Laredo 3 piece balcony set

SC-K-317EY/3

Questions, problems, missing parts with this product? Do not return to your

retailer,please call our customer service department 9:00 a.m. to 5:00 p.m.

Eastern Standard Time Monday through Friday Phone # 1-800-457-4652

or contact us at www.numarkcustomerservice.com

Table of Contents

Need help?

Do you have a question about the Laredo SC-K-317EY/3 and is the answer not in the manual?

Page 1 Laredo 3 piece balcony set ASSEMBLY INSTRUCTIONS SC-K-317EY/3 Questions, problems, missing parts with this product? Do not return to your retailer,please call our customer service department 9:00 a.m. to 5:00 p.m. Eastern Standard Time Monday through Friday Phone # 1-800-457-4652 or contact us at www.numarkcustomerservice.com...
Page 2 Parts Left Arm Right Arm Back Seat Front crossbar Seat Cushion Table top Metal table leg (8 Bolts and 8 Metal Washers Attached) Center post Hardware Jd x 1 Jc x 24 Jb x 24 + 2 spares Ja x 4 Umbrella Insert Piece Bolt Metal washer...
Page 3 Assembly instruction Jb x 4 Bolt Jc x 4 Metal washer Do not tighten completely. Repeat procedure for the other side. Jb x 6 Bolt Jc x 6 Metal washer Do not tighten completely. Repeat procedure for the other side.
Page 4 Assembly instruction Jb x 2 Bolt Jc x 2 Metal washer Do not tighten completely. Repeat procedure for the other side. Tighten all the bolts, put the chair cushion (F) on the chair. Repeat procedure for the other chair.
Page 5 Assembly instruction Ja x 4 Screw Do not tighten completely. Repeat procedure for the other three legs. Jb x 8 Bolt (remove from the table leg) Jc x 8 Metal washer (remove from the table leg) Do not tighten completely. Repeat procedure for the other three legs.
Page 6 Assembly instruction Jd x 1 Umbrella Insert Piece Turn table upright, and tighten all the blots (Jb) in a diagonal pattern. Your chairs and table are now ready for use! ６...
