- Page 1 Tumble dryer WT43H0C5DN User manual and installation instructions Register your product on My Siemens and discover exclusive services and offers. siemens-home.bsh-group.com/welcome The future moving in. Siemens Home Appliances...
-
Page 2: Table Of Contents
Futher information and explanations are available online: Table of contents 1 Safety .......... 4 9 Programmes ....... 21 1.1 General information.... 4 9.1 Automatic programmes.... 21 1.2 Intended use....... 4 9.2 Timed programmes .... 22 1.3 Restriction on user group... 4 10 Accessories...... 23 1.4 Safe installation ...... 5 1.5 Safe use ........ 7 11 Laundry........ - Page 3 15.2 Base unit ........ 31 15.3 Moisture sensor...... 33 16 Troubleshooting....... 35 17 Transportation, storage and disposal ........ 39 17.1 Preparing the appliance for transportation ...... 39 17.2 Disposing of old appliance .. 39 18 Customer Service..... 40 18.1 Product number (E-Nr.) and production number (FD).. 40 19 Consumption values....
-
Page 4: Safety
en Safety 1 Safety Observe the following safety instructions. 1.1 General information ¡ Read this instruction manual carefully. ¡ Keep the instruction manual and the product information safe for future reference or for the next owner. ¡ Do not connect the appliance if it has been damaged in transit. 1.2 Intended use Only use this appliance: ¡... -
Page 5: Safe Installation
Safety en 1.4 Safe installation Take note of the safety instructions when installing the appliance. WARNING ‒ Risk of electric shock! Incorrect installation is dangerous. ▶ Connect and operate the appliance only in accordance with the specifications on the rating plate. ▶ Connect the appliance to a power supply with alternating cur- rent only via a properly installed socket with earthing. - Page 6 en Safety ▶ If the power cord is too short and a longer one is not available, please contact an electrician to have the domestic installation adapted. WARNING ‒ Risk of injury! The high weight of the appliance may result in injury when lifted. ▶...
-
Page 7: Safe Use
Safety en CAUTION ‒ Risk of cutting! Touching sharp edges on the appliance may lead to cuts. ▶ Do not touch the sharp edges on the appliance. ▶ Wear protective gloves when installing and transporting the ap- pliance. 1.5 Safe use WARNING ‒ Risk of electric shock! If the appliance or the power cord is damaged, this is dangerous. - Page 8 en Safety WARNING ‒ Risk of explosion! If there is coal dust or flour in the air around the appliance, this may cause an explosion. ▶ Keep the area around the appliance clean during operation. WARNING ‒ Risk of poisoning! Condensation water from this appliance is not suitable for drinking and may be contaminated with fluff.
-
Page 9: Safe Cleaning And Maintenance
Safety en ▶ Rinse the laundry thoroughly with warm water and detergent be- fore drying it in the machine. ▶ Do not use the appliance if industrial chemicals have been used to clean the laundry beforehand. WARNING ‒ Risk of fire! If drying is interrupted early, the laundry is not cooled sufficiently and may ignite. - Page 10 en Safety An ingress of moisture can cause an electric shock. ▶ Do not use steam- or high-pressure cleaners, hoses or sprays to clean the appliance. WARNING ‒ Risk of injury! The use of non-original spare parts and non-original accessories is dangerous. ▶ Only use the manufacturer's original spare parts and original ac- cessories.
