Page 1
Warranty information contained in this User Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.
Page 2
As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding the world’s expectations for technological evolution, innovation, and simplicity. At ViewSonic®, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic® product you have chosen will serve you well.
Safety Precautions Please read the following Safety Precautions before you start using the device. • Keep this user guide in a safe place for later reference. • Read all warnings and follow all instructions. • Sit at least 18" (45 cm) away from the device. •...
Page 4
• If smoke, an abnormal noise, or a strange odor is present, immediately turn the device off and call your dealer or ViewSonic®. It is dangerous to continue using the device. •...
Page 5
• Fastening the display to a wall or fixed object using cordage or other restraining devices can help support the weight of the display in order to prevent the display from falling over. Hole pattern Interface Pad Pad Hole Screw Specification & Quantity (W x H) (W x H x D) M4 x 10 mm...
Introduction Package Contents • Monitor • Power cord • Video cable • Quick start guide NOTE: The power cord and video cables included in your package may vary depending on your country. Please contact your local reseller for more information.
Product Overview Front View Display screen Rear View Joy Key Security Slot Power Button Type-C 1. AC IN 2. HDMI 3. DisplayPort 4. USB Type-C 5. Audio Out 6. USB Upstream 7. USB 8. Micro USB Downstream NOTE: For more information about the Joy Key and its functions, refer to “Hot Keys”.
Initial Setup This section provides detailed instructions for setting up your monitor. Installing the Stand 1. Place the monitor on a flat, stable surface with the screen facing down. 2. Align and slide the upper hooks of the monitor stand into the stand mounting slots.
Page 11
3. Lift the device into its upright position on a flat, stable surface. NOTE: Always place the device on a flat, stable surface. Failure to do so may cause the device to fall and damage the device and/or result in personal injury.
Refer to the table below for the standard dimensions for wall mount kits. NOTE: For use only with a UL certified wall mount kit/bracket. To obtain a wall- mounting kit or height adjustment base, contact ViewSonic® or your local dealer.
Page 13
5. Attach the mounting bracket to the VESA mounting holes at the rear of the monitor. Then secure it with four (4) screws (M4 x 10 mm). 100 mm 6. Follow the instructions that come with the wall mounting kit to mount the monitor onto the wall.
Using the Security Slot To help prevent the device from being stolen, use a security slot locking device to secure the device to a fixed object. Additionally, fastening the monitor to a wall or fixed object using a security cable can help support the weight of the monitor in order to prevent the monitor from falling over.
Making Connections This section guides you on how to connect the monitor with other equipment. Connecting to Power 1. Connect the power cord to the AC IN jack at the rear of the device. 2. Connect the power cord plug to a power outlet.
Connecting External Devices HDMI Connection Connect one end of an HDMI cable to the HDMI port of your monitor. Then connect the other end of the cable to the HDMI port of your computer. NOTE: The monitor is equipped with two HDMI 2.0 ports. HDMI...
DisplayPort Connection Connect one end of a DisplayPort cable to the DisplayPort port. Then connect the other end of the cable to the DisplayPort or mini DP port of your computer. NOTE: To connect the monitor to the Thunderbolt port (v. 1&2) on your Mac, connect the mini DP end of the “mini DP to DisplayPort cable”...
USB Connection Connect one end of a USB cable to a USB port of the monitor. Then connect the other end of the cable to a USB port of your computer. NOTE: The monitor supports four (4) types of USB ports. When making the connection(s), observe the following guidelines: •...
Audio Connection Plug the audio jack of the ear-/headphones into the Audio Out port of the monitor. Additionally, you can connect the monitor to a sound bar using an audio cable. NOTE: The monitor is also equipped with dual speakers.
Using the Monitor Adjusting the Viewing Angle For optimal viewing, you can adjust the viewing angle using any of the following methods: Height Adjustment Lower or raise the monitor to the desired height (0 to 130 mm). NOTE: When adjusting, press down firmly along the adjustment track holding the monitor with both hands on the side.
