The AVG-SC121D-T is a full HD scaler switcher
with 12 video, 6 audio & 2 MIC inputs. It scales
& switches HDMI, VGA, YPbPr, C-Video & S-
video to HDMI & VGA simultaneously, and
audio to a 2x20W amplifier. It's controllable via
the front panel, IR, RS232 & TCP/IP(where
fitted)
Features
12 video Inputs: 4 HDMI, 4 VGA, 1 YPbPr,
2 C-video & 1 S-video
2 MIC inputs with level control and mixer
function
Upscale to HDMI & VGA simultaneously up
to 1080P.
Built-in 2x20Watt@4Ω digital amplifier (or
2x10Watt@8Ω)
Output resolution is selectable
Output display H/V size: adjustable to
eliminate any overscale error
Output display H/V position moveable.
MIC volume and line volume adjustable
Extensive OSD function with full control
HDMI1.3 and HDCP compliant.
Firmware updatable via USB
Output freeze function
Power PoC receiver (e.g. AVG-HD402PR)
with PoC function
Front panel lockout feature
Controllable via receiver AVG-HD402PR at
display end.
Controllable via front panel, IR, RS232 &
TCP/IP.
