- Page 1 2.4Ghz Ergo Laser Mouse RF-MSE14 User Guide...
-
Page 2: Table Of Contents
2.4Ghz Ergo Laser Mouse Contents Introduction ..............4 Features ................. 4 Package contents ..........4 System requirements......... 4 Top................5 Bottom ..............7 Setting up the mouse ..........8 Installing the battery.......... 8 Setting up the mouse ........11 Installing the mouse driver and software 12 Configuring the Mouse ........18 Uninstalling the mouse driver and software25 Maintaining ..............26... - Page 3 Specifications ............27 Legal notices.............. 28 One-year limited warranty ........31 Important safety instructions 1 Read these instructions. 2 Keep these instructions. 3 Heed all warnings. 4 Follow all instructions. 5 Do not use this apparatus near water. 6 Clean only with a dry cloth. 7 Batteries should not be exposed to excessive heat such as sunshine, fire, or the like.
-
Page 4: Introduction
Introduction Congratulations on your purchase of the 2.4Ghz Ergo Laser Mouse. This mouse represents the state of the art in wireless mouse design and is designed for reliable and trouble-free performance. Features • Nano dongle • 2.4 GHz wireless connection •... -
Page 5: Top
5 6 7 Item Description C button Press to go to the previous page in a Web browser. B button Press to activate dynamic search. You must install the mouse driver to use this feature. A button Press to go to the next page in a Web browser. Left button Press to perform standard left-mouse actions such as selecting items and opening programs. - Page 6 Item Description DPI LED Indicates the current DPI setting. One LED lit— DPI is set to 800. Two LEDs lit— DPI is set to 1200. Three LEDs lit— DPI is set to 1600. Scroll wheel Roll to move the screen image up or down or tilt to move the screen left or right.
-
Page 7: Bottom
Bottom Item Description Battery comparntment Provides storage for the battery and dongle. Laser sensor Detects the mouse movements and sends signals to the computer to move the mouse pointer on the screen. Power button Slide to turn the mouse on or off. RF-MSE14... -
Page 8: Setting Up The Mouse
Setting up the mouse Installing the battery To install the battery: 1 Press the tab on the battery compartment cover, then lift the cover away from the mouse. - Page 9 2 Pull the dongle out of the battery compartment. 3 Insert one AA battery into the battery compartment. Make sure that the + and – symbols on the battery match the + and – symbols in the battery compartment. RF-MSE14...
- Page 10 4 Replace the battery compartment cover.
-
Page 11: Setting Up The Mouse
Setting up the mouse To set up the mouse: 1 Plug the USB dongle into a USB port on the computer. 2 Slide the power button on the bottom of the mouse to the right to turn on the mouse. The computer detects the mouse. -
Page 12: Installing The Mouse Driver And Software
Installing the mouse driver and software To use advanced functions, such as dynamic search and magnifier, you need to install the mouse driver and software. Note: The following instructions are based on the Windows® XP operating system. To install the mouse driver and software: 1 Make sure that you have installed the battery, connected the dongle, and turned on the mouse. - Page 13 3 Click Install Mouse Driver. The Welcome screen opens. 4 Click Next. The Start Installation screen opens. RF-MSE14...
- Page 14 5 Click Next. An installation progress bar appears. When the installation is complete, the Setup Complete screen opens. 6 Click Finish.
- Page 15 Using the mouse To use the mouse: • Press the left or right mouse buttons to perform standard left and right mouse clicks. • Move the scroll wheel to move the screen image up, down, left, or right. Tip: You can also scroll the screen by sliding your mouse instead of using the scroll wheel.
- Page 16 • Press button A to go to the next page in a Web browser or press button C to go the previous page in a Web browser. A button C button...
- Page 17 • Press button B to use the dynamic search function. B button Note: To use dynamic search, press the left mouse button and drag the mouse to highlight a word. Press the dynamic search button. The Google™ Web site opens and displays information about the word.