Tilt Angle Adjustment Tilt the monitor forwards or backwards to the desired viewing angle (-5˚ to 21˚). NOTE: When adjusting, support the stand firmly with one hand while tilting the monitor forwards or backwards with the other hand. Screen Orientation Adjustment (Monitor Pivot) 1.
Page 22
2. Rotate the monitor 90° clockwise or counter clockwise from landscape to portrait orientation. NOTE: • When adjusting, make sure to hold both sides of your monitor firmly with both hands. • If using the Auto Pivot function, the system can detect the screen orientation automatically.
Turning the Device On/Off 3. Plug the power cord into a power outlet. 4. Press the Power button to turn on the monitor. 5. To turn the monitor off, press the Power button again. NOTE: The monitor will still consume some power as long as the power cord is connected to the power outlet.
Move the joy key to activate the Startup Menu. NOTE: Follow the key guide that appears on the screen to select the option or make adjustments. Main Menu Enter the On-Screen Display (OSD) Menu. DisplayPort 1.2 3840 x 2160 @ 60Hz VP2786-4K...
Page 26
Color Mode Select one of the preset standard color settings. ViewMode Select one of the preset display settings. Brightness Adjust the brightness level.
Page 27
Input Select the input source. Volume Adjust the volume settings. NOTE: Move the joy key to return to the previous menu.
Hot Keys When the On-Screen Display (OSD) Menu is off, you can quickly access special functions by using the Joy Key. Description Press and hold the key for 5 seconds to activate/deactivate LED lighting. Backstage Lighting Press and hold the key to lock/unlock the OSD Menu. When the menu appears on the screen, continue holding the key for 10 seconds to lock/unlock the OSD Menu.
Page 29
Description Power Press and hold the key to lock/unlock the button. When the menu appears on the screen, continue holding the key for 10 seconds to lock/unlock the Power button. Power Lock/Unlocked Power Lock/Unlock Locking Power Button Locking Power Button Press and hold for 5 sec Press and hold for 10s to lock power...
Page 30
Description Press and hold the key for 10 seconds to activate/deactivate Ultra Fast. Boot Up Screen On/Off Ultra Fast Press to turn on...
Startup Menu. Then navigate to Main Menu and press the l key to display the OSD Menu. DisplayPort 1.2 3840 x 2160 @ 60Hz VP2786-4K 2. Move the Joy Key to select the main menu. Then press the l key to enter the selected menu.
Page 32
3. Move the Joy Key to select the desired menu option. Then press the l key to enter the sub-menu. 3840 x 2160 @ 60Hz VP2786-4K 4. Move the Joy Key to adjust/select the setting. Then press the l key to confirm.
On-Screen Display (OSD) Menu Tree Main Menu Sub-menu Menu Option Auto RGB (Full Range) Color Format RGB (Limited Range) DisplayPort YUV (Full Range) YUV (Limited Range) DisplayPort 1.2 Auto RGB (Full Range) Color Format RGB (Limited Range) HDMI 1 YUV (Full Range) YUV (Limited Range) HDMI 2.0 Auto...
Page 34
Main Menu Sub-menu Menu Option Brightness (-/+, 0~100) 9300K 7500K Color 6500K Temperature 6300K 5000K Gamma DCI-P3 Sharpness (-/+, 0~100) Aspect Ratio Full Screen Uniformity Recall Color Mode Brightness (-/+, 0~100) 9300K 7500K Color 6500K Temperature 6300K 5000K Gamma sRGB Sharpness (-/+, 0~100) Aspect Ratio...
Page 35
Main Menu Sub-menu Menu Option Brightness (-/+, 0~100) 9300K 7500K Color 6500K Temperature 6300K 5000K Gamma REC709 Color Mode Sharpness (-/+, 0~100) Aspect Ratio Full Screen Uniformity Recall Sharpness (-/+, 0~100) DICOM-SIM Aspect Ratio Full Screen Recall...
