INSTRUCTION MANUAL

Advertisement

loading

Related Manuals for Smeg STO900

Summary of Contents for Smeg STO900

  • Page 1 INSTRUCTION MANUAL...

  • Page 2: Table Of Contents

    Cleaning and maintenance _______________________________ 27 Troubleshooting ________________________________________ 31 Thank you for choosing this product. We advise you to carefully read all the instructions contained in this manual, in order to understand how to operate your dishwasher safely and correctly. The manual is divided into paragraphs, which provide a step by step...

  • Page 3: Safety And Operating Instructions

    THE NAME PLATE FEATURING THE TECHNICAL DATA, SERIAL NUMBER AND MARKINGS IS VISIBLY POSITIONED ON THE INNER EDGE OF THE DOOR. THE NAME PLATE ON THE INNER EDGE OF THE DOOR MUST NEVER BE REMOVED. DO NOT LEAVE THE DISCARDED PACKAGING MATERIALS UNSUPERVISED WITHIN THE HOME.
  • Page 4 DO NOT INTRODUCE SOLVENTS SUCH AS ALCOHOL OR TURPENTINE WHICH MAY CAUSE AN EXPLOSION. DO NOT LOAD DISHES THAT ARE SOILED WITH ASH, WAX OR PAINTS. LEANING OR SITTING ON THE DISHWASHER DOOR WHEN OPEN MAY CAUSE THE APPLIANCE TO OVERTURN, PUTING PEOPLE AT RISK.
  • Page 5 WARRANTY, AS WELL AS POSING A POTENTIAL HAZARD TO THE USER. The manufacturer declines all responsibility for damage to persons or property resulting from failure to observe the above precautions, from tampering with even a single component of the appliance, or from the use of non original spare parts.

  • Page 6: Installation And Hook-Up

    Some protective systems preventing access to the door opening and closing mechanisms are not active until the appliance has been installed. If the appliance is not built into a cabinet, or is built into a cabinet but without one or both front panels, some mechanical parts which may cause serious injury when the door is opened and closed are accessible.
  • Page 7 Installation instructions 2.1 Water supply connection Preventing the risk of clogging or damage: if the water pipe is new or has not been used for a long time, before connecting to the water supply check that the water is clear and free of impurities, to prevent damage to the appliance.
  • Page 8 N = blue = yellow-green In the event of damage to the supply cord, have it replaced by the an Authorized Technical Service Centre in order to avoid any risk. If this lamp needs changing, contact the manufacturer or an Authorised Service Centre.
  • Page 9 Fit replacement 13A fuse into fuse cover. Refit both into plug. The fuse cover must be refitted when changing a fuse and if the fuse cover is lost the plug must not be used until a correct replacement is fitted.

  • Page 10: Description Of The Controls

    Illumination of this light signals that rinse aid dispenser is empty. EXTRA PROGRAM BUTTON This button gives access to the one of the five extra programs (see table). EXTRA PROGRAM LIGHT Illuminates to indicate that one of the five extra programs (see table) is going to be executed.
  • Page 11 Press this button to select the zone where you wish to concentrate the washing action. WASH-ZONE LIGHTS If one of the lights is on, the wash-zone washing system has been selected. PROGRAM DELAY BUTTON Press this button to delay the start of the program by up to 9 hours. INFORMATION DISPLAY...
  • Page 12 User instructions SETTING THE WASHING PROGRAM AND SWITCHING ON To select the most suitable program for the dishes to be washed refer to the table below, which indicates the most appropriate program according to dish type and degree of soiling.
  • Page 13 (1) The cycle duration and power consumption may vary according to the water and room temperatures, and the type and amount of dishes. (2) The stated water and power consumption values refer to nominal conditions. Real values are affected by the type of load of dishes, room temperature and incoming water temperature.
  • Page 14 User instructions The washing cycle will not take place if the dishwasher door is left open or not properly closed. TABLE FOR CERTIFICATION BODIES Reference standard EN 50242 Reference program Load 12 place-settings Type of detergent Amount of detergent 30 g Rinse aid setting 3.2 Washing programs...
  • Page 15 "main" program (1, 2, 3, 4 or 5). This function is retained in the memory, so the button has to be pressed again (the light goes out) if the user wishes to execute one of the 5 main programs at the next cycle.
  • Page 16 By pressing the button (7) you activate the "2/1" option, confirmed when the relative light comes on. This option has been studied for the use of dishwashing powder or tablets with integrated substances in place of rinse-aid known on the market as “2 in 1” or “double action” products; in this case the dishwasher will use the product in an optimal way without consuming dishwasher rinse-aid.
  • Page 17 User instructions If the door has to be opened while washing is in progress, the program will be interrupted. The relative light will keep flashing and a beeper will signal that the cycle has not been completed. When the door is closed the program will continue from where it was interrupted.

