IR Receiver Modules for Remote Control Systems
22531-1
ORDERING CODE
Taping:
TSOP57...TT - top view taped
TSOP57...TR - side view taped
PARTS TABLE
AGC
36 kHz
38 kHz
Carrier
frequency
40 kHz
56 kHz
Package
Pinning
Dimensions (mm)
Mounting
Application
Best remote control code
Rev. 1.4, 25-Feb-14
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
NOISY ENVIRONMENTS
AND SHORT BURSTS (AGC3)
(1)(2)
TSOP57336
(3)(4)(5)(6)
TSOP57338
TSOP57340
TSOP57356
1 = OUT, 2, 3, 6, 7, 8 = GND, 4, 5 = V
(1) (2) (3)
MCIR RCMM Mitsubishi
1
TSOP573.., TSOP575..
Vishay Semiconductors
FEATURES
• Height of 0.8 mm
• ± 75° half angle sensitivity
• Low supply current
• Photo detector and preamplifier in one package
• Suitable for all common data formats including
those for short bursts
• Supply voltage: 2.5 V to 5.5 V, typically even
2.0 V to 5.5 V is possible
• Improved immunity against ambient light
• Insensitive to supply voltage ripple and noise
• Material categorization: For definitions of compliance
please see www.vishay.com/doc?99912
DESCRIPTION
The TSOP573.., TSOP575.. series are miniaturized receiver
modules for infrared remote control systems. A PIN diode
and a preamplifier are assembled on a lead frame, the epoxy
lens cap is designed as an IR filter.
The demodulated output signal can be directly connected to
a microprocessor for decoding. The TSOP573.. is optimized
to better suppress spurious pulses from energy saving
lamps. The TSOP575.. has an excellent noise suppression.
It is immune to dimmed LCD backlighting and any
fluorescent lamps. AGC3 and AGC5 may also suppress
some data signals in case of continuous transmission.
This component has not been qualified according to
automotive specifications.
VERY NOISY ENVIRONMENTS
AND SHORT BURSTS (AGC5)
TSOP57538
Belobog
S
3.95 W x 3.95 H x 0.8 D
SMD
Remote control
(4) (5)
RECS-80 Code x-map
www.vishay.com/doc?91000
(1)(2)
TSOP57536
(3)(4)(5)
TSOP57540
TSOP57556
(6)
XMP-1, XMP-2
