USING YOUR VACUUM CLEANER
5. You can adjust the extension tube length to a comfortable cleaning
height. To alter the length of the telescopic handle,
a) Push and hold the extension lock in the direction indicated.
b) Slide the tube, up or down, to the correct length.
6. The suction of the vacuum cleaner can be adjusted by rotating the
power dial on the back of the unit. You may want to use reduced power
when cleaning furniture, upholstery or long pile rugs.
7. You can also adjust the suction using the tab on the hose handle. To
use less suction power, move the suction control tab to the open
position in the direction indicated. For maximum suction power, close
the tab.
8. When using the floor head you can adapt the brush depending on
floor type. Please refer to the diagram below:
5
a)
6
7
b)
Hard Floor Icon
Carpet/Rug Icon
