AVG-ADC
The AVG-ADC Analog to Digital Audio
Convertor is designed for either home or
professional audio conversion.
Features
Converts Analog L/R Audio Signal
to S/PDIF or Optical (Toslink)
Supports L/R Stereo Audio via
3.5mm mini jack and RCA
connectors
Supports Output Sampling rate of
96 kHz, 2 channels LPCM digital
audio
Compact design for easy operation
Advertisement
Table of Contents
Related Manuals for AVGear AVG-ADC
Summary of Contents for AVGear AVG-ADC
- Page 1 Supports L/R Stereo Audio via 3.5mm mini jack and RCA connectors Supports Output Sampling rate of 96 kHz, 2 channels LPCM digital audio Compact design for easy operation The AVG-ADC Analog to Digital Audio Convertor is designed for either home or professional audio conversion.
- Page 2 AVG-ADC PLEASE READ THIS PRODUCT MANUAL CAREFULLY BEFORE USING THIS PRODUCT. This manual is only for operation instruction only, and is not to be used in a maintenance capacity. The functions described in this version are current as at March 2015. Any changes of functions and operational parameters will be updated in future manual versions.
- Page 3 AVG-ADC SAFETY OPERATION GUIDE In order to guarantee the reliable operation of the equipment and safety of the user, please abide by the following procedures in installation, use and maintenance: 1. The system must be earthed properly. Please do not use two blade plugs and ensure the AC power supply ranges from 100v to 240v and from 50Hz to 60Hz.
- Page 4 AVG-ADC TABLE OF CONTENTS Introduction ......................1 Introduction to the AVG-ADC................ 1.1 Features ....................... 1.2 Whats in the Box ..……………………………………………………………………2 System Connection ....................3 System Applications ..................3.1 Usage Precautions ..................3.2 Connection Diagram ..................3.3 Specification ......................4...
- Page 5 AVG-ADC 1. Introduction 1.1. Introduction to the AVG-ADC The AVG-ADC Analog to Digital Audio Convertor is designed for either home or professional audio conversion. Analog Audio is input by either the 3.5mm stereo audio socket or L/R RCA connectors and output on both S/PDIF and Optical (Toslink) connectors.
- Page 6 AVG-ADC 2. Package List 1 x AVG-ADC 1 x Power Adapter (DC 5V 1A) Note: Please confirm if the product and the accessories are all included, if not, please contact your dealer.
- Page 7 3. System Connection 3.1 System Applications The AVG-ADC is ideal in applications where external devices such as Receivers etc require an Analog signal to be made available in Digital format. This is a great accessory to have at any installation for the retrofitting of unplanned equipment.
- Page 8 AVG-ADC 4. Specification Input Input 1 Analog L/R Input Connector 1 3.5mm L/R socket Min/ Max Signal Level Line Level -10 dbV, 0.316V RMS Output Output 1 S/PDIF, 1 Optical Output Connector 1 Coax RCA, 1 Toslink Format LPCM 32,44.1,48 & 96kHz Sampling Rates...
