Hardware
Fa x 12 + 1 spare
M6 x 18L Bolt
Ff x 4
Nut
Everwood Harrington Double Glider
ASSEMBLY INSTRUCTIONS
Fb x 4
M6 x 25L Bolt
Fg x 4
Plastic Washer
SR-I-139NDG
Fc x 2
M6 x 30L Bolt
Fh x 1
Open Allen Wrench
1
Fd x 4
M6 x 50L Bolt
Fi x 1
Allen Wrench
Fe x 26
Metal Washer
Advertisement
Related Manuals for Numark Everwood Harrington SR-I-139NDG
Summary of Contents for Numark Everwood Harrington SR-I-139NDG
- Page 1 Everwood Harrington Double Glider ASSEMBLY INSTRUCTIONS SR-I-139NDG Questions, problems, missing parts with this product? Do not return to your retailer,please call our customer service department 9:00 a.m. to 5:00 p.m. Eastern Standard Time Monday through Friday Phone # 1-800-457-4652 or contact us at www.numarkcustomerservice.com Hardware Fd x 4 Fe x 26...
- Page 2 Parts Left Arm Right Arm Seat Back Base Leg Base Leg Connector Assembly instruction Fa x 4 M6 x 18L Bolt Fc x 2 M6 x 30L Bolt Fe x 6 Metal Washer Don’t tighten completely. Repeat procedure for the other arm.
- Page 3 Assembly instruction Fb x 4 M6 x 25L Bolt Fe x 4 Metal Washer Don’t tighten completely. Repeat procedure for the other side. Fa x 8 M6 x 18L Bolt Fe x 8 Metal Washer Note: the arrow should be towards down. Don’t tighten completely.
- Page 4 Assembly instruction Fd x 4 M6 x 50L Bolt Fe x 8 Metal Washer Ff x 4 Fg x 4 Plastic Washer Don’t tighten completely. Repeat procedure for the other chair. Securely tighten all bolts. Now your glider is ready for use.
