INSTRUCTION MANUAL
GUIDE FOR USING THE DISHWASHER AND THE WASHING PROGRAMS

Advertisement

loading
Need help?

Need help?

Do you have a question about the STO905-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Smeg STO905-1

Summary of Contents for Smeg STO905-1

  • Page 1 INSTRUCTION MANUAL GUIDE FOR USING THE DISHWASHER AND THE WASHING PROGRAMS...

  • Page 3: Table Of Contents

    Contents Safety and operating instructions ___________________________ 2 Installation and hook-up __________________________________ 5 Description of the controls ________________________________ 9 Operating instructions ___________________________________ 21 Cleaning and maintenance _______________________________ 31 Troubleshooting _______________________________________ 35 Thank you for choosing this product. We advise you to carefully read all the instructions contained in this manual, in order to understand how to operate your dishwasher safely and correctly.

  • Page 4: Safety And Operating Instructions

    Safety instructions 1. Safety and operating instructions THIS MANUAL FORMS AN INTEGRAL PART OF THE APPLIANCE: IT MUST ALWAYS BE KEPT INTACT TOGETHER WITH THE DISHWASHER. BEFORE USING THE APPLIANCE, CAREFULLY READ ALL THE INSTRUCTIONS CONTAINED IN THIS MANUAL. INSTALLATION MUST BE PERFORMED BY A QUALIFIED TECHNICIAN, IN COMPLIANCE WITH THE REGULATIONS IN FORCE.
  • Page 5 Safety instructions THIS APPLIANCE IS MARKED ACCORDING TO THE EUROPEAN DIRECTIVE 2002/96/EC ON WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE). BY ENSURING THIS PRODUCT IS DISPOSED OF CORRECTLY, YOU WILL HELP PREVENT POTENTIAL NEGATIVE CONSEQUENCES FOR THE ENVIRONMENT AND HUMAN HEALTH, WHICH COULD OTHERWISE BE CAUSED BY INAPPROPRIATE WASTE HANDLING OF THIS PRODUCT.
  • Page 6 Safety instructions DO NOT DRINK THE WATER RESIDUES WHICH MAY BE PRESENT INSIDE THE DISHES OR DISHWASHER AT THE END OF THE WASHING PROGRAM AND BEFORE THE DRYING CYCLE. KNIVES AND OTHER SHARP-POINTED KITCHEN UTENSILS MUST BE PLACED IN THE CUTLERY BASKET WITH THEIR TIPS FACING DOWNWARD. AQUASTOP MODELS THE AQUASTOP DEVICE PREVENTS FLOODING IN THE EVENT OF A WATER LEAK.

  • Page 7: Installation And Hook-Up

    Installation instructions 2. Installation and hook-up Remove the polystyrene basket retainers. Position the appliance in the desired place of installation. The back or sides of the dishwasher may be placed up against walls or other furniture units. If the dishwasher is installed near a heat source, fit the special insulating panel to prevent overheating and malfunction of the appliance.
  • Page 8 Installation instructions 2.1 Water supply connection Preventing the risk of clogging or damage: if the water pipe is new or has not been used for a long time, before connecting to the water supply check that the water is clear and free of impurities, to prevent damage to the appliance.
  • Page 9 Installation instructions IF THE APPLIANCE IS PROVIDED WITH A PLUGLESS SUPPLY CORD: AN OMNIPOLAR CIRCUIT BREAKER IN OVERVOLTAGE PROTECTION CLASS III MUST BE INSTALLED IN AN EASILY ACCESSIBLE POSITION ON THE POWER SUPPLY LINE. THE CONNECTION TO THE MAINS MUST BE CARRIED OUT BY A QUALIFIED TECHNICIAN IN ACCORDANCE TO THE SCHEME SHOWN BELOW AND THE REGULATIONS IN FORCE.
  • Page 10 Installation instructions FOR UK ONLY: THIS APPLIANCE MUST BE EARTHED. Fuse replacement If the mains lead of this appliance is fitted with a BS 1363A 13amp fused plug, to change a fuse in this type of plug use an A.S.T.A. approved fuse to BS 1362 type and proceed as follows: Remove the fuse cover A and fuse B.

