www.vishay.com
IR Receiver Modules for Remote Control Systems
22531-1
DESIGN SUPPORT TOOLS
Model
Available
ORDERING CODE
Taping:
TSOP37...TT1 - top view taped
TSOP37...TT2 - top view taped
PARTS TABLE
AGC
Carrier frequency
Package
Pinning
Dimensions (mm)
Mounting
Application
Best remote control code
BLOCK DIAGRAM
Band
Input
AGC
pass
PIN
Control circuit
20445-5
Rev. 1.2, 24-Sep-2018
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
click logo to get started
40 kHz
4, 5
V
S
30 kΩ
1
OUT
Demo-
dulator
2, 3,
6, 7, 8
GND
Vishay Semiconductors
FEATURES
• Very low supply current
• Photo detectors and preamplifier in one package
• Internal filter for PCM frequency
• Optimized for Sony 12, 15, and 20 bit IR-code
• Supply voltage: 2.5 V to 5.5 V
• Improved immunity against ambient light
• Insensitive to supply voltage ripple and noise
• Material categorization:
for definitions of compliance please see
www.vishay.com/doc?99912
DESCRIPTION
The TSOP37S40 series are miniaturized SMD IR receiver
modules for infrared remote control systems. A PIN diode
and a preamplifier are assembled on a PCB, the epoxy
package contains an IR filter.
The demodulated output signal can be directly connected to
a microprocessor for decoding.
The demodulated output signal can be directly decoded by
a microprocessor. The TSOP37S40 is compatible with 12,
15, and 20 bit Sony codes. It is optimized to suppress
almost all spurious pulses from energy saving fluorescent
lamps but will also suppress some data signals.
These components have not been qualified according to
automotive specifications.
SONY (AGC-S)
TSOP37S40
Belobog
1 = OUT, 2, 3, 6, 7, 8 = GND, 4, 5 = V
3.95 W x 3.95 H x 0.8 D
SMD
Remote control
(1)
Sony 12, 15, and 20 bit IR-code
APPLICATION CIRCUIT
17170-11
Tran mitter
IR receiver
with
T ALxxxx
R
and C
recommended to reduce upply ripple for V < 2.8 V
1
1
1
www.vishay.com/doc?91000
TSOP37S40
(1)
S
R
1
V
+ V
C
1
μC
OUT
V
O
ND
Document Number: 82671
ND

Advertisement

loading
Need help?

Need help?

Do you have a question about the TSOP37 TT1 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Vishay TSOP37 TT1 Series

  • Page 1 TSOP37S40 www.vishay.com Vishay Semiconductors IR Receiver Modules for Remote Control Systems FEATURES • Very low supply current • Photo detectors and preamplifier in one package • Internal filter for PCM frequency • Optimized for Sony 12, 15, and 20 bit IR-code •...
  • Page 2: Absolute Maximum Ratings

    TSOP37S40 www.vishay.com Vishay Semiconductors ABSOLUTE MAXIMUM RATINGS PARAMETER TEST CONDITION SYMBOL VALUE UNIT Supply voltage -0.3 to +6 Supply current Output voltage -0.3 to (V + 0.3) Output current Junction temperature °C Storage temperature range -25 to +85 °C Operating temperature range -25 to +85 °C...
  • Page 3 TSOP37S40 www.vishay.com Vishay Semiconductors Optical Test Signal Correlation with ambient light sources: 10 W/m = 1.4 klx (std. illum. A, T = 2855 K) 10 W/m = 8.2 klx (daylight, T = 5900 K) Wavelength of ambient illumination: λ = 950 nm 600 µs...
  • Page 4 TSOP37S40 www.vishay.com Vishay Semiconductors Axis Title 0° 10° 20° 30° 0.30 0.25 40° 0.20 0.15 50° 0.10 60° 0.05 70° 80° - Ambient Temperature (°C) - Relative Transmission Distance 21947 rel. Fig. 9 - Sensitivity vs. Ambient Temperature Fig. 11 - Directivity 0.30...
  • Page 5 TSOP37S40 www.vishay.com Vishay Semiconductors SUITABLE DATA FORMAT Axis Title The TSOP37S40 series is designed to suppress spurious 10000 output pulses due to noise or disturbance signals. The devices can distinguish data signals from noise due to differences in frequency, burst length, and envelope duty cycle.
  • Page 6 TSOP37S40 www.vishay.com Vishay Semiconductors PACKAGE DIMENSIONS in millimeters 4 x 0.75 = 3 Not indicated tolerances ± 0.1 0.475 (0.3) 0.75 ± 0.05 technical drawings according to DIN specifications Pinning from topview (8 x) 0.35 ± 0.05 Pin 1 identification...
  • Page 7: Ordering Information

    • Handling after reflow should be done only after the work surface has been cooled off VISHAY LEAD (Pb)-FREE REFLOW SOLDER PROFILE Axis Title 10000 max. 260 °C 255 °C 245 °C...
  • Page 8 TSOP37S40 www.vishay.com Vishay Semiconductors TAPING VERSION TSOP37... DIMENSIONS in millimeters TT1 Ø 180 ± 2 = 1800 pc . Tape po ition coming out from reel Ø 21 ± 0.8 Ø 13 ± 0.2 Label po ted here (12.4) Part mounted Empty leader 400 mm min.
  • Page 9 The labels are on each packing unit final packing area. The standard packing units are labeled and contain Vishay Semiconductor GmbH specific data. VISHAY SEMICONDUCTOR GmbH STANDARD BAR CODE PRODUCT LABEL (finished goods) PLAIN WRITING ABBREVIATION LENGTH...
  • Page 10: Esd Precaution

    • Storage humidity ≤ 60 % RH max. BAR CODE LABELS After more than 168 h under these conditions moisture The Vishay Semiconductors standard bar code labels are content will be too high for reflow soldering. printed at final packing areas. The labels are on each...
  • Page 11 Except as expressly indicated in writing, Vishay products are not designed for use in medical, life-saving, or life-sustaining applications or for any other application in which the failure of the Vishay product could result in personal injury or death. Customers using or selling Vishay products not expressly indicated for use in such applications do so at their own risk.