-
Page 18: Configuring The Mouse
Configuring the Mouse To configure the mouse: • Double-click the mouse icon on the system tray to open the mouse program, then click a tab to adjust a mouse function. If the mouse icon is not in your system tray, click Start, Settings, Control Panel, then click RF 2.46Ghz Ergo Laser Mouse. - Page 19 Configuring mouse buttons To configure the buttons: 1 Click the Button list arrow to open the list of buttons, then click the button you want to configure. 2 Click the Function list arrow to open the list of functions, then click the function you want to assign to the button. The default settings for the mouse buttons are: Button Function...
- Page 20 3 Click other tabs to make more adjustments, or click OK to save your selections and close the program. Note: To restore default button functions, click Use Default. Adjusting the double-click speed To adjust the double-click speed: 1 To adjust double-click speed, drag the slider. 2 To test the click speed, double-click the Test Area icon.
- Page 21 Adjusting the orientation Use this tab to adjust the angle at which you use the mouse. To adjust the orientation: 1 Click Set Orientation to activate orientation setup, then use the on-screen pointer to follow the dog as it moves around.
- Page 22 Adjusting the wheel settings To adjust the wheel settings: 1 To select the wheel scrolling method, click: • Enable Universal Scrolling—Uses common scrolling functions. • Use Microsoft Office 97 Scrolling Emulation Only—Uses Microsoft Office 97 scrolling emulation. 2 To specify scrolling exceptions, click Exceptions. 3 To adjust vertical scrolling speed, click: •...
- Page 23 5 To reverse scrolling direction, click Reverse Scrolling Direction. 6 Click other tabs to make more adjustments, or click OK to save your selections and close the program. Note: To restore to default scrolling speed, click Use Default. Adjusting the pointer behavior To adjust the pointer behavior: 1 Click a pointer option.
- Page 24 Hiding the system tray’s mouse icon To hide the system tray’s mouse icon: • Uncheck Show mouse icon in systray, then click OK to save changes and close the application.
-
Page 25: Uninstalling The Mouse Driver And Software25
Uninstalling the mouse driver and software To uninstall the mouse driver and software: 1 Unplug the dongle. 2 Click Start, Programs, RF 2.4Ghz Ergo Laser Mouse, then click Uninstall RF 2.4Ghz Ergo Laser Mouse Driver. A message asks if you are sure you want to uninstall the driver. 3 Click Yes to continue. -
Page 26: Maintaining
4 When the uninstallation is complete, click OK to continue. The Uninstall Complete screen opens. 5 Click Finish. Your computer restarts and the uninstallation is complete. Maintaining To clean the mouse: • Wipe the surface and the optical sensor with a soft, lint-free cloth slightly moistened with water. -
Page 27: Troubleshooting
Troubleshooting If you experience any problems with the mouse, check the following: • Make sure that your computer meets the system requirements. • Make sure that the battery in the laser mouse is installed correctly. Make sure the polarity of the battery corresponds with the polarity symbols inside the battery compartment. - Page 28 Storage temperature -40° to 140°F (-40° to 60°C) Operating humidity 90% RH or less Storage humidity 95% RH or less Battery AA (1) Regulations and EMI, ESD, RS, EFT, FCC, EC, IC, IEC-003 certifications Legal notices FCC Part 15 This device complies with Part 15 of the FCC Rules. Operation of this product is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause...
- Page 29 FCC warning Changes or modifications not expressly approved by the party responsible for compliance with the FCC Rules could void the user’s authority to operate this equipment. DHHS and FDA safety certification This product is made and tested to meet safety standards of the FCC, requirements and compliance with safety performance of the U.S.
- Page 30 Products and parts replaced under this warranty become the property of Rocketfish and are not returned to you. If service of Products and parts are required after the Warranty Period expires, you must pay all labor and parts charges.
- Page 31 How to obtain warranty service? If you purchased the Product at a retail store location, take your original receipt and the Product to the store you purchased it from. Make sure that you place the Product in its original packaging or packaging that provides the same amount of protection as the original packaging.
- Page 32 7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645 © 2009 Best Buy Enterprise Services, Inc. All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
- Page 33 7601 Penn Avenue South, Richfield, MN 55423-3645 USA © 2009 Best Buy Enterprise Services, Inc. All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. All other products and brand names are trademarks of their respective owners.
