INSTRUCTION MANUAL

GUIDE FOR USING THE DISHWASHER AND THE WASHING PROGRAMS

Downloaded from DishWasher-Manual.com Manuals

Table of Contents

Need help?

Do you have a question about the Dishwasher and is the answer not in the manual?

Questions and answers

Summary of Contents for Smeg Dishwasher

Page 1 INSTRUCTION MANUAL GUIDE FOR USING THE DISHWASHER AND THE WASHING PROGRAMS Downloaded from DishWasher-Manual.com Manuals...
Page 2: Table Of Contents
Thank you for choosing this product. We advise you to carefully read all the instructions contained in this manual, in order to understand how to operate your dishwasher safely and correctly. The manual is divided into paragraphs, which provide a step by step...
Page 3: Safety And Operating Instructions
THAT OPENINGS UNDERSIDE OBSTRUCTED. ALWAYS SWITCH OFF THE DISHWASHER AFTER EACH USE TO AVOID WASTING ELECTRICITY. OBSOLETE APPLIANCES MUST BE RENDERED UNUSABLE. CUT OFF THE MAINS POWER CORD AFTER UNPLUGGING IT FROM THE WALL OUTLET, AND MAKE SAFE ANY COMPONENTS WHICH MIGHT BE DANGEROUS FOR CHILDREN (LOCKS, DOORS, ETC.).
Page 4: Safety Instructions
OFFICE, YOUR HOUSEHOLD WASTE DISPOSAL SERVICE OR THE SHOP WHERE YOU PURCHASED THE PRODUCT. IN THE EVENT OF A FAULT, DISCONNECT THE DISHWASHER FROM THE ELECTRICAL POWER SUPPLY AND SHUT OFF THE WATER TAP. DO NOT USE APPLIANCES WHICH HAVE BEEN DAMAGED DURING TRANSIT! IF IN DOUBT, CONSULT YOUR DEALER.
Page 5 Safety instructions DO NOT DRINK THE WATER RESIDUES WHICH MAY BE PRESENT INSIDE THE DISHES OR DISHWASHER AT THE END OF THE WASHING PROGRAM AND BEFORE THE DRYING CYCLE. KNIVES AND OTHER SHARP-POINTED KITCHEN UTENSILS MUST BE PLACED IN THE CUTLERY BASKET WITH THEIR TIPS FACING DOWNWARD.
Page 6: Installation And Hook-Up
Position the appliance in the desired place of installation. The back or sides of the dishwasher may be placed up against walls or other furniture units. If the dishwasher is installed near a heat source, fit the special insulating panel to prevent overheating and malfunction of the appliance.
Page 7 DRAIN CONNECTION Fit the drain hose into a pipe having diameter of at least 4 cm; the dishwasher is ﬁtted with a special device which allows column installation, even with the drain pipe below the level of the dishwasher. 2.2 Electrical connection and precautions...
Page 8 FROM THE ELECTRICAL SUPPLY OR SWITCH OFF THE ALL-POLE DISCONNECTION DEVICE. WARNING! Some components inside the appliance are intentionally electrically live even with the ON/OFF switch turned to off. Before any repair operation, disconnect the appliance from the electrical mains. Downloaded from DishWasher-Manual.com Manuals...
Page 9 Correct replacement are identified by the colour insert or the colour embossed in words on the base of the plug. Replacement fuse covers are available from your local electrical store. Downloaded from DishWasher-Manual.com Manuals...
Page 10: Description Of The Controls
User instructions 3. Description of the controls 3.1 Upper panel All the dishwasher controls are grouped on the upper panel. Switch-on, programming, switch-off etc. procedures are only possible when the door is open. ON/OFF BUTTON Pressing this button energises the appliance.
Page 11 WASH-ZONE LIGHTS If one of the lights is on, the wash-zone washing system has been selected. PROGRAM DELAY BUTTON Press this button to delay the start of the program by up to 9 hours. INFORMATION DISPLAY Downloaded from DishWasher-Manual.com Manuals...
Page 12 Wash at 65°C NORMAL 105' 1,30 and pans, Cold rinse 65°C normal dirt Rinse at 68°C Mixed dishes, Wash at 65°C normal dirt STRONG 1,20 Cold rinse and FAST which has not Rinse at 70°C dried Downloaded from DishWasher-Manual.com Manuals...
Page 13 To execute programs 6,7,8,9,10 users must first press the extra programs button (6). (*) Reference program as per EN 50242 standard. (**) When the " 50" or " 60" program is selected, the dishwasher recognises the AUTO AUTO type of dirt and automatically adjusts the washing parameters as appropriate.
Page 14 User instructions The washing cycle will not take place if the dishwasher door is left open or not properly closed. 3.2 Washing programs Before starting a washing program make sure that: • The water supply tap is open. • The correct amount of detergent has been added to the dispenser.
Page 15 User instructions CHANGING THE PROGRAM To change the program in progress, simply open the door and select a new program. When the door is closed the dishwasher will automatically select the new program. SELECTING THE WASH-ZONE OPTION (available in all programs...
Page 16 The PROGRAM DELAY button (12) can be pressed to delay the start of the program by up to 9 hours. This means that the dishwasher can be operated at the time of day of your choice. Press the button several times in succession and the display will show the delay with which the appliance will start, beginning from 9 hours.
Page 17 12 - 21 20 - 36 22 - 33 37 - 59 34 - 45 60 - 79 46 - 53 80 - 107 Contact your local water board for information on the hardness of your water supply. Downloaded from DishWasher-Manual.com Manuals...