Page 36
Main Menu Sub-menu Menu Option Contrast (-/+, 0~100) Brightness (-/+, 0~100) 9300K 7500K Color 6500K Temperature 6300K 5000K Gamma (-/+, Advanced DCR 0/25/50/75/100) (-/+, 0~100) Gain Green (-/+, 0~100) Blue (-/+, 0~100) Color Mode User (-/+, 0~100) Offset Green (-/+, 0~100) Blue (-/+, 0~100) (-/+, 0~100)
Page 37
Main Menu Sub-menu Menu Option Brightness (-/+, 0~100) Result Remind Schedule Color Calibration Hour Notice Counter Hour Recall CAL1/CAL2/ Sharpness (-/+, 0~100) CAL3 Aspect Ratio Color Mode Full Screen Uniformity Recall Standard HDR_M HDR_H Smooth...
Page 38
Main Menu Sub-menu Menu Option Ultra Clear (-/+, 0~4) Advanced- (-/+, 0~100) CAD/CAM Sharpness Advanced- (-/+, 1.8~2.6) Gamma Ultra Clear (-/+, 0~4) Advanced- (-/+, 0~100) Video Edit Sharpness Advanced- (-/+, 1.8~2.6) Gamma Ultra Clear (-/+, 0~4) Advanced- ViewMode Animation (-/+, 0~100) Sharpness Black Stabilization (-/+, 0~10) Ultra Clear...
Page 39
Main Menu Sub-menu Menu Option English Français Deutsch Español Italiano Suomi Language Select Русский Türkçe 日本語 한국어 繁體中文 简体中文 Adaptive Sync Resolution Notice PureXP™ Setup Menu Information OSD Timeout (-/+, 5/15/30/60) Background Auto 0° OSD Pivot +90° -90° 180° Power Indicator Auto Power Off 30 minutes 45 minutes...
Page 40
Main Menu Sub-menu Menu Option DisplayPort HDMI 1 Left Source Select HDMI 2 Type C PBP Left-Right DisplayPort HDMI 1 Right Source Select HDMI 2 Type C Swap DisplayPort HDMI 1 PIP Source Select HDMI 2 Type C PIP H. Position PIP Position PIP V.
Page 41
Main Menu Sub-menu Menu Option Standard Optimize ECO Mode Conserve Energy Saving Overscan Standard Response Time Advanced Ultra Fast Setup Menu USB Charging Level 1 Level 2 Backstage Lighting Level 3 Burn-in Eraser DDC/CI Rename All Recall...
Input. Then press the l key to enter the Input menu. DisplayPort 1.2 3840 x 2160 @ 60Hz VP2786-4K 3. Move the Joy Key to select the desired input source. Then press the l key to confirm the selection.
Page 43
Color Mode. Then press the l key to enter the Color Mode menu. 3840 x 2160 @ 60Hz VP2786-4K 3. Move the Joy Key to select the desired option. Then press the l key to enter its sub-menu.
Page 44
2. Move the Joy Key to select ViewMode. Then press the l key to enter the ViewMode menu. 3840 x 2160 @ 60Hz VP2786-4K 3. Move the Joy Key to select the desired option. Then press the l key to enter its sub-menu.
Page 45
Audio Adjust. Then press the l key to enter the Audio Adjust menu. 3840 x 2160 @ 60Hz VP2786-4K 3. Move the Joy Key to select the desired option. Then press the l key to enter its sub-menu.
Page 46
Setup Menu. Then press the l key to enter the Setup Menu menu. 3840 x 2160 @ 60Hz VP2786-4K 3. Move the Joy Key to select the desired option. Then press the l key to enter its sub-menu.
Page 47
Menu Option Description Set the OSD Menu orientation. • Auto: With the built-in G sensor, the OSD Menu can automatically pivot when the monitor is positioned vertically. OSD Pivot • 0°: Sets the OSD Menu without a pivot. • +90°: Sets the OSD Menu with a +90° pivot. •...
Page 48
Menu Option Description Adjust the response time, creating smooth images without streaking, blurring or ghosting. A low response time is Response Time perfect for the most graphic-intense gaming, and provides amazing visual quality while watching sports or action movies. USB Charging Enable/disable usb charging.
3. Move the Joy Key to select HDR. Then press the l key to enter its sub- menu. 4. Move the Joy Key to select one of the options . Then press the l key to confirm. 3840 x 2160 @ 60Hz VP2786-4K...