-
Page 11: Preventing Material Damage
Preventing material damage en Foam and foam rubber may deform 2 Preventing material or melt during the drying process. Do not dry laundry that contains damage ▶ foam or foam rubber. Unsuitable cleaning products may Follow these instructions to avoid ma- damage the surfaces of the appli- terial damage and damage to the ap- ance. -
Page 12: Energy Saving Mode
en Installation and connection Spin the laundry in the washing ma- 4 Installation and con- chine before drying. nection a If the laundry is excessively damp, this extends the programme dura- tion and increases energy con- 4.1 Unpacking the appliance sumption. ATTENTION! Observe the programme's maximum Objects remaining in the drum that load capacity. -
Page 13: Requirements For The Install- Ation Location
Installation and connection en Replace the accessories in ques- ▶ Installation loca- Requirements tion before operating the appli- tion ance. On the floor Place the appli- → "Accessories", Page 23 ance on a clean, level and firm Included with Description surface. the appliance Align the appli- Tumble dryer ance... -
Page 14: Aligning The Appliance
en Installation and connection 4.4 Aligning the appliance In order to reduce vibrations and noises, align the appliance correctly. To align the appliance, turn the ap- ▶ pliance feet. Check that the appli- ance is level using a spirit level. All appliance feet must stand firmly on the ground. -
Page 15: Familiarising Yourself With Your Appliance
Familiarising yourself with your appliance en 5 Familiarising yourself with your appliance 5.1 Appliance You can find an overview of the parts of your appliance here. On certain models, specific details such as the colour and shape may differ from those pictured. Ventilation opening Door Maintenance flap on the base Condensation container... -
Page 16: Control Panel
en Familiarising yourself with your appliance 5.2 Control panel You can use the control panel to configure all functions of your appliance and to obtain information about the operating status. Programmes → Page 21 Programme selector → Page 24 Display → Page 17 Buttons → Page 19... -
Page 17: Display
Display en 6 Display The display shows the current settings, options or relevant information. Display Designation Description 0:40 Programme dura- Approximate expected programme dura- tion/programme tion or programme time remaining. time remaining 1:27 Timed programme The timed programme is set. → "Timed programmes", Page 22 "Ready in"... -
Page 18: Dryness Level
en Display Display Designation Description Fluff filter Clean the fluff filter → Page 25. Filter system on Clean the filter system on the base unit the base unit → Page 27. Drying Programme status Dryness level: Iron Programme status Dryness level: Programme status Cupboard Dry ... - Page 19 Buttons en 7 Buttons Below is an overview of the buttons and their setting options. Button Selection Description ¡ Start Start, cancel or pause the programme. ¡ Cancel ¡ Pause 3 sek. ¡ Activate Activate or deactivate the childproof lock. ¡...
-
Page 20: Changing The Dryness Level
en Dryness level 8 Dryness level Each automatic programme has a specified dryness level. The dryness level defines how dry or damp your laundry is after the programme ends. Dryness level Laundry Drying result Cupboard Dry Multi-layered, thick laundry The laundry is dry. Plus that does not dry readily. -
Page 21: Programmes
Programmes en 9 Programmes You can dry your fabrics using either an automatic programme or a timed pro- gramme. 9.1 Automatic programmes Automatic programmes are pro- Tips grammes in which humidity sensors ¡ Select the dryness level according measure the residual moisture in the to the type of fabric or the desired laundry during the drying cycle. -
Page 22: Timed Programmes
en Programmes Programme Description Max. load (kg) Once the laundry is dry, iron it or hang it up. The residual moisture is then distrib- uted evenly. Super 40' Dry items made of synthetics and light cotton. Towels Dry hard-wearing, heat-resistant towels and dressing gowns made of cotton or linen. - Page 23 Accessories en 10 Accessories Use original accessories. These have been made especially for your appli- ance. Note: Some accessories are avail- able in other colours. Contact → "Customer Service", Page 40. Order number Connection kit To save space, stack the WZ11410 appliance on a suitable washing machine of the same width and depth and that is from the...
-
Page 24: Preparing The Laundry
QR code in the table of scanning the QR code in the table of contents or on siemens-home.bsh- contents or on siemens-home.bsh- group.com . group.com . -
Page 25: Starting The Programme
operation en Press . 12.4 Starting the programme Requirement: A programme is set. 12.7 Cancelling the pro- → "Setting a programme", Page 24 gramme Press . ▶ Press . a The display shows the programme Open the appliance door. duration or the "Ready in" time. Remove the laundry. - Page 26 en operation Remove the fluff from the door. Disconnect the two-part fluff filter. Remove the two-part fluff filter. Open the two fluff filters. Remove the fluff from the recess. Remove the fluff. Ensure that no fluff falls into the air channel.
