Lexmark 40G0450 Quick Reference

Quick Reference
Using the 2.4-inch display printer
model
Learning about the printer
Using the printer control panel
2
1
10
8 7
9
Use the To
1 Display
• View the printer status.
•
Set up and operate the printer.
2 Select button Submit changes made in the printer settings.
3 Arrow Scroll up and down or left and right.
buttons
4 Keypad Enter numbers, letters, or symbols.
Use the
5 Sleep button
6 Stop or
3
4
5
Cancel button
7 Back button
8 Home button
9 Indicator light Check the status of the printer.
10 USB port
Setting the paper size and type
6
1
From the printer control panel, navigate to:
> Settings >
Size/Type >
2
Press the up or down arrow button to select the tray or feeder, and
then press
3
Press the up or down arrow button to select the paper size, and
then press
4
Press the up or down arrow button to select the paper type, and
then press
To
Enable Sleep mode or Hibernate mode.
Do the following to wake the printer from Sleep
mode:
•
Press any hard button.
• Pull out Tray 1 or load paper in the
multipurpose feeder.
• Open a door or cover.
• Send a print job from the computer.
•
Perform a power‑on reset with the main
power switch.
•
Attach a device to the USB port on the
printer.
Stop all printer activity.
Return to the previous screen.
Go to the home screen.
Connect a flash drive to the printer.
Note: Only the front USB port supports flash
drives.
> Paper Menu > > Paper
.
.
to change the settings.
1
Configuring Universal paper settings
The Universal paper size is a user‑defined setting that lets you print on
paper sizes that are not preset in the printer menus.
Notes:
• The smallest supported Universal size is
70 x 127 mm (2.76 x 5 inches) for one‑sided printing and
105 x 148 mm (4.13 x 5.83 inches) for two‑sided (duplex)
printing.
• The largest supported Universal size is 216 x
356 mm (8.5 x 14 inches) for one‑sided and two‑sided printing.
•
When printing on paper less than 210 mm (8.3 inches) wide, the
printer may print at a reduced speed after a period of time to
ensure the best print performance.
From the printer control panel, navigate to:
> Settings > > Paper Menu >
Setup > > Units of Measure > > select unit of
measure >
Adjusting toner darkness
Using the Embedded Web Server
1
Open a Web browser, and then type the IP address of the printer
in the address field.
Notes:
• View the printer IP address in the TCP/IP section in the
Network/Ports menu. The IP address appears as four sets of
numbers separated by periods, such as 123.123.123.123.
• If you are using a proxy server, then temporarily disable it to
load the Web page correctly.
2 Click Settings > Print Settings > Quality Menu > Toner Darkness.
3 Adjust the toner darkness, and then click Submit.
Using the printer control panel
1
From the printer control panel, navigate to:
> Settings > > Print Settings >
Menu > > Toner Darkness
> Universal
> Quality
