NL-4 connectors in BASSO15 parallel for straightforward, flexible installation setup.
- Page 2 +/-2 Link Cabinet Construction 15 mm Birch Plywood Grille 1,5 mm perforated weatherised steel with protective foam Finish Durable IDEA proprietary Aquaforce paint coating process Handles 2 integrated handles Feet/Skates 4 rubber feet Installation 36 mm Pole mount socket Accessories 35 mm Pole (K&M-21336)
- Page 3 • IDEA declines any responsibility from misuse that may result in malfunction or damage of the equipment. WARRANTY • All IDEA products are guaranteed against any manufacturing defect for a period of 5 years from date of purchase for acoustical parts and 2 years from date of purchase for electronic devices.
- Page 4 For further information scan the QR Code or refer to the following web address: www.ideaproaudio.com/product-detail/basso15 IDEA is always in pursuit of better performance, greater reliability and design features. Technical specifications and minor finish details may vary without notice in order to improve our products.