-
Page 27: Filter System On The Base Unit
operation en Clean the two fluff filters thoroughly 12.11 Filter system on the under warm, running water and base unit then dry them off. During drying, fluff from the laundry is collected in the base unit's filter sys- tem. The filter system protects the ap- pliance from fluff. -
Page 28: Condensation Container
en operation Use a soft brush to clean the heat Push the filter mat onto the retain- exchanger cover. ers. Make sure that you remove all dirt Ensure that the cleaned filter mat from the seal. is not deformed, damaged or in- verted when you push it onto the Clean the filter mat thoroughly un- retainers. -
Page 29: Childproof Lock
Childproof lock en Pull out the condensation con- Push the condensation container ▶ tainer, keeping it level. in as far as it will go. Empty the condensation container. 13 Childproof lock Secure your appliance against being operated unintentionally using the controls. 13.1 Activating the childproof lock Press and hold the two ... -
Page 30: Basic Settings
en Basic settings 14 Basic settings You can configure the basic settings for your appliance to meet your needs. 14.1 Overview of the basic settings Basic setting Programme Value Description position End signal 0 (off) Set the volume of the signal at the 1 (quiet) end of the programme. -
Page 31: Changing The Basic Set- Tings
To keep your appliance working effi- ciently for a long time, it is important to clean and maintain it carefully. Note: You can find further information in the digital instruction manual by scanning the QR code in the table of contents or on siemens-home.bsh- group.com . - Page 32 en Cleaning and servicing Open the maintenance flap. Cleaning the base unit You can remove any visible dirt in the base unit. CAUTION Risk of cutting! Touching sharp edges on the heat exchanger may lead to cuts. Do not touch the fins on the heat ▶...
-
Page 33: Moisture Sensor
Cleaning and servicing en Clean the opening with a soft, Close the maintenance flap. damp cloth. 15.3 Moisture sensor Close the base unit → Page 33. The moisture sensor in this appliance Closing the base unit measures how damp the laundry is Requirement: The base unit is open. during the drying cycle. - Page 34 en Cleaning and servicing Clean the moisture sensor with a sponge.
-
Page 35: Troubleshooting
Troubleshooting en 16 Troubleshooting You can rectify minor faults on your appliance yourself. Read the troubleshoot- ing information before contacting after-sales service. This will avoid unneces- sary costs. WARNING Risk of electric shock! Incorrect repairs are dangerous. Repairs to the appliance should only be carried out by trained specialist ▶... - Page 36 en Troubleshooting Fault Cause and troubleshooting Creasing. Set the suitable programme for the type of fabric. ▶ → "Programmes", Page 21 Easy-Care fabrics are dried for too long. → "Changing the dryness level", Page 20. ▶ → "Adjusting the dryness level", Page 20. ▶ Anti-Crease not activated. Activate the Anti-Crease function. ▶...
- Page 37 Troubleshooting en Fault Cause and troubleshooting The length of the pro- The programme operation is optimised electronically. gramme changes dur- This may change the programme duration. ing the drying cycle. Not a fault – no action required. ▶ Pumping noise. Condensation pump active. Not a fault –...
- Page 38 en Troubleshooting Fault Cause and troubleshooting Water is leaking from The lever for the heat exchanger cover is not closed the appliance. correctly. Ensure that the lever for the heat exchanger cover ▶ is closed correctly. → "Closing the base unit", Page 33 The laundry is too Unsuitable programme for the type of fabric.
-
Page 39: Transportation, Storage And Disposal
Transportation, storage and disposal en Insert the condensation container 17 Transportation, stor- → Page 29. age and disposal Disconnect the appliance's mains plug from the power supply. a The appliance is now ready to be 17.1 Preparing the appliance transported. for transportation 17.2 Disposing of old appli- ATTENTION! ance If the appliance is operated immedi-... -
Page 40: Customer Service
en Customer Service Information about current disposal 18.1 Product number (E-Nr.) methods are available from your and production number specialist dealer or local authority. (FD) This appliance is la- You can find the product number (E- belled in accordance Nr.) and the production number (FD) with European Directive on the appliance's rating plate. -
Page 41: Consumption Values
Consumption values en 19 Consumption values The Cotton Eco programme The actual values may deviate from (denoted by the arrow symbol) is the indicated values depending on suitable for drying cotton laundry with the type of fabric, composition of a normal dampness level, and is the laundry to be dried, residual moisture most efficient programme for drying in the fabric, set degree of dryness,... -
Page 42: Technical Data
en Technical data Programme Final Load Spin Initial Pro- Energy mois- (kg) speed mois- gramm con- ture (rpm) ture e dura- sump- level level tion tion (h:min) (kWh/ cycle) Easy Care Cup- 1:14 0,65 board Dry Easy Care Cup- 1:29 0,79 board Dry You can find more information about... - Page 44 Valid within Great Britain: Imported to Great Britain by BSH Home Appliances Ltd. Grand Union House Old Wolverton Road Wolverton, Milton Keynes MK12 5PT United Kingdom Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG *9001726655* 9001726655 (020518)
