LG 52LG70ED Owner's Manual

LG 52LG70ED Owner's Manual

Hide thumbs Also See for 52LG70ED:
Table of Contents

Advertisement

Quick Links

User's Guide Specification
User's Guide Specification
1.
Model Description
MODEL
42/47/52LG70ED-CA
SUFFIX
LGEND
2.
Printing Specification
1. Trim Size (Format) :
2. Printing Colors :
3. Stock (Paper)
• Cover :
Coated paper, S/W 150 g/㎡
Uncoated paper, 백상지 60 g/㎡
• Inside :
4. Printing Method :
5. Bindery :
Perfect bind
6. Language :
EN (1)
7. Number of pages :
"This part contain Eco-hazardous substances (Pb, Cd, Hg, Cr6+, PBB, PBDE, etc.) within LG standard level,
N
Details should be followed Eco-SCM management standard[LG(56)-A-2524].
O
Especially, Part should be followed and controlled the following specification.
T
(1)Eco-hazardous substances test report should be submitted
E
when Part certification test and First Mass Production.
S
(2) Especially, Don't use or contain lead(Pb) and cadmium(Cd) in ink.
3.
Special Instructions
(1) Origin Notification
* LGEIN : Printed in Indonesia
* LGESP : Printed in Brazil
* LGEND : Printed in China
* Other Oversea Factories : NON
3.
Changes
10
9
8
7
6
5
4
3
2
1
REV.
MM/DD/YY SIGNATURE
NO.
BRAND
Product Name
42/47/52LG70ED
185 mm x 260 mm
1 Color (BLACK)
Off-set
108 pages
* LGEWA : Printed in U.K.
* LGEMX : Printed in Mexico
* LGEIL : Printed in India
CHANGE NO.
담 당
CHOI MJ
08.01.21
LG
Part No.
* LGEMA : Printed in Poland
CHANGE
CONTENTS
관 리 자
KIM JO
08.01.21
MFL36914907
(0801-REV00)
