- Page 1 PCD-41B Owner’s Manual Take the time to read through this owner’s manual. Familiarity with installation and operation procedures will help you obtain the best Performance from your new CD-receiver. Page -...
-
Page 2: Table Of Contents
CONTENTS CONTENTS ------------------------------------------------------------------------------------------- ---01 PRECAUTION --------------------------------------------------------- ---------------------- ACCESSORY ---------------------------------------------------------------------------------- INSTALLATION (UN-INSTALLATION) ------------------------------------------------ --- W IRING DIAGRAM ------------------------------------------------------------- ---------- CONTROL PANEL ---------------------------------- ----------------------------------- ---- I NNER PANEL -- -- --- -- --- -- -- --- -- --- -- -- --- -- --- -- -- --- -- --- -- --- -- --- -- -- --- -- --- --- - BASIC OPERATION ------------------------------------------------------------------------------------07 POW ER ----- ----- ------ ----- ------ ----- ----- ------ ----- ------ ------ ----- ------ ----- ------ -- 07... -
Page 3: Precaution
PRECAUTION This unit is designed and manufactured with consideration of user’s safety, however any improper use or operation may result in a certain hazard or misuse. So it is highly recommended to read this manual thoroughly and adhere to the following precaution. SAFETY PRECAUTION ... -
Page 4: Accessory
ACCESSORY Package will include in the following accessories for installation and operation the unit. Installation Accessory Release Key Screw Bolt Screw Nut Mount Strap Remote Control Cable Panel carry case External mic Page -... -
Page 5: Installation/Un-Installation
Installation/Un-Installation First complete the electrical connections, and then check them for correctness. Installation/ Un-installation Page -... -
Page 6: Wiring Diagram
WIRING DIAGRAM 1、Purple：Right Rear + 2、Gray：Right Front + 3、White：Left Front + 4、Green：Left Rear + 5、Blue：Auto Antenna 6、Yellow:ACC B+(Fuse 15A) 7、Purple/Black:Right Rear - 8、Gray/Black：Right Front - 9、White/Black：Left Front - 10、Green/Black：Left Rear - 11、Red：Connect to Ignition Key switch 12V DC(Fuse 1A) 12、Black:ACC B- 13、Red RCA:Line out-Right Front 14、Red RCA:Line out-Right Rear 15、White RCA:Line out-Left Front... -
Page 7: Control Panel
CONTROL PANEL INNER PANEL 1 POWER (MODE) 3 T-DN 4 T-UP 5 DISC SLOT 6 LCD DISPLAY 7 EJ 8 AMS 9 OPEN 10 SEL 11 VOL (BAND) 13 MO/ST 14 LOC 15 IR SENSOR 16 1/PAUSE/PLAY 17 2/INT 18 3/RPT 19 4/RDM 20 5 21 6... -
Page 8: Basic Operation
BASIC OPERATION 1.POWER Press [POWER] button to turn on the unit.Press again to turn off the unit. MODE Short press to change mode in the sequence of TUNER -> (* CD) -> (* SD) -> (*USB) -> AUX -> TUNER In BLUETOOTH mode, press to reject a coming call or hang up while calling. -
Page 9: Open
9.OPEN Press open button to show the inner panel. 10.SEL Multimedia and select button, and to choose hours/minutes. In the radio state, press it to enter the SOUND SETTING menu：BAS-> TRE -> BAL -> FAD -> LOUD -> EQ(CLASSIC->POP ->ROCK -> EQ OFF)->DX->STEREO->VOL-> BAS In the CD/USB/SD state, press it to enter the SOUND SETTING menu：BAS->... -
Page 10: Clk
22.CLK Clock time display.Press button to show time, long press and rotate vol button to adjust clock time. 23.MUTE Short press to mute on, short press again to mute off. 24. AUX IN AUX IN socket 25. USB SOCKET Insert a USB Flash Storage Device and music starts to play automatically. LCD display. Support Music File Format: MP3, WMA Files 26. -
Page 11: Bluetooth Section
1.Power on 2.Open the Bluetooth of mobile phone→Search for Bluetooth devices→Choose a name for the “SOUNDSTREAM” Bluetooth devices→Connect the Bluetooth(The first time use when you need to enter the passcode “0000” to connect Bluetooth.) 3.After pairing is successful, the machine displays BTON once, and then transferred to the current mode, when operating the phone call with music or a call comes in, the machine will automatically turn Bluetooth mode. -
Page 12: Remote Control
SPECIFICATION FM TUNER Frequency Range ----------------------------------------------------------------. 87.5 ~ 107.9MHZ Usable Sensitivity ------------------------ -------------------------- -------------- 18 dBuV Stereo Separation --------------------------------------------------- --------------------------- 30 dB AM (MW) TUNER Frequency Range -------------------------------------------------------------- 530 ~ 1710KHz U s a b l e S e n si t i vi t y - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3 5 d B u V ELECTRIC Power Supply ------------------------------------------------------------------------... -
Page 13: Specification & Feature
TROUBLSHOOTING Symptom Cause Remedy Replace with a fuse of the same rating Power does Fuse is blown amperage. If the fuse blows again, not turn on. consult your local retailer. (No sound is produced.) Incorrect wiring Consult your local retailer. Wiring for amplifier Refer to the unit wiring diagram to General... -
Page 14: Troubleshooting
FCC Caution. § 15.19 Labelling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
