- Page 1 INSTRUCTION MANUAL Angle Grinder M0920 M0921 DOUBLE INSULATION Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model M0920 M0921 Depressed center wheel diameter 180 mm 230 mm Max. wheel thickness 6.5 mm Spindle thread M14 or 5/8" (country specific) Rated speed (n)/No load speed (n 8,500 min 6,600 min Overall length 439 mm Net weight 5.0 kg... - Page 3 13. Prevent unintentional starting. Ensure the GRINDER SAFETY WARNINGS switch is in the off-position before connecting to power source and/or battery pack, picking Safety Warnings Common for Grinding Operations: up or carrying the tool. Carrying power tools with This power tool is intended to function as a grinder. your finger on the switch or energising power tools Read all safety warnings, instructions, illustrations that have the switch on invites accidents.
- Page 4 Position the cord clear of the spinning acces- b) The grinding surface of centre depressed wheels sory. If you lose control, the cord may be cut or must be mounted below the plane of the guard lip. snagged and your hand or arm may be pulled into An improperly mounted wheel that projects through the the spinning accessory.
-
Page 5: Functional Description
33. Do not use cloth work gloves during operation. Fibers from cloth gloves may enter the tool, which causes tool breakage. SAVE THESE INSTRUCTIONS. WARNING: DO NOT let comfort or famil- iarity with product (gained from repeated use) replace strict adherence to safety rules for the subject product. -
Page 6: Operation
For models with 5/8" spindle thread Installing or removing wheel guard (For depressed center wheel/Multi disc) WARNING: • When using a depressed center grinding wheel/ Multi-disc, the wheel guard must be fitted on the tool so that the closed side of the guard always points toward the operator. -
Page 7: Replacing Carbon Brushes
Never use gasoline, benzine, thinner, alcohol any other maintenance or adjustment should be per- or the like. Discoloration, deformation or cracks formed by Makita Authorized Service Centers, always may result. using Makita replacement parts. ► 1. Exhaust vent 2. Inhalation vent... - Page 8 Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885424A934 www.makita.com 20170821...
