RocketFish RF-WTRMS User Manual
Wireless optical notebook mouse
Hide thumbs
Also See for RF-WTRMS:
- User manual (44 pages) ,
- User manual (16 pages) ,
- User manual (16 pages)
Subscribe to Our Youtube Channel
Related Manuals for RocketFish RF-WTRMS
Summary of Contents for RocketFish RF-WTRMS
- Page 1 Wireless Optical Notebook Mouse RF-WTRMS User Guide...
-
Page 2: Table Of Contents
Legal notices ..............11 Introduction Congratulations on your purchase of a Rocketfish optical notebook mouse! Your Rocketfish mouse is sensitive to any movement, making it easy for you to control the on-screen pointer. It’s also easy to set up, and its self-storing USB receiver makes it convenient for travel anywhere. -
Page 3: System Requirements
• USB port Operating system • Microsoft® Windows® 98SE/Me/2000/XP and Mac Using the mouse Installing the batteries To install the batteries: 1 Press the battery cover release button, then slide the battery cover off the mouse. Battery cover release button RF-WTRMS... - Page 4 2 Insert batteries into the battery compartment. Make sure that the positive (+) and negative (-) ends of each battery match the diagrams inside the battery compartment. 3 Slide the battery cover back onto the mouse. Removing the receiver from the mouse The USB RF receiver is conveniently stored on the bottom of the mouse.
- Page 5 • Plug the USB receiver into an available USB port on your computer. The receiver’s LED turns red, and your computer identifies the receiver and begins installing the default driver. : If a message or dialog box appears on the screen, follow the on-screen prompts to complete the driver installation. RF-WTRMS...
- Page 6 Linking the mouse and receiver The mouse has 256 identification codes that allow the mouse and its receiver to operate without interference from other RF devices. After your computer detects the USB receiver and the default driver is installed, you must make a communications link between the mouse and its receiver before you can use the mouse.
- Page 7 Dark surfaces cause the mouse’s light emitter diode (LED) to glow brighter, which causes the battery to discharge more rapidly. Conserving power When the mouse batteries are running low on power, the LED light on the receiver turns red and blinks. RF-WTRMS...
- Page 8 To use your mouse’s Sleep mode: 1 Do not use your mouse for five minutes. After five minutes of inactivity, the mouse automatically enters Sleep mode to conserve battery power. 2 To wake the mouse, just move the mouse or click a mouse button.
-
Page 9: Troubleshooting
• Make sure that the receiver’s USB plug is firmly connected to the USB port on your computer. • Make sure that the appropriate device drivers are installed. • Make sure that you have made a radio link between the mouse and its receiver. RF-WTRMS... - Page 10 When you use the mouse, other wireless devices work more slowly or fail temporarily. • The mouse may cause interference with any cordless, radio-based device that operates at 27 MHz, such as a telephone, baby monitor, or toy. To reduce interference, move the mouse’s receiver and the base unit of the affected device as far away from each other as possible.
-
Page 11: Specifications
USB low-speed device HID class Radio frequency 27 MHz Dimensions 0.79 × 0.39 × 2.8 inches (20 × 10 × 71 mm) Operating voltage 5V (powered by USB port) Operating current Below 15 mA Legal notices FCC statement Wireless Optical Notebook Mouse—RF-WTRMS RF-WTRMS... - Page 12 • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced technician for help. Rocketfish 7601 Penn Avenue South • Richfield, MN 55423 1-800-620-2790...
- Page 13 Copyright © 2008 Rocketfish. Rocketfish and the Rocketfish logo are trademarks of Best Buy Enterprise Services, Inc. Other brands and product names are trademarks or registered trademarks of their respective holders. Specifications and features are subject to change without notice or obligation.
- Page 15 RF-WTRMS...
- Page 16 7601 Penn Avenue South, Richfield, MN 55423-3645 USA © 2008 Best Buy Enterprise Services, Inc. All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. All other products and brand names are trademarks of their respective owners.