  • Page 11: Description Of The Controls

    User instructions 3. Description of the controls 3.1 Upper panel All the dishwasher controls are grouped on the upper panel. Switch-on, programming, switch-off etc. procedures are only possible when the door is open. ON/OFF BUTTON Pressing this button energises the appliance. SELECTED PROGRAM INDICATOR LIGHTS Illumination of this light denotes the program selected and the occurrence of a fault (troubleshooting).
  • Page 12 User instructions "3/1" OPTION BUTTON Press this button to activate the option for use of 3/1 products. "3/1" OPTION LIGHT Illuminates to indicate that the function is activated. WASH-ZONE BUTTON Press this button to select the zone where you wish to concentrate the washing action.
  • Page 13 User instructions After using the table to identify the most appropriate washing program: • press the ON/OFF button (1) and wait for the PROGRAM INDICATOR LIGHT (2) to illuminate; • keep pressing the PROGRAM SELECTION button (3) until the indicator light corresponding to the desired program illuminates; •...
  • Page 14 User instructions EXTRA PROGRAMS (see relevant section for explanation of functioning modes) CONSUMPTION DURATION PROGRAMME TYPE OF DISHES PROGRAM DETERGENT NUMBER MINUTES WATER POWER AND DIRT DESCRIPTION GRAMS & SYMBOL (LITRES) (KWh) (1) DISH WARMER Clean mixed dishes Cold rinse requiring rinsing and 0,70 Rinse at 68°...
  • Page 15 User instructions PROGRAMS TABLE DURATION CONSUMPTION PROGRAMME TYPE OF DISHES PROGRAM DETERGENT NUMBER MINUTES WATER POWER AND DIRT DESCRIPTION GRAMS & SYMBOL (LITRES) (KWh) (1) SOAK Mixed dishes awaiting Cold rinse (to prevent dirt 0,01 washing from drying) QUICK Dishes and glasses Wash at 38°...
  • Page 16 User instructions EXTRA PROGRAMS (see relevant section for explanation of functioning modes) CONSUMPTION DURATION PROGRAMME TYPE OF DISHES PROGRAM DETERGENT NUMBER MINUTES WATER POWER AND DIRT DESCRIPTION GRAMS & SYMBOL (LITRES) (KWh) (1) DISH WARMER Clean mixed dishes Cold rinse requiring rinsing and 0,70 Rinse at 68°...
  • Page 17 User instructions NOTES AND REFERENCES Only run the soak program with half loads. Options cannot be used with the soak program. Standard programme under EN 50242. See information sheet provided When the " 50" or " 60" program is selected, the dishwasher recognises AUTO AUTO the type of dirt and automatically adjusts the washing parameters as appropriate.
  • Page 18 User instructions 3.2 Washing programs Before starting a washing program make sure that: • The water supply tap is open. • The correct amount of detergent has been added to the dispenser. • The baskets have been correctly loaded. • The spray arms are able to rotate freely and without obstruction.
  • Page 19 User instructions SELECTING THE WASH-ZONE OPTION Press button (10) in repetition to select the zone where you wish to concentrate the washing action, in the following order: right zone 65% - left zone 35% (right-hand light on); right zone 35% - left zone 65% (left-hand light on); both zones 50% (lights off).
  • Page 20 User instructions DELAYING THE PROGRAM The PROGRAM DELAY button (12) can be pressed to delay the start of the program by up to 9 hours. This means that the dishwasher can be operated at the time of day of your choice. Press the button several times in succession and the display will show the delay with which the appliance will start, beginning from 9 hours.
  • Page 21 User instructions ADJUSTING THE WATER SOFTENING SYSTEM N.B.: for the setting below to be possible, a washing program other than the soak program must be set. Press the PROGRAM DELAY button (12) and keep it pressed until the preset value appears followed by a full stop (normally 3.). Release the button then press it again in succession to display the value required, referring to the table.
  • Page 22 User instructions If the door has to be opened while washing is in progress, the program will be interrupted. The relative light will keep flashing and a beeper will signal that the cycle has not been completed. When the door is closed the program will continue from where it was interrupted.

