Ezviz CSC1HC1E2 Quick Start Manual

Box Content

Internet Camera (x1)
Foam Sticker (x2)
The camera appearance is subject to the actual one you have bought.

Basics

Name Description
LED Indicator • Solid Red: Camera is starting up.
• Slow-flashing Red: Wi-Fi connection has failed.
• Fast-flashing Red: Device exception (e.g. microSD card error).
• Solid Blue: Video is being viewed or played back in EZVIZ App.
• Fast-flashing Blue: Camera is ready for the Wi-Fi connection.
• Slow-flashing Blue: Camera is running properly.
microSD Card • microSD Card should be purchased separately.
• Initialize the card in the EZVIZ app before using it.
RESET Button Hold down the RESET button for 5 seconds while the camera is running, the
camera restarts and all parameters are reset to default.

Setup

Step 1 Power-on
Plug the power cable into the camera and to the power adapter and then into a
power outlet, as shown in the figure below.
Step 2 Camera Setup
1. Create a user account
- Connect your mobile phone to Wi-Fi.
- Download and install the EZVIZ app by searching "EZVIZ" in App Store or Google
TM
Play .
- Launch the app and register for an EZVIZ user account following the start-up
wizard.
USB Cable (x1)
Metal Plate (x1)
(3.5mm Hole Diameter)
MIC
Speaker
Power Input
Regulatory Information
(x1)
Lens
LED Indicator
Magnetic Base
microSD Card
Slot
RESET Button
Power Outlet
Power Cable
1
Power Adapter (x1)
Quick Start Guide (x1)
