Thank you for buying a SNAPPER Product! Before operating your machine, read this manual carefully and pay
particular attention to the "IMPORTANT SAFETY INSTRUCTIONS" on Pages 2 & 3. Remember that all power
equipment can be dangerous if used improperly. Also keep in mind that SAFETY requires careful use in
accordance with the operating instructions and common sense!
COPYRIGHT © 2001
SNAPPER INC.
ALL RIGHTS RESERVED
Safety Instructions & Operator's Manual for
REAR ENGINE RIDING MOWER
MODEL NUMBER EXPLANATION
E
33
10 - 10.0 HP Engine
12 – 12.0 HP Engine
15
22
K
15 – 15.0 HP Engine
22 - Series Designation
EUROPEAN
SERIES 22
MODEL
E281022BE
E281222BE
E331522KVE
V
E
ENGINE OPTIONS
SERIES DESIGNATION
B - Briggs Engine
K – Kohler Engine
MANUAL No. 7-4391 (I.R. 2/19/01)
ENGINE TYPE
V - Overhead
Valve
E - Electric Start