Page 18 END OF CYCLE At the end of the program the beeper sounds briefly and the lights of programs 4 and 5 flash. To switch off the dishwasher, open the door and press the ON/OFF button (1). REMOVING THE DISHES At the end of the washing program, wait at least 20 minutes before removing the dishes, to allow them to cool down.
Page 19: Operating Instructions
Before replacing the cap, remove any salt residues from around the opening. • When using the dishwasher for the first time, in addition to the salt it is also necessary to add one litre of water to the container. •...
Page 20 With the exception of the SOAK program, before every washing cycle it is necessary to add the required amount of detergent to the detergent dispenser. The rinse aid, on the other hand, should only be added as required. Downloaded from DishWasher-Manual.com Manuals...
Page 21 ADJUSTING THE RINSE AID DISPENSER SETTING The dishwasher is factory set for medium water hardness. However it possible to change the setting by turning the dispenser’s selector to the desired position: the amount of rinse aid dispensed is proportional to the selector position.
Page 22 • Do not use detergents formulated for washing dishes by hand, because they produce a great deal of foam and may negatively affect the operation of the dishwasher. • Add the correct amount of detergent. An insufficient amount of detergent will result in a partial removal of dirt from the dishes, whereas an excessive amount is wasteful and does not improve the washing results.
Page 23 The introduction of detergent into the rinse aid dispenser, even in liquid form, will damage the dishwasher. 4.3 General warnings and recommendations Before using the dishwasher for the first time, it is advisable to read the following recommendations concerning dish types to be washed and their loading.
Page 24 • Glass and crystal: in general, glass and crystal objects can be washed in the dishwasher. However, certain types of glass and crystal may become dull and lose their clearness after many washings. Therefore, for these items we recommend using the least aggressive program available.
Page 25 User instructions 4.4 Using the baskets The dishwasher has a capacity of 12 place-settings, including serving dishes. Downloaded from DishWasher-Manual.com Manuals...
Page 26 User instructions The basket is ﬁtted with plate racks which can be stowed horizontal if required. The photos show the rack for normal glasses (item A) and for ﬂute glasses (item B). Downloaded from DishWasher-Manual.com Manuals...
Page 27 When detergent tablets are used, when the dispenser opens the table lodges in the basket shown in the photo; it is therefore essential for this basket to be left empty. It is not a cutlery rack. Downloaded from DishWasher-Manual.com Manuals...
Page 28 Cutlery must be placed with the tips facing downward. The cutlery basket features an exclusive system of independent sliding tip-up supports, offering a series of combinations to allow optimum use of the space available. It can also be separated into two parts. Downloaded from DishWasher-Manual.com Manuals...
Page 29: Cleaning And Maintenance
5.1 General warnings and recommendations Avoid the use of acidic or abrasive detergents. Clean the outer surfaces and door-lining of the dishwasher regularly using a soft cloth moistened with water or with a normal detergent suitable for painted surfaces. Clean the door gaskets with a damp sponge.
Page 30 D from the underside to remove it from the micro-filter: • separate the two parts which make up the plastic filter by pressing the body of the filter in the zone shown by the arrows; • remove the centre filter by lifting it upwards. Downloaded from DishWasher-Manual.com Manuals...
Page 31 The filters should be cleaned under running water using a stiff brush. • It is essential to thoroughly clean the filters according to the above instructions: the dishwasher cannot function if the filters are clogged. • Carefully replace the filters in their seats, to avoid damaging the wash pump.
Page 32 If after following the above troubleshooting instructions the problem persists, call the nearest After-Sales Centre. WARNING: any operations performed on the appliance by unauthorised persons are not covered by the warranty and shall be paid for by the user. Downloaded from DishWasher-Manual.com Manuals...
Page 33: Troubleshooting
User instructions 6. Troubleshooting The dishwasher is capable of signalling a number of faults through the simultaneous illumination of several indicator lights, with the following meanings: FAULT DESCRIPTION Acquastop failure The anti-flooding system has been activated (for the relevant models only). The system is tripped in case of water leaks.
Page 34 • The alarm E7 is visualized at the end of the cycle that comes, however, brought to the end since the operation of the dishwasher is not harmed. To “reset” an alarm is necessary: •...
Page 35 550 mm outer edge of the control panel Height 580 mm Capacity 12 Standard place settings Water supply pressure min. 0,05 - max. 0,9 MPa (min. 0.5 – max. 9 bar) Electrical characteristics See rating plate Downloaded from DishWasher-Manual.com Manuals...
Page 36 2,2 - max. 7 kg min. 4,8 - pounds max. 15,5 pounds min. 1,5 - max. 5 kg min. 3,3 pounds max. 11 pounds 19 510 0372 02 Downloaded from DishWasher-Manual.com Manuals...
Page 37 Downloaded from DishWasher-Manual.com Manuals...
