RocketFish RF-NANMSE User Manual

RocketFish RF-NANMSE User Manual

Nano laptop laser mouse
Hide thumbs Also See for RF-NANMSE:
Table of Contents

Advertisement

Quick Links

Download this manual
Nano Laptop Laser Mouse
User Guide
RF-NANMSE

Advertisement

Table of Contents
loading

Related Manuals for RocketFish RF-NANMSE

Summary of Contents for RocketFish RF-NANMSE

  • Page 1 Nano Laptop Laser Mouse User Guide RF-NANMSE...

  • Page 3: Table Of Contents

    Specifications...21 Legal notices ...22 One-year limited warranty...25 Introduction Congratulations on your purchase of the Rocketfish RF-NANMSE nano laptop laser mouse. This mouse represents the state of the art in wireless mouse design and is designed for reliable and trouble-free performance.

  • Page 4: Package Contents

    Package contents • Mouse • Receiver • Installation CD (includes software and User Guide) • Quick Setup Guide • AA battery System requirements • At least one USB port (USB 2.0 or 1.1) • CD drive • Operating system: Windows® 2000, Windows® XP with Service Pack 1 or...
  • Page 5 Scroll wheel Right button Note: The A and B buttons are programmable. You need to install the mouse drive to program the buttons and to use the full functionality of the mouse. For more information, see “Installing the mouse driver and software” on page 10.
  • Page 6 Power button Battery compartment Laser sensor 7 8 9 Description Turns the mouse on or off. Provides storage for the dongle and battery. Detects mouse movements and sends signals to the laptop to move the mouse pointer on the screen.

  • Page 7: Setting Up The Mouse

    Setting up the mouse Installing the battery To install the battery: Press the tab on the battery compartment cover, then lift the cover away from the mouse. Pull the dongle out of the battery compartment. RF-NANMSE...
  • Page 8 Insert one AA battery into the battery compartment. Make sure that the + and – symbols on the battery match the + and – symbols in the battery compartment. Replace the battery compartment cover.
  • Page 9 Setting up the mouse To set up the mouse: Plug the USB dongle into a USB port on the laptop. Slide the power button on the bottom of the mouse down to turn on the mouse. The laptop detects the mouse. RF-NANMSE...

  • Page 10: Installing The Mouse Driver And Software

    Insert the provided installation CD in the CD drive on the laptop. The installation program should start automatically. If it does not start automatically, open Windows Explorer, browse the CD, then double-click autorun.exe. The Rocketfish Nano Laptop Laser Mouse screen opens. Click Install Mouse Driver. The Welcome screen opens.
  • Page 11 Click Next. The Start Installation screen opens. Click Next. A installation progress bar appears. When the installation is complete, the Setup Complete screen opens. Click Finish. RF-NANMSE...

  • Page 12: Using The Mouse

    Move the scroll wheel to move the screen image up, down, left, or right. Tip: You can also scroll the screen by sliding your mouse instead of using the scroll wheel. To do this, press down on the scroll wheel. A four-way icon appears on the screen.

  • Page 13: Configuring The Mouse

    Configuring the mouse To configure the mouse: • Double-click the mouse icon program, then click a tab to adjust a mouse function. You can select any of the following tabs: • Buttons—See “Configuring mouse buttons” on page 14. • Double-Click—See ”Adjusting the double-click speed” on page 15.
  • Page 14 Click the Function list arrow to open the list of functions, then click the function you want to assign to the button. To restore default button functions, click Use Default. The default settings for the mouse buttons are: Button Left button...
  • Page 15 To adjust double-click speed, drag the slider. To test the click speed, double-click the Test Area icon. To restore to default settings, click Reset to Default Value. Click other tabs to make more adjustments, or click OK to save your selections and close the program. RF-NANMSE...
  • Page 16 Adjusting the orientation Use this tab to adjust the angle at which you use the mouse. To adjust the orientation: Click Set Orientation to activate orientation setup, then use the on-screen pointer to follow the dog as it moves around.
  • Page 17 To adjust the horizontal scrolling speed, drag the slider. To restore to default scrolling speed, click Use Default. To reverse scrolling direction, click Reverse Scrolling Direction. Click other tabs to make more adjustments, or click OK to save your selections and close the program. RF-NANMSE...
  • Page 18 Adjusting pointer behavior To adjust pointer behavior: Click the pointer options. You can select: • Pointer Wrap—The pointer goes to the opposite side of the screen when it reaches the screen edge. • X Focus—Activates a window when the pointer moves over the title bar.

  • Page 19: Uninstalling The Mouse Driver And Software

    Unplug the dongle. Click Start, All Programs, Rocketfish Nano Laptop Laser Mouse, then click Uninstall Rocketfish Nano Laptop Laser Mouse Driver. A message asks if you are sure you want to uninstall the driver. Click Yes to continue. The Remove Programs From Your Computer screen opens and displays the progress.

  • Page 20: Maintaining

    • When the mouse LED lights red, the battery power is low. Replace the battery with a new one. • If the laser mouse fails to work, check the USB port to see if the dongle is correctly connected. • Only use the mouse on a clean, flat, non-slippery surface to ensure smooth and accurate cursor action.

  • Page 21: Specifications

    Specifications Specifications subject to change without notice. Dimensions Mouse: 1.49 × 3.78 × 2.37 inches (37.78 × 95.92 × 60.23 mm) H × L × W Dongle: 0.26 × 0.74 × 0.59 inches (6.60 × 18.80 × 15.00 mm) Resolution...

  • Page 22: Legal Notices

    Legal notices FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-vide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in-stalled and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 23 This device may not cause harmful interference and This device must accept any interference, including interference that may cause undesired operation of the device. Canada ICES-003 statement This Class B digital apparatus complies with Canadian ICES-003. RF-NANMSE...

  • Page 25: One-Year Limited Warranty

    Product is determined to be defective by an authorized Rocketfish repair center or store personnel, Rocketfish will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable products or parts. Products and parts replaced under this warranty become the property of Rocketfish and are not returned to you.
  • Page 26 7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645 © 2009 Best Buy Enterprise Services, Inc. All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
  • Page 28 7601 Penn Avenue South, Richfield, MN 55423-3645 USA © 2009 Best Buy Enterprise Services, Inc. All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. All other products and brand names are trademarks of their respective owners...