The KVM function allows the user to control two computers connected to the same monitor from a single keyboard and mouse. NOTE: Only applicable in PBP (Picture-by-Picture) mode. To connect the two computers to the monitor: 1. Connect one end of the USB Type C cable to the USB Type C port of the monitor. Then connect the other end of the cable to the USB Type C port of the notebook.
Page 51
4. Move the Joy Key to select PBP Left-Right. Then press the l key to enable PBP mode. 3840 x 2160 @ 60Hz VP2786-4K To activate the KVM function: 1. Press and hold the key for two (2) seconds to activate the KVM function.
Auto Pivot With the Auto Pivot function, the monitor can detect the image display and adjust the image’s orientation on the screen automatically when pivoting the screen vertically or horizontally. NOTE: The Auto Pivot function uses DDC/CI to communicate with the monitor. Before applying the Auto Pivot function, please make sure the DDC/CI setting is set to On.
To ensure long-term color accuracy, some specific models support the hardware color calibration function. The Colorbration+ application installation file can be found at: http://color.viewsonic.com/support/software/. Standard monitor packing does not include the color sensor, which the Colorbration+ application needs for the calibration process.
Dual Color The monitor comes with a dual color engine to display two different color settings in PIP (Picture-in-Picture) or PBP mode. You can set different color presets in both windows (Main Window and Secondary Window). Main Window Secondary Window NOTE: ...
Multi-Picture. Then press the l key to enter its sub-menu. 4. Move the Joy Key to select PBP Left-Right or PIP. Then press the l key to enter the selected mode. 3840 x 2160 @ 60Hz VP2786-4K 55 55...
PBP (Picture-by-Picture) Left Window Right Window PBP Left-Right NOTE: To display full-sized images in the windows, please adjust the screen resolution to 1920 x 1080 (PBP Left-Right). To configure PBP: 1. Move the Joy Key to display the Startup Menu. Then navigate to Main Menu and press the l key to display the OSD Menu.
PIP (Picture-in-Picture) Main Window Inset Window To configure PIP: 1. Move the Joy Key to display the Startup Menu. Then navigate to Main Menu and press the l key to display the OSD Menu. 2. Move the Joy Key to select Setup Menu. Then press the l key to enter the Setup Menu menu.
Backstage Lighting With the Backstage Lighting function, the monitor can adjust the LED brightness to the optimal settings. To configure the Backstage Lighting settings: 1. Open the OSD Menu and select the Setup Menu menu. Then touch the l key to enter the menu.
To update the firmware: 1. Download and install the vDisplayManager application: https://color.viewsonic. com/support/software/. 2. Connect the USB Type B male cable (square with 2 cut corners) to the USB Type B port of your monitor.
Appendix Specifications Item Category Specifications IPS type, TFT Active Matrix 3840 x 2160 LCD, Type 0.1554 mm x 0.1554 mm pixel pitch Display Size 68.47 cm, 27" (27" viewable) Color Filter RGB vertical stripe Glass Surface Anti-Glare type, Hard Coating (3H) TMDS digital (100 Ω) Input Signal Video Sync...
Page 61
Item Category Specifications • 4096 x 2160 @ 24, 25, 30, 50, 60Hz • 3840 x 2160 @ 24, 25, 30, 60Hz • 3840 x 1080 @ 60Hz • 2560 x 1440 @ 60Hz • 2048 x 1152 @ 60Hz •...
Page 62
Do not set the graphics card in your computer to exceed these timing modes; doing so may result in permanent damage to the display. Please use the power adapter from ViewSonic® or an authorized source only. The test condition follows EEI standards.
This function, on some models, is disabled by default. Black Stabilization ViewSonic’s Black Stabilization provides heightened visibility and detail by brightening dark scenes. Blue Light Filter Adjusts the filter that blocks high-energy blue light for a more comfortable viewing experience.
Page 64
Color Adjust Provides several color adjustment modes to help adjust the color settings to fit the user’s needs. Color Range The monitor can detect the input signal color range automatically. You can manually change the color range options to fit the correct color range if the colors are not displayed correctly.
