Instruction sheet for SATK60193HE
© Copyright 2020 Caleffi
Product range
Cod. SATK60193HE
Function
The heat interface unit code SATK60193HE is designed to provide indirect heating (hydraulic
separation by means of a plate heat exchanger) to both low temperature and high temperature
heating systems. SATK60193HE does not need any dedicated connection kit and can be used
to replace existing old recessed modules.
Specifications
For functional and performance-related features, please refer to the instruction sheet code
78202 and technical brochure 01212 supplied with the module. The product corresponding to
SATK60193HE is code SATK60103HE
Code for replacement of
existing modules
SATK60193HE
DHW production and optional functions
Code
SATK60193HE
Dimensions / electric specifications
Code
SATK60193HE
recess mounted heat interface unit for indirect heating, 40 kW heat
exchanger, heating circuit regulating temperature 25–45 °C (low temperature
range) or 45–75 °C (high temperature range).
Standard code
SATK60103HE
DHW temperature
and flow rate range
42–60 °C max 18 l/min
Dimensions (W x H x D)
570 x 590 x 110 mm
www.caleffi.com
SATK60 series
Main specifications
Heating range 25-75 °C
Main optional functions
DHW preheating function
Electric specifications
Max operating pressure: 16 bar.
Power supply 230 V (AC) - 50 Hz.
Max power consumption: 80 W
H0009183
Advertisement
Related Manuals for CALEFFI SATK60 Series
Summary of Contents for CALEFFI SATK60 Series
- Page 1 H0009183 www.caleffi.com Instruction sheet for SATK60193HE SATK60 series © Copyright 2020 Caleffi Product range Cod. SATK60193HE recess mounted heat interface unit for indirect heating, 40 kW heat exchanger, heating circuit regulating temperature 25–45 °C (low temperature range) or 45–75 °C (high temperature range).
- Page 2 These instructions must be observed and applied during installation, to prevent problems from arising during fitting or normal operation. Before proceeding with installation, CAREFULLY read brochure 01212 and instruction sheet code 78202 (available on the website www.caleffi.com). You should therefore: A) Carefully measure the dimensions of heat interface unit SATK60 so that it is ideally positioned on the wall.
- Page 3 When performing the hydraulic and electrical connections, observe all the safety notes provided below WARNINGS These instructions must be read and understood before installing and servicing the device. IMPORTANT! FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN A SAFETY HAZARD! 1 The device must be installed, commissioned and maintained by qualified technical personnel in accordance with national regulations and/or relevant local requirements.
- Page 4 If a fitting needs to be tightened apply a proper tightening torque, otherwise the components may be damaged by overtightening. For the updated version of the technical documentation refer to www.caleffi.com. Caleffi S.p.A.
