Vishay TSSP57038 Manual

Ir receiver modules for remote control systems
Hide thumbs Also See for TSSP57038:
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

www.vishay.com
IR Receiver Modules for Remote Control Systems
22531-1
LINKS TO ADDITIONAL RESOURCES
D D
D
3 D
Product Page
3D Models
DESCRIPTION
The TSSP57038 is a compact infrared detector module
for presence sensing applications. It receives 38 kHz
modulated signals and has a peak sensitivity of 940 nm.
This component has not been qualified according to
automotive specifications.
Rev. 2.2, 30-Mar-2021
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
Arrow.com.
Downloaded from
3 3
3
Calculators
Marking
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
Vishay Semiconductors
FEATURES
• Up to 2 m for presence sensing
• Uses modulated bursts at 38 kHz
• PIN diode and sensor IC in one package
• Low supply current
• Shielding against EMI
• Visible light is suppressed by IR filter
• Insensitive to supply voltage ripple and noise
• Supply voltage: 2.5 V to 5.5 V
• Material
categorization:
compliance please see
ORDERING CODE
Taping:
TSSP57038TT1 - top view taped, 1800 pcs/reel
APPLICATIONS
• Reflective sensors for hand dryers, towel or soap
dispensers, water faucets, toilet flush
• Vending machine fall detection
• Security and pet gates
• Person or object vicinity activation
BLOCK DIAGRAM
Input
AMP
PIN
20445-7
PRESENCE SENSING
IR emitter
Envelope
signal
38 kHz
Out to
μC
1
www.vishay.com/doc?91000
TSSP57038
for
definitions
of
www.vishay.com/doc?99912
4, 5
V
33 kΩ
1
OUT
Demo-
Band
dulator
pass
2, 3,
6, 7, 8
GND
+3 V
+3 V
Document Number: 82482
S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TSSP57038 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vishay TSSP57038

Summary of Contents for Vishay TSSP57038

  • Page 1 DESCRIPTION dispensers, water faucets, toilet flush • Vending machine fall detection The TSSP57038 is a compact infrared detector module for presence sensing applications. It receives 38 kHz • Security and pet gates modulated signals and has a peak sensitivity of 940 nm.

  • Page 2: Parts Table

    TSSP57038 www.vishay.com Vishay Semiconductors PARTS TABLE Carrier 38 kHz TSSP57038 frequency Package Belobog Pinning 1 = OUT, 2, 3, 6, 7, 8 = GND, 4, 5 = V Dimensions (mm) 3.95 W x 3.95 H x 0.8 D Mounting Application...

  • Page 3: Typical Characteristics

    TSSP57038 www.vishay.com Vishay Semiconductors TYPICAL CHARACTERISTICS (T = 25 °C, unless otherwise specified) Optical Test Signal (IR diode TSAL6200, I = 0.4 A, 30 pulses, f = f , t = 10 ms) 10/f is recommended for optimal function Output Signal 16110 λ...
  • Page 4 TSSP57038 www.vishay.com Vishay Semiconductors The typical application of this device is a reflective or beam break sensor with active low “detect” or “no detect” information contained in its output. Applications requiring up to 2 m beam break or 1 m reflective range benefit from...
  • Page 5 TSSP57038 www.vishay.com Vishay Semiconductors PACKAGE DIMENSIONS in millimeters 4 x 0.75 = 3 Not indicated tolerances ± 0.1 0.475 (0.3) 0.75 ± 0.05 technical drawings according to DIN specifications Pinning from topview (8 x) 0.35 ± 0.05 Pin 1 identification...
  • Page 6 Max. ramp up 3 °C/s Max. ramp down 6 °C/s Max. 2 cycles allowed Time (s) 19800 TAPING VERSION TSSP57038 DIMENSIONS in millimeters Tape and reel dimensions: Unreel direction Reel size “Y” TT1 Ø 180 ± 2 = 1800 pcs.
  • Page 7 The standard packing units are labeled with standard bar code labels before transported as finished goods to warehouses. The labels are on each packing unit and contain Vishay Semiconductor GmbH specific data. VISHAY SEMICONDUCTOR GmbH STANDARD BAR CODE PRODUCT LABEL (finished goods)

  • Page 8: Esd Precaution

    Aluminum bag VISHAY SEMICONDUCTORS STANDARD BAR CODE LABELS Label The Vishay Semiconductors standard bar code labels are printed at final packing areas. The labels are on each packing unit and contain Vishay Semiconductors specific data. Reel...
  • Page 9 Except as expressly indicated in writing, Vishay products are not designed for use in medical, life-saving, or life-sustaining applications or for any other application in which the failure of the Vishay product could result in personal injury or death. Customers using or selling Vishay products not expressly indicated for use in such applications do so at their own risk.