Page 65
Displays the timing mode (video signal input) coming from the graphics card in the computer, the LCD model number, the serial number, and the ViewSonic® website URL. See your graphics card’s user guide for instructions on changing the resolution and refresh rate (vertical frequency).
Page 66
Offset Adjusts black levels for red, green, and blue. The gain and offset functions allow users to control the white balance for the upmost control when manipulating contrast and dark scenes. OSD Pivot Sets the monitor OSD Menu display direction. Overscan Refers to a cropped image on your monitor’s screen.
Page 67
Sharpness Adjusts the picture quality of the monitor. ViewMode ViewSonic’s unique ViewMode feature offers “Game”, “Movie”, “Web”, “Text”, “MAC”, and “Mono” presets. These presets are specifically designed to deliver an optimized viewing experience for different screen applications. ViewScale Gamers have the ability to adjust the display size of the image on the...
• Connect the monitor to another computer. • If you have an older graphics card, contact ViewSonic® for a non-DDC adapter. • Adjust brightness and contrast settings via the OSD Screen image is too Menu. light or dark •...
Page 69
Problem or Issue Possible Solutions • Adjust the horizontal and vertical controls via the The screen isn’t OSD Menu. centered correctly • Check the Aspect Ratio. • Reset the monitor to factory settings. The screen appears • Make sure the “Blue Light Filter” is Off. yellow The OSD Menu •...
• ViewSonic® does not recommend the use of any ammonia or alcohol-based cleaners on the display screen or case. Some chemical cleaners have been reported to damage the screen and/or case of the monitor. • ViewSonic® will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners.
Regulatory and Service Information Compliance Information This section addresses all connected requirements and statements regarding regulations. Confirmed corresponding applications shall refer to nameplate labels and relevant markings on the unit. FCC Compliance Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
The following information is only for EU-member states: The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2012/19/EU (WEEE). The mark indicates the requirement NOT to dispose of the equipment as unsorted municipal waste, but use the return and collection systems according to local law.
Schedule 2 of the Rule. Product Disposal at End of Product Life ViewSonic® respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit the ViewSonic®...
VESA is a registered trademark of the Video Electronics Standards Association. DPMS, DisplayPort, and DDC are trademarks of VESA. Disclaimer: ViewSonic® Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product.
For technical support or product service, see the table below or contact your reseller. NOTE: You will need the product’s serial number. Country/ Region Website Country/ Region Website Asia Pacific & Africa Australia www.viewsonic.com/au/ Bangladesh www.viewsonic.com/bd/ www.viewsonic.com.cn www.viewsonic.com/hk/ 中国 (China) 香港 (繁體中文) Hong Kong (English) www.viewsonic.com/hk-en/ India www.viewsonic.com/in/...
How long the warranty is effective: ViewSonic® displays are warranted for between 1 and 3 years, depending on your country of purchase, for all parts including the light source and for all labor from the date of the first consumer purchase.
Page 77
(e) the serial number of the product. • Take or ship the product, freight prepaid, in the original container to an authorized ViewSonic® service center or ViewSonic®. • For additional information or the name of the nearest ViewSonic® service center, contact ViewSonic®. Limitation of implied warranties:...
Page 78
Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of...
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &...
Page 80
Exclusion of damages: ViewSonic®’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages...
Page 81
Name, address, of manufacturer and importers: México, Av. de la Palma #8 Piso 2 Despacho 203, Corporativo Interpalmas, Col. San Fernando Huixquilucan, Estado de México Tel: (55) 3605-1099 http://www.viewsonic.com/la/soporte/index.htm NÚMERO GRATIS DE ASISTENCIA TÉCNICA PARA TODO MÉXICO: 001.866.823.2004 Hermosillo: Villahermosa: Distribuciones y Servicios Computacionales SA de CV.
Page 82
C0 M91 Y72 K24 Process Color C0 M0 Y0 K100 Process Color C0 M91 Y72 K24 Process Color Pantone Black C Spot Color Pantone 187 C Spot Color...