  • Page 23: Operating Instructions

    User instructions 4. Operating instructions Once the dishwasher has been correctly installed, prepare for use as follows: • Adjust the water softening system; • Add the regenerating salt; • Add the rinse aid and detergent. 4.1 Using the water softening system The amount of scale contained in the water (water hardness index) can cause whitish staining on the dry dishes, which...
  • Page 24 User instructions • Do not use table salt as it contains insoluble substances which, over time, may damage the water softening system. • When necessary, refill the regenerating salt container before starting the washing program. In this way, the excess saline solution will be immediately removed by the water;...
  • Page 25 User instructions ADDING THE RINSE AID The rinse aid helps the dishes dry faster and prevents the formation of scale deposits and staining; it is automatically added to the water during the final rinse cycle, from the container situated on the inner side of the door.
  • Page 26 User instructions ADDING THE DETERGENT After adding the detergent, to close the lid slide it in the direction shown by the arrow as far as it will go then press gently to lock. During washing, the dispenser will be opened automatically. •...
  • Page 27 User instructions • "3/1" Products If you wish to use detergents which already contain salt and rinse aid, check whether your dishwasher is fitted with the "3/1 option button" on the "Controls description" page and then refer to the section which explains how to use this function. If the button is not provided, we recommend the use of conventional products (separate detergent, salt and rinse aid), because with conventional washing cycles "3/1"...
  • Page 28 User instructions WARNING! • Make sure that the dishes are securely in place so that they cannot tip over or obstruct the rotation of the spray arms during the washing cycle. • Do not place very small objects in the baskets as these could fall and obstruct the spray arms or the wash pump.
  • Page 29 User instructions 4.4 Using the baskets The dishwasher has a capacity of 12 place-settings, including serving dishes.
  • Page 30 User instructions The basket is fitted with plate racks which can be stowed horizontal if required. The photos show the rack for normal glasses (item A) and for flute glasses (item B).
  • Page 31 User instructions When detergent tablets are used, when the dispenser opens the table lodges in the basket shown in the photo; it is therefore essential for this basket to be left empty. It is not a cutlery rack.
  • Page 32 User instructions CUTLERY BASKET Cutlery must be placed with the tips facing downward. The cutlery basket features an exclusive system of independent sliding tip-up supports, offering a series of combinations to allow optimum use of the space available. It can also be separated into two parts.

  • Page 33: Cleaning And Maintenance

    User instructions 5. Cleaning and maintenance Before carrying out any work, always disconnect the appliance from the electrical power supply. 5.1 General warnings and recommendations Avoid the use of acidic or abrasive detergents. Clean the outer surfaces and door-lining of the dishwasher regularly using a soft cloth moistened with water or with a normal detergent suitable for painted surfaces.
  • Page 34 User instructions To remove the upper spray arms, unsrew the looking ring. Wash them under running water and carefully replace them in their seats, checking that their rotary movement is in no way impeded. CLEANING THE FILTER UNIT • It is advisable to periodically inspect the centre filter C and, if necessary, to clean it.
  • Page 35 User instructions GENERAL WARNINGS AND RECOMMENDATIONS FOR CORRECT MAINTENANCE: • The filters should be cleaned under running water using a stiff brush. • It is essential to thoroughly clean the filters according to the above instructions: the dishwasher cannot function if the filters are clogged. •...
  • Page 36 User instructions If the dishes are not being cleaned properly, check that: • the correct amount of detergent has been added; • there is regenerating salt inside the special container; • the dishes are being loaded correctly; • the selected program is suitable for the dish types and their degree of soiling;...

  • Page 37: Troubleshooting

    User instructions 6. Troubleshooting The dishwasher is capable of signalling a number of faults through the simultaneous illumination of several indicator lights, with the following meanings: FAULT DESCRIPTION Acquastop failure The anti-flooding system has been activated (for the relevant models only). The system is tripped in case of water leaks.
  • Page 38 User instructions FAULT DESCRIPTION Turbine flow-regulator malfunction (for the relevant models only) The appliance is not able to "measure" the amount of water loaded accurately. Interrupt the program and switch off the dishwasher. Switch the dishwasher back on, program it again and start the washing cycle.
  • Page 39 User instructions TECHNICAL DATA Width 858 mm Depth measured flush with the 550 mm outer edge of the control panel Height 580 mm Capacity 12 Standard place settings Water supply pressure min. 0,05 - max. 0,9 MPa (min. 0.5 – max. 9 bar) Electrical characteristics See rating plate...
