Idea BASSO18-A Quick Start Manual

Idea BASSO18-A Quick Start Manual

18? direct radiation multipurpose active subwoofer

Advertisement

BASSO18-A
18˝ High Performance Direct Radiation Active Subwoofer
BASSO Series models allow the user to choose the most adequate subwoofer
for any given situation from within a family of products with common finish,
design solutions and performance philosophy as well as shared rigging and
transport accessories.
BASSO18-A is an active 1.5 KW single 18˝ direct radiation subwoofer delivering
a very natural, linear response in the VLF range from 30 Hz to 110 Hz.
Built with 18" Premium birch plywood and fitted with a 2-mm steel grille,
this medium format medium format cabinet is finished with IDEA Aquaforce
weatherized coating to endure life on the road or stylishly integrate in any
installation.
BASSO18-A seamlessly matches with 2-way loudspeakers in LUA and EXO
Series maximizing the high-density performance of these systems for a
wide range of portable, mobile and install professional sound reinforcement
applications, from high power club sound systems and medium size live music
events to rental and touring companies.
Optional rigging accessories allow for BASSO18-A to be stacked and flown
with RF-600 rigging frame.

DSP AND POWER MODULE

BASSO18-A features an integrated 1500 W Class-D power module equipped with PowerCON 32A Mains connectors and XLR balanced
audio signal connectors allowing for a simple, straightforward power and audio linking of the array elements.
Mains IN
Mains OUT

PRELOADED SELECTABLE PRESETS

The 24-bit high-resolution integrated DSP board allows for easy
access to four preloaded presets, just toggling the press-button
PRESET SELECT in the back control pannel. The active preset will
be indicated by the active led above its number.
Signal OUT: balanced audio XLR
LINK
USB Port
Signal IN: balanced audio XLR
INPUT
PRESET 1: LPF @100 Hz
PRESET 2: LPF @120 Hz
PRESET 3: LPF @150 Hz
PRESET 4: LPF @180 Hz
QuickStart Guide
PRESET 1
PRESET 2
PRESET 3
PRESET 4
Active Preset
PRESET
SELECT
Preset Select toggle
Gain level knob
GAIN
Activity leds
6
+
-
STATUS
TEMP
CLIP
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BASSO18-A and is the answer not in the manual?

Questions and answers

Summary of Contents for Idea BASSO18-A

  • Page 1 RF-600 rigging frame. DSP AND POWER MODULE BASSO18-A features an integrated 1500 W Class-D power module equipped with PowerCON 32A Mains connectors and XLR balanced audio signal connectors allowing for a simple, straightforward power and audio linking of the array elements.
  • Page 2 2 x Neutrik PowerCON® Cabinet Construction 18 mm Plywood Grille 2 mm perforated weatherised steel with protective foam Finish Durable IDEA proprietary Aquaforce paint coating process Handles 4 integrated handles Feet/Skates 4 rubber feet Installation Top 36 mm Pole-mount socket Accessories 35 mm Pole (K&M-21338)
  • Page 3 • IDEA declines any responsibility from misuse that may result in malfunction or damage of the equipment. WARRANTY • All IDEA products are guaranteed against any manufacturing defect for a period of 5 years from date of purchase for acoustical parts and 2 years from date of purchase for electronic devices.
  • Page 4 For further information scan the QR Code or refer to the following web address: www.ideaproaudio.com/basso18-a IDEA is always in pursuit of better performance, greater reliability and design features. Technical specifications and minor finish details may vary without notice in order to improve our products.