  • Page 18: Operating Instructions

    The rinse aid helps the dishes dry faster and prevents the formation of scale deposits and staining; it is automatically added to the water during the final rinse cycle, from the container situated on the inner side of the door.
  • Page 19 Close the door S. Use a cloth to remove any spillage of rinse aid which might lead to the formation of excess foam. ADJUSTING THE RINSE AID DISPENSER SETTING The dishwasher is factory set for medium water hardness.
  • Page 20 ADDING THE DETERGENT After adding the detergent, to close the lid slide it in the direction shown by the arrow as far as it will go then press gently to lock. During washing, the dispenser will be opened automatically. Use only detergents specially formulated for dishwashers. For optimal washing results it is important to use a good quality detergent.
  • Page 21 The introduction of detergent into the rinse aid dispenser, even in liquid form, will damage the dishwasher. 4.2 General warnings and recommendations Before using the dishwasher for the first time, it is advisable to read the following recommendations concerning dish types to be washed and their loading.
  • Page 22 If in doubt as to the fastness of the colours, it is advisable to wash just a few items at a time for approximately one month.
  • Page 23 User instructions 4.3 Using the baskets The dishwasher has a capacity of 12 place-settings, including serving dishes.
  • Page 24 User instructions The basket is fitted with plate racks which can be stowed horizontal if required. The photos show the rack for normal glasses (item A) and for flute glasses (item B).
  • Page 25 Cutlery must be placed with the tips facing downward. The cutlery basket features an exclusive system of independent sliding tip-up supports, offering a series of combinations to allow optimum use of the space available. It can also be separated into two parts.

  • Page 26: Cleaning And Maintenance

    CLEANING THE WATER INTAKE FILTER The water intake filter A located at the outlet of the water supply tap needs to be cleaned periodically. After having closed the water supply tap, unscrew the end of the water intake hose, remove the filter A and clean it delicately under running water.
  • Page 27 CLEANING THE FILTER UNIT It is advisable to periodically inspect the centre filter C and, if necessary, to clean it. To remove the filter, grip the tabs, turn them anticlockwise and lift upwards; push the centre filter D from the underside to remove it from the...
  • Page 28 DISUSE: Check that there are no deposits of sludge or rust inside the water pipe: if there are, allow the water to run from the water supply tap for a few minutes. Plug the power cord back into the socket.
  • Page 29 If there are visible traces of rust inside the tank: the tank is made of steel, and therefore any rust marks are due to external elements (fragments of rust from the water pipes, pots, cutlery, etc.).

  • Page 30: Troubleshooting

    User instructions 6. Troubleshooting The dishwasher is capable of signalling a number of faults through the simultaneous illumination of several indicator lights, with the following meanings: FAULT DESCRIPTION Acquastop failure The anti-flooding system has been activated (for the relevant models only). The system is tripped in case of water leaks.
  • Page 31 To “reset” an alarm is necessary: Open and close the door, or turn off and on the machine. At this point is possible to program the dishwasher again.
  • Page 32 Depth measured flush with the 550 mm outer edge of the control panel Height 580 mm Capacity 12 Standard place settings Water supply pressure min. 0,05 - max. 0,9 MPa (min. 0.5 – max. 9 bar) Electrical characteristics See rating plate...
  • Page 33 2,2 - max. 7,2 kg min. 1,5 - max. 5 kg 19 510 0320 02...
