AVG-DAC
The AVG-DAC Digital to Analog Audio
Convertor is designed for either home or
professional audio conversion.
Features
ConvertsS/PDIF or Optical (Toslink)
to Analog L/R Audio Signal
Supports 2 channel LPCM digital
audio only
Supports Sampling rates of 32,
44.1, 48 and 96 kHz
Compact design for easy operation
Advertisement
Table of Contents
Related Manuals for AVGear AVG-DAC
Summary of Contents for AVGear AVG-DAC
- Page 1 Analog L/R Audio Signal Supports 2 channel LPCM digital audio only Supports Sampling rates of 32, 44.1, 48 and 96 kHz Compact design for easy operation The AVG-DAC Digital to Analog Audio Convertor is designed for either home or professional audio conversion.
- Page 2 AVG-DAC PLEASE READ THIS PRODUCT MANUAL CAREFULLY BEFORE USING THIS PRODUCT. This manual is only for operation instruction only, and is not to be used in a maintenance capacity. The functions described in this version are current as at March 2015. Any changes of functions and operational parameters will be updated in future manual versions.
- Page 3 AVG-DAC SAFETY OPERATION GUIDE In order to guarantee the reliable operation of the equipment and safety of the user, please abide by the following procedures in installation, use and maintenance: 1. The system must be earthed properly. Please do not use two blade plugs and ensure the AC power supply ranges from 100v to 240v and from 50Hz to 60Hz.
- Page 4 AVG-DAC TABLE OF CONTENTS Introduction ......................1 Introduction to the AVG-DAC................ 1.1 Features ....................... 1.2 Whats in the Box ..……………………………………………………………………2 System Connection ....................3 System Applications ..................3.1 Usage Precautions ..................3.2 Connection Diagram ..................3.3 Specification ......................4...
- Page 5 AVG-DAC 1. Introduction 1.1. Introduction to the AVG-DAC The AVG-DAC Digital to Analog Audio Convertor is designed for either home or professional audio conversion. Digital Audio is input by either the Coaxial S/PDIF or Optical Tosliknk connector. It is then converted to Analog and made available on a 3.5mm socket 1.2.
- Page 6 AVG-DAC 2. Package List 1 x AVG-DAC 1 x Power Adapter (DC 5V 1A) Note: Please confirm if the product and the accessories are all included, if not, please contact your dealer.
- Page 7 3. System Connection 3.1 System Applications The AVG-DAC is ideal in applications where external devices such as Receivers etc require a Digital signal to be made available in Analog format. This is a great accessory to have at any installation for the retrofitting of unplanned equipment.
- Page 8 AVG-DAC 4. Specification Input Input 1 S/PDIF, 1 Optical Input Connector 1 Coax RCA, 1 Toslink Format LPCM 32,44.1,48 & 96kHz Sampling Rates Output Output 1 Analog L/R Output Connector 1 3.5mm Socket Min/ Max Signal Level Line Level -10 dbV, 0.316V RMS 100Ω...
